Model PRO-9342FT

Owner's Manual

Page 1

FEATURES :

2 Two Button Programmable RF Transmitters

Two Channel Receiver ( capable of accepting 4 transmitters )

Anti-scan Technology

Remote Panic in all modes

Protected Valet

7 Function LED - Arm / Disarm / Zone1/Zone2/Zone3/Valet / Arming

Intrusion Alert with Memory

Audible Arm / Disarm / Defective Zone / Tamper Confirmation

Instant Siren Activation

Low Current Horn Output

True Last Door Arming ( hardwire only )

Defective Zone By - Pass

Hardwire or Voltage Sense Selectable

Active or Passive Arming Selectable

Programmable Auto Lock On / Off

Programmable Auto Unlock On / Off

Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds

Programmable Active or Passive Door Locks

User Programmable Permanent Chirp Delete

On Command RF Chirp Delete from Transmitter

6 Tone Multi - Tone Siren

RF Inhibit with ignition on

Parking Light Flasher

OPTIONS :

Single or Dual Stage Shock Sensor

Starter Disable

Remote Trunk Release

Remote Keyless Entry

Multiple Vehicle Capable

Remote Starter

Remote Power Window Roll Up

Remote Garage Door Interface

2 Button Remote Security System

ARMING THE SYSTEM - ACTIVE

1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.

2. Press and release the Lock/"Arm" / Unlock/"Disarm" button on the keychain transmitter.

Red dash mounted L.E.D. begins to flash slowly.

Parking Lights flash one time.

Siren and or Horn sounds one chirp.

If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.

Simply close the opened entry point to provide full protection. If the siren/horn

did not sound when arming, then the chirps have been turned off, and you

should refer to the section titled “ ELIMINATING THE ARM / DISARM CHIRPS “

in this manual.

Doors Lock - Optional

SILENT ARMING - ACTIVE

1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid.

2. Press and hold the Lock/"Arm" / Unlock/"Disarm" button on the keychain transmitter for

2 seconds.

Red dash mounted L.E.D. begins to flash slowly.

Parking Lights flash one time.

Siren/Horn will not sound.

If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid

ajar. Simply close the opened entry point to provide full protection.

Doors Lock - Optional

ARMING THE SYSTEM - PASSIVE ( AUTOMATIC )

1. Turn off the engine, exit the vehicle, and close and lock all doors, hood lid, and trunk lid.

Red dash mounted L.E.D. begins to flash rapidly, indicating 30 second passive

arming has begun.

2. Opening any protected entry point during the 30 second passive arming cycle will

immediately suspend automatic arming, and the 30 second passive arming cycle will re

start when all doors are closed. At the end of the passive arming cycle;

Red dash mounted L.E.D. begins to flash slowly.

Parking Lights flash one time.

Siren and or Horn sounds one chirp

If the siren/horn did not sound when arming, then the chirps have been turned

off, and you should refer to the section titled “ ELIMINATING THE ARM / DISARM

CHIRPS “ in this manual.

Doors Lock - Optional

Door locking during passive arming is a selectable feature. The alarm can be

programmed to allow the doors to lock only when arming using the keychain

transmitter, and they will not automatically lock during passive arming.

PROTECTION WHILE THE SYSTEM IS ARMED

Opening any protected door, hood, or trunk lid will cause the alarm to immediately

Page 2

Page 3

sound. The alarm will continue to sound for 30 seconds, then stop and continue

to monitor all protected entry points. If the thief left a door opened, the alarm will

sound for six 30 second cycles, remain armed and ignore that triggered zone.

Whenever the system is armed, the red dash mounted L.E.D. indicator will slowly

flash. This serves as a visual deterrent to the potential thief. The L.E.D. is a very

low current bulb, and will not cause the vehicle’s battery to drain, even when left

unattended for extended periods.

Whenever the system is triggered, the vehicle’s parking lights will flash for the

full 30 second alarm cycle, attracting visual attention to the vehicle.

Optional - Whenever the system is armed, the vehicle’s starting circuit will be

bypassed. If the thief should choose to ignore the siren/horn, the vehicle can not

be started.

Optional - Any strong impact to the vehicle will cause the alarm to trigger for the

full 30 second alarm cycle.

Optional - Any mild impact to the vehicle will cause the alarm to sound a short

series of warning tones.

DISARMING THE SYSTEM

1. As you approach the vehicle, press and release the Lock/"Arm" / Unlock/"Disarm"

button on the keychain transmitter.

Red dash mounted L.E.D. turns off.

