AtlonA

Miniature Multimode Fiber Optic HDMI

Extension Kit

AT-HDF30SR

User Manual

TABLE OF CONTENTS

1. Introduction .................................................. 1

2. Features .................................................. 1

3. Specication .................................................. 2

4. Package Contents .................................................. 2

5. Operation .................................................. 3

6. Audio .................................................. 3

7. Serial Data .................................................. 3

8. RS-422 Serial Data .................................................. 3

9. Connection Diagram .................................................. 4

10. Safety Information .................................................. 5

11. Warranty .................................................. 6

12. Atlona Product Registration .................................................. 7

INTRODUCTION

Atlona Technologies’ new AT-HDF30S (Transmitter) and AT-HDF30R ( Receiver ) units are low cost, Fi-

ber Optic HDMI baluns. This extremely small and high performance solution will carry HDMI audio/video

signal, bi-directional stereo audio and 2 channels of RS-232 through one multimode ber. This Mini-HDMI

ber optic transmitter allows any HD video source to extend signal up to 400m at WUXGA (1920x1200 @

60Hz) and supports HDTV resolution up 1080p. Multiple signals can run through a single conduit without

crosstalk or interference . Along with being HDCP compliant, this unit is capable of transmitting DVI video

signal with an Atlona DVI-to-HDMI adapter.

Atlona’s AT-HDF30SR is equipped with advanced digital ber optic technology allowing for self adjust-

ment with no com¬pression, bit reduction, or signal degradation. These units support 12-bit color depth

and have an 8dB input equalizer, which compensates losses over 5m (16ft). With this self-adjustment and

no power cord needed, quick and easy set up is as simple as plug and play.

The AT-HDF30S is compatible with other Atlona products including the AT-DVIF30R and AT-RGBF30R

(for non HDCP signal only ). Using one of these units on the receiver end will not only transmit signal, but

also convert from HDMI-to-RGB/YPbPr/DVI in a single setup. This extension kit is the perfect solution for

Video Wall Presentations and all Digital Signage applications due to its long range, conversion ability, and

lossless signal transmission.

• HDMI v1.3 Compliant

• Supported signals:

Digital Audio Video

Bi-Directional Stereo Audio

Channel RS232

• Supported resolutions at 400M ( 1320FT )

PC : 1920x1200 (60Hz)

HDTV: 1080p/1080i/720p

• Supports HDCP/DDC Content

• No loses, no degradations, no crosstalk

• One Multimode ( SC type ) Fiber

• 12-bit color depth and 8dB equalizer

• MAC/PC compatible

• High secure signal transfer

• Compatible with AT-DVIF30R and AT-RGBF30R

FEATURES:

SPECIFICATIONS:

Video

Resolution Up to 1080p@60Hz or

1920x1200@60Hz

Connector HDMI Female Plug

Protocol HDCP/DDC Capable

Audio

Channel Capacity 2

Operating Mode Unbalanced (Stereo Audio),

Bi-directional

Input/Output Impedance 10k/50 Ohms (Stereo Audio)

Max. Input/Output Level 5 dBu/4Vpp (Stereo Audio)

Magnitude Freq. Re-

sponse

20Hz to 20kHz @ -3dB

THD+N >70 @ 1k Hz (Stereo Audio)

Connector Terminal Block

Optical

Fiber Type Multimode

Number of Fibers 1

Connector SC

Serial Data

Channel Capacity 2

Signal Format RS-232

Data Rate Up to 57.6kbaud

Connector Terminal Block

Physical

Dimension (H x W x D) 0.75” x 2.75” x 3.0”

Power Level (max.) +5VDC @ 1.0A

Operating Temperature 0 to +50oC

Humidity 0 to 95% RH, non-condensing

• AT-HDF30S x 1

(Units Sold Separately)

• AT-HDF30R x 1

• Operation Manual x 1

PACKAGE CONTENTS:

2 3

1. Make sure, if plugged into a source, the power is off before proceeding with the ber optic installation.

2. Connect (SC type) Multimode ber from Sender unit to Receiver by connecting one unit’s ber optical

port to the others.

3. Connect the AT-HDF30SR (Transmitter) HDMI video input to the HDMI video source.

4. Next, connect the AT-HDF30SR (Receiver) HDMI video output directly to the HDMI video receiver

using proper HDMI cable.

Atlona’s AT-HDF30SR audio interface supports two channel high delity transmissions. Two separate

mono channels or one stereo channel can be transmitted in each direction while the Line-level audio

signals remain connected to the units.

When SENDING the audio signal, connect two cables to the “AUDIO OUTPUT” connectors of the line-

level source. On the HDF30SR, connect the other end of the cables to the front panel terminal block

connectors labeled “AUDIO IN”. For stereo channels, be sure to match the cables at both ends (L to L,

R to R).

When RECEIVING the audio signal, label and connect two twisted-pair cables to the “AUDIO INPUT”

connectors of the line level audio receiver. On the AT-HDF30SR, connect the other end of the cables to

the front panel terminal connectors labeled “AUDIO OUT”. If using stereo channels, be sure to match

the cables at both ends (L to L, R to R).

Atlona’s AT-HDF30SR units can be used for RS-232 interface as well as transmits two channels of un-

balanced data signals

1. Connect one serial computer data cable to the the RS-232 device.

2. Next, Connect the other end of cable to the front panel data terminal connector on the

AT-HDF30SR.

Atlona’s AT-HDF30SR units transmit a single channel of differential data signals which are compatible

with RS-422 electrical signals

1. Connect one data cable to the RS-422 device.

2. Next, connect the other end of this cable to the front panel RS-422 terminal connector on the

AT-HDF30SR.

