AudioCodes Mediant Guide de démarrage rapide

Configuration Note

Multi-Service Business Routers Product Series

Mediant MSBR

Layer 2 Bridging using the CLI

Version 6.8

Version 6.8 3 Mediant MSBR

Configuration Note Contents

Table of Contents

1Introduction .........................................................................................................7

2Layer 2 Switching Interfaces..............................................................................9

2.1 Commands.............................................................................................................9

2.2 Examples .............................................................................................................10

3VLANs ................................................................................................................11

3.1 Commands...........................................................................................................11

3.2 Examples .............................................................................................................12

4Trunk Bridging ..................................................................................................15

4.1 Commands...........................................................................................................15

4.2 Examples .............................................................................................................16

5Port-Monitoring .................................................................................................17

5.1 Commands...........................................................................................................17

5.2 Examples .............................................................................................................18

6Bridge Group Virtual Interface (BVI) Interfaces..............................................21

6.1Commands...........................................................................................................21

6.2 Examples .............................................................................................................22

7802.1p Priority/Layer 2 QoS..............................................................................25

7.1 Commands...........................................................................................................25

7.2 Examples .............................................................................................................25

8QinQ ...................................................................................................................27

8.1 Commands...........................................................................................................27

8.2 Example...............................................................................................................28

9Pseudo Wires ....................................................................................................29

9.1 Connectivity Fault Management (CFM) ................................................................29

9.2 Commands...........................................................................................................29

9.3 Example...............................................................................................................30

Configuration Note 4 Document #: LTRT-31672

Layer 2 Bridging using CLI

This page is intentionally left blank.

Version 6.8 5 Mediant MSBR

Configuration Note Notices

Notice

This document describes the configuration of the Layer 2 bridging provided by AudioCodes

Mediant Multi-Service Business Router (MSBR) series.

Information contained in this document is believed to be accurate and reliable at the time of

printing. However, due to ongoing product improvements and revisions, AudioCodes cannot

guarantee accuracy of printed material after the Date Published nor can it accept responsibility

for errors or omissions. Before consulting this document, check the corresponding Release

Notes regarding feature preconditions and/or specific support in this release. In cases where

there are discrepancies between this document and the Release Notes, the information in the

Release Notes supersedes that in this document. Updates to this document and other

documents as well as software files can be downloaded by registered customers at

http://www.audiocodes.com/downloads.

This document is subject to change without notice.

Date Published: June-22-2016

Trademarks

AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s

Inside Matters, OSN, SmartTAP, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To

VoIP, 3GX, VocaNOM and CloudBond 365 are trademarks or registered trademarks of

AudioCodes Limited All other products or trademarks are property of their respective

owners. Product specifications are subject to change without notice.

WEEE EU Directive

Pursuant to the WEEE EU Directive, electronic and electrical waste must not be disposed

of with unsorted waste. Please contact your local recycling authority for disposal of this

product.

Customer Support

Customer technical support and services are provided by AudioCodes or by an authorized

AudioCodes Service Partner. For more information on how to buy technical support for

AudioCodes products and for contact information, please visit our Web site at

www.audiocodes.com/support.

Abbreviations and Terminology

Each abbreviation, unless widely used, is spelled out in full when first used.

Document Revision Record

LTRT Description

31672 Added Q-in-Q section.

Configuration Note 6 Document #: LTRT-31672

Layer 2 Bridging using CLI

Documentation Feedback

AudioCodes continually strives to produce high quality documentation. If you have any

comments (suggestions or errors) regarding this document, please fill out the

Documentation Feedback form on our Web site at http://www.audiocodes.com/downloads.

Configuration Note 1. Introduction

Version 6.8 7 Mediant MSBR

1 Introduction

This document describes the Layer 2 bridging configuration on the MSBR device.

Configuration Note 8 Document #: LTRT-31672

Layer 2 Bridging using CLI

This page is intentionally left blank.

Configuration Note 2. Layer 2 Switching Interfaces

Version 6.8 9 Mediant MSBR

2 Layer 2 Switching Interfaces

In the MSBR, the Layer 2 switching is hardware-based and uses the host's Media Access

Control (MAC) address from the host's network interface cards (NICs) to decide where to

forward frames. The MAC addresses that the MSBR acquires are used to build a MAC

Address table, also known as a ''CAM Table''. Layer 2 switching interfaces also support

high speed, low latency, and wire speed.

2.1 Commands

The table below describes Layer 2 switching Interface commands.

Table 2-1: Layer 2 Switching Interfaces

Command Description

MSBR# configure data

Enter the data configuration menu.

(config-data)# interface

<physical_interface>

[slot/port.vlanID]

The interface command allows you to enter

a specific interface configuration mode.

<physical_interface> - selects the type of

interface.

[slot/port.vlanID] – slot and port number is

taken from the device panel.

Note: The interface configuration mode

changes after the command is entered.

(conf-if-GE SlotNum/PortNum)#

desc [WORD] Defines a description. It is a recommended

to write a useful and informative interface

description.

(conf-if-GE SlotNum/PortNum)#

duplex [Auto/Half/Full] Configures negotiation duplex on the

interface:

•Auto (default)

•Half

•

Full

(conf-if-GE SlotNum/PortNum)#

speed[10/100/Auto] Configures speed negotiation on the

interface:

•10

•100

•

Auto (default)

(conf-if-GE SlotNum/PortNum)#

shutdown

Disables the interface.

Configuration Note 10 Document #: LTRT-31672

Layer 2 Bridging using CLI

Command Description

(conf-if-GE SlotNum/PortNum)#

spanning-tree [cost/edge/point-

to-point/priority]

Relates to the spanning-tree protocol (STP)

issues on the interface.

•edge – this type of port mode will not

participate on spanning-tree converge

and acts as a port fast port according to

STP.

•cost – sets a cost value for the interface

to be used in calculations of the cost to

the root bridge in STP.

•point-to-point – enables link type point-to-

point to make the link become designated

port.

•priority – local priority number on

interface configuration mode.

MSBR# sh data interface

<physical_interface>

[slot/port.vlanID]

Displays interface statistics, port mode,

speed, duplex and PoE information.

2.2 Examples

This example shows how to configure an interface to access mode and auto-negotiation

100BaseT full permanent:

#interface configured as access mode

MSBR(config-data)# interface gigabitethernet 4/1

MSBR(conf-if-GE 4/1)# duplex full

MSBR(conf-if-GE 4/1)# speed 100

MSBR(conf-if-GE 4/1)# switchport mode access

MSBR(conf-if-GE 4/1)# spanning-tree edge enabled

MSBR(conf-if-GE 4/1)# exit

MSBR(config-data)# interface vlan 200

MSBR(config-data)# interface vlan 300

#interface configured as Trunk mode

MSBR(config-data)# interface gigabitethernet 4/2

MSBR(conf-if-GE 4/2)# switchport mode trunk

MSBR(conf-if-GE 4/2)# switchport native vlan 200 [ All Untagged

packets send to vlan 200]

MSBR(config-data)# interface gigabitethernet 4/3

MSBR(conf-if-GE 4/3)# switchport mode trunk

MSBR(conf-if-GE 4/3)# switchport native vlan 300[ All Untagged

packets send to vlan 300]