If passive arming was selected during the installation, then the L.E.D. will start

flashing rapidly, indicating that the system is re arming automatically. Open any

door to suspend the automatic arming.

Parking Lights flash two times.

If the parking lights flashed three times, then the alarm was triggered in your

absence. Before turning the key on, examine the L.E.D. to identify which zone

was triggered.

Siren / Horn sounds two chirps.

If the siren/horn sounds 4 chirps, then the alarm was triggered in your absence.

Before turning the key on, examine the L.E.D. and refer to the INTRUSION

WARNING SIGNALS section of this manual to identify which zone was triggered.

If the siren/horn did not sound when disarming, then the chirps have been

turned off, and you should refer to the section titled “ ELIMINATING THE

Lock/"Arm" / Unlock/"Disarm" CHIRPS “ in this manual.

Doors Unlock - Optional

SILENT DISARMING

1. As you approach the vehicle, press and hold the Lock/"Arm" / Unlock/"Disarm" button on

the keychain transmitter for 2 seconds.

Red dash mounted L.E.D. turns off.

If passive arming was selected during the installation, then the L.E.D. will start

flashing rapidly, indicating that the system is re arming automatically. Open any

door to suspend the automatic arming.

Page 4

Parking Lights flash two times.

If the parking lights flashed three times, then the alarm was triggered in your

absence. Before turning the key on, examine the L.E.D. to identify which zone

was triggered.

Siren/Horn does not sound.

If the siren and or horn sounds 4 chirps, then the alarm was triggered in your

absence. Before turning the key on, examine the L.E.D. and refer to the INTRUSION

WARNING SIGNALS section of this manual to identify which zone was triggered.

Doors Unlock - Optional

INTRUSION WARNING SIGNALS

This system will inform you if an intrusion attempt has occurred while you were away from

the vehicle. If an intrusion attempt has occurred, the siren/horn will chirp 4 times and the

parking lights will flash 3 times when disarming the system. Enter the vehicle, and observe

the red dash mounted L.E.D. to identify which zone was triggered.

If the L.E.D. is flashing one time...pause...one time...pause...etc., then an intrusion

attempt was made to the optional shock sensor, or an accessory triggering device

that may have been added to the system.

If the L.E.D. is flashing two times...pause...two times...pause...etc., then an intrusion

attempt was made to a hood or trunk pin switch that was added to the system, or to

a light activated entry point if the alarm was installed using the voltage sensing

feature.

If the L.E.D. is flashing three times...pause...three times...pause...etc., then an

intrusion attempt was made through one of the vehicle’s doors.

These intrusion warning indicators are stored in the system’s memory, and will only be

erased when the ignition key is turned on.

VALET / SYSTEM OVERRIDE SWITCH

The valet switch allows you to temporarily bypass all alarm functions, eliminating the need

to hand your transmitter to parking attendants or garage mechanics. When the system is in

valet mode, all alarm functions are bypassed, however the remote panic feature and remote

door locks will remain operational. To use the valet mode;

1. Enter the vehicle, and turn the ignition key to the on position.

2. Move the valet toggle switch to the on position. The dash mounted L.E.D. will turn

on solid, and remain on as long as the system is in valet mode.

3. To return to normal operation, move the valet switch back to the off position any

time the ignition is on.

In the event that you lose your keychain transmitter, or if the transmitter fails to disarm the

system, the valet switch can be used to disarm the alarm. Open the vehicle’s door ( the

alarm will sound ). Turn the ignition key on, and move the valet switch to the on position. The

alarm will disarm, and the vehicle can now be started.

NOTE : Always remember to move the valet switch back to the off position. This will ensure

that the vehicle remains protected at all times.

Page 5

ELIMINATING THE NORMAL ARM / DISARM CHIRPS

As explained earlier in the manual, you can eliminate the chirps selectively any time you arm

or disarm the system simply by holding the Lock/"Arm" / Unlock/"Disarm" button for two

seconds. If you find the normal arming and disarming chirps annoying, they can be turned

off permanently, eliminating the need to hold the Lock/"Arm" / Unlock/"Disarm" button for

two seconds. To do this,

1. With the valet switch in the off position, turn the ignition key on then off.

2. Within 10 seconds, move the valet switch to on then off three times.

3. If the chirps were on before you started, then you will hear 2 chirps indicating

they have been turned off.

If the chirps were off before you started, then you will hear one chirp indicating

they have been turned on.

NOTE: If the siren/horn chirps two times, regardless of the valet switch operation as

described above, then the horn and siren chirps have been turned off via programming

features7&8. Contact your installation center or Audiovox technical department for

information on how to reinstate the chirp feature through programming.