OPERATION:

AUDIO:

SERIAL DATA:

RS-422 SERIAL DATA:

CONNECTION DIAGRAM

RS-232 (2)

Stereo Audio

HDMI Source

HDMI Cable

AT-HDF30S

Fiber Cable

RS-232 (2)

Stereo Audio

AT-HDF30R

HDMI Cable

HDMI Display

RS-232 (2)

Stereo Audio

AT-DVIF30R

DVI Cable

DVI Monitor

... or

Stereo Audio

AT-RGBF30R

VGA or YPbPr

Display

RS-232 (2)

... or

SAFETY INFORMATION

Safeguards

To reduce the risk of electric shock, do not

expose this product to rain or moisture.

If the wall plug does not t into your local

power socket, hire an electrician to replace

your obsolete socket.

Do not modify the wall plug.

Doing so will void the warranty and safety

features.

This equipment should be installed near

the socket outlet and the device should

be easily accessible in case it requires

disconnection.

Precautions

FCC Regulations state that any

unauthorized changes or modications to

this equipment not expressly approved by

the manufacturer could void the

user’s authority to operate this

equipment.

Operate this product using only the

included external power supply. Use of

other power supplies could impair

performance, damage the product or cause

res.

In the event of an electrostatic discharge,

this device may automatically turn off. If this

occurs, unplug the device, and plug it back

in.

Protect and route power cords so they will

not be stepped on or pinched by anything

placed on or against them. Be especially

careful of plug-ins, or cord exit points from

this product.

Avoid excessive humidity, sudden

temperature changes or temperature

extremes.

Keep this product away from wet locations

such as bathtubs, sinks, laundries, wet

basements and swimming pools.

Use only accessories recommended by

ATLONA to avoid re, shock or other

hazards.

Unplug the product before cleaning. Use

a damp cloth for cleaning. Do not use

cleaning uid or aerosols, which could

enter the unit and cause damage, re or

electrical shock. Some substances may

also mar the nish of the product.

Never open or remove unit panels or make

any adjustments not described in this

manual. Attempting to do so could expose

you to dangerous electrical shock or other

hazards. It may also cause damage to your

AT-HDF30SR. Opening the product will void

the warranty.

Do not attempt to service the unit. Instead

disconnect it and contact your Authorized

ATLONA reseller or contact ATLONA

directly.

WARRANTY

1. LIMITED WARRANTY

Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the

accompanying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be

free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event

applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of

receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation

may not apply to Customer.

2. CUSTOMER REMEDIES

Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-

gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet

this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited

Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-

uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.

3. NO OTHER WARRANTIES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLI-

ERS DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED

TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH

REGARD TO THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES

CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JU-

RISDICTION.

4. NO LIABILITY FOR DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLO-

GIES OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITA-

TION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS

OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER

PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA

TECHNOLOGIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA

TECHNOLOGIES’ AND ITS SUPPLIERS’ ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT

SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JU-

RISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

ATLONA

2151 O’toole Ave, Ste D

San Jose CA 95131

Toll Free: 1-877-536-3976

International: 408-954-8782

FAX: 408-954-8792

Website: www.atlona.com

E-MAIL: [email protected]

6 7

ATLONA PRODUCT REGISTRATION

Thank you for purchasing this Atlona product — we hope you’ll enjoy it.

We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership

record if your product is lost or stolen and helps ensure you’ll receive notication of performance issues and rm-

ware updates.

At Atlona, we respect and protect your privacy and assure you that your registration information is completely

secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited

warranty rights.

To register go to www.atlona.com/registration

Table des matières

Autres manuels Atlona Extenseur

Atlona

Atlona AT-HDVS-150-TX-WP Manuel utilisateur

Atlona

Atlona AT-USB50-SR Manuel utilisateur

Atlona

Atlona AT-HD4-SI40SR Manuel utilisateur

Atlona

Atlona AT-HD4-V110SR Manuel utilisateur

Atlona

Atlona AT-VGA-RS300SRS Manuel utilisateur

Atlona

Atlona AT-HD4-V40SRS Manuel utilisateur

Atlona

Atlona AT-HDMI40SR Manuel utilisateur

Atlona

Atlona AT-DVITX-RSNET Manuel utilisateur

Atlona

Atlona AT-UHD-EX-70C-KIT Manuel utilisateur

Atlona

Atlona AT-VGA180AR Manuel utilisateur

Atlona

Atlona AT-DVI40SRS Manuel utilisateur

Atlona

Atlona AT-UHD-EX-70-2PS Series Manuel utilisateur

Atlona

Atlona AT-DVI4-100SR Manuel utilisateur

Atlona

Atlona AT-RGVF30S-IR Manuel utilisateur

Atlona

Atlona AT-DVI60SRS Manuel utilisateur

Atlona

Atlona AT-VGA100-SR Manuel utilisateur

Atlona

Atlona AT-VGA180AS Manuel utilisateur

Atlona

Atlona AT-HD-RG100SR Manuel utilisateur

Atlona

Atlona AT-UHD-EX-100CE-TX Manuel utilisateur

Atlona

Atlona AT-VGA-RS300SRS Manuel utilisateur

Atlona

Atlona AT-VBNC400SR Manuel utilisateur

Atlona

Atlona AT-2VGA300SL Manuel utilisateur

Atlona

Atlona AT-2VGA300SL Manuel utilisateur

Atlona

Atlona AT-2VGA300SL Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur

SECO-LARM

SECO-LARM ENFORCER EVT-PB1-V1TGQ Manuel utilisateur