NOTE: Whenever the chirps are by - passed, the 4 chirp intrusion indicator and 3 chirp

defective zone indicator will always operate. Since these are important warnings to you

that something has happened, they cannot be eliminated.

REMOTE PANIC OPERATION

The Lock/"Arm" / Unlock/"Disarm" button on your keychain transmitter also functions as a

panic switch for use in emergency situations. To use remote panic,

1. Press and hold the Lock/"Arm" / Unlock/"Disarm" button on the keychain

transmitter for 3 or more seconds. The alarm will immediately sound.

2. To stop the alarm, press and hold the Lock/"Arm" / Unlock/"Disarm" button on

the transmitter again for 3 seconds. If the button is not pressed, the alarm will

automatically stop after 30 seconds.

NOTE: All normal transmitter functions will operate in the panic mode.

ADDITIONAL REMOTE FUNCTION ( CHANNEL 2 )

This security system has an additional feature that can be connected to a number of

different optional accessories. Some of the more common uses for this channel are;

Remote Trunk Release

Remote Car Starter

Remote Window Closure

Remote Garage Door Interface

To activate the optional accessory, press and hold the option button 2 on the keychain

transmitter for 3 seconds.

Page 6

PRO-9342FT

SYSTEM FUNCTIONS AT A GLANCE

DASH L.E.D. INDICATORS

RAPID FLASHING = PASSIVE ARMING

SLOW FLASHING = ARMED

OFF = DISARMED

ON SOLID = VALET MODE

3 FLASH...PAUSE = INTRUSION ZONE 3

2 FLASH...PAUSE = INTRUSION ZONE 2

1 FLASH...PAUSE = INTRUSION ZONE 1

SIREN CHIRP INDICATORS

1 CHIRP * = ARM

2 CHIRPS * = DISARM

3 CHIRPS = ARM / DOOR OPENED

4 CHIRPS = DISARM / INTRUSION

* These chirps are optional, and can be de - activated.

PARKING LAMPS

1 FLASH = ARM

2 FLASHES = DISARM

3 FLASHES = DISARM / INTRUSION

Your System Has These Features Activated

Single Stage Shock Sensor

Dual Stage Shock Sensor

Remote Keyless Entry

Starter Disable when armed

Auto Lock with ignition key

Auto Unlock with ignition key

Passive Arming

No Lock in passive mode

Hardwire doors, hood, and trunk

Siren Activation

Horn Activation

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Audiovox Alarme de voiture

Audiovox

Audiovox 5BCR07 Mode d'emploi

Audiovox

Audiovox Prestige APS-25KB Manuel utilisateur

Audiovox

Audiovox Professional PS-230i Manuel utilisateur

Audiovox

Audiovox Prestige Platinum APS-995C Manuel utilisateur

Audiovox

Audiovox Protodyne PRO-300A Manuel utilisateur

Audiovox

Audiovox APS-800 Manuel utilisateur

Audiovox

Audiovox Pursuit PRO-9056 Manuel utilisateur

Audiovox

Audiovox Prestige APS-920 Manuel utilisateur

Audiovox

Audiovox Prestige Platinum 128-5730A Manuel utilisateur

Audiovox

Audiovox Prestige Platinum APS-400 Manuel utilisateur

Audiovox

Audiovox Prestige Platinum APS-300R Manuel utilisateur

Audiovox

Audiovox Prestige Platinum APS 995 Manuel utilisateur

Audiovox

Audiovox APS996A - Prestige Remote Security System Manuel utilisateur

Audiovox

Audiovox Pursuit PRO 9845B Manuel utilisateur

Audiovox

Audiovox Prestige Platinum APS-596N Manuel utilisateur

Audiovox

Audiovox UltraGuard PRO 9549UG Manuel utilisateur

Audiovox

Audiovox APA-800a Manuel utilisateur

Audiovox

Audiovox RO9801 Manuel utilisateur

Audiovox

Audiovox Pursuit PRO 9842B Manuel utilisateur

Audiovox

Audiovox 5BCR03 Mode d'emploi

Audiovox

Audiovox PRO-9276C Manuel utilisateur

Audiovox

Audiovox Auto Security 5BCR Guide de dépannage

Audiovox

Audiovox APS996A - Prestige Remote Security System Manuel utilisateur

Audiovox

Audiovox Pursuit PRO-9675FT4 Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur

Clifford

Clifford Nova 3 Manuel utilisateur

Viper

Viper 560XV Manuel utilisateur
