Atid AT870N Guide de référence

Guide for Customer

AT870N

ATID Co., Ltd

ATID is a registered trademark of ATID Co., Ltd.

AT870N is a registered trademark of ATID Co., Ltd. and of its wholly owned subsidiaries.

ATID Co., Ltd.

#1205, Byuksan/GyungIn Digital Valley II, #481-10,

Gasan-Dong, Gumchon-Gu, Seoul, Korea

Tel: +82-2-544-1436

Fax: +82-2-2113-0040

www.atid1.com

Disclaimer

No part of the contents of this documentation or the procedures described there in may be reproduced or

transmitted in any form or by any means without prior written permission of ATID Co., Ltd.. or its wholly owned subsidiaries ("ATID ").

Owners of ATID products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own internal business

purposes.

Purchaser shall not remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all notices appear on any

reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed versions by contacting ATID Customer Administration. Electronic versions may either be

downloadable from the ATID web site (www.atid1.com) or provided on appropriate media.

If you visit our web site and would like to make comments or suggestions about this or other ATID publications, please let us know via the “Contact ATID ” page.

Contents

Page Contents

Before using manual for AT870N

Chapter 1. Caution when using AT870N

1. How to use battery correctly

2. Caution when using AT870N

Chapter 2. Product composition

1. Product composition

2. Name of each part

3. Function of each part

22 16. LOCK

Chapter 3. Basic function

11 1. Switch On Backup Battery

12 2. Attaching and Detaching the battery

13 3. Charging battery

15 5. Checking Battery Gauge

16 6. Backup Battery

16 7. Battery replacement

17 8. Soft Reset

17 9. Hard Reset

18 10. Initializing System

19 11. Attaching Micro SD card

20 12. Attaching SIM Card

21 13. Shortcuts setting

21 14. Set up phone password

22 15. Owner information

Page Contents

Chapter 3. Basic function(continues)

23 17. Memory

23 18. Task Manager

24 19. Remove the program

20. GPS

25 21. Set screen brightness

25 22. Backlight ON/OFF set up

33. Data transfer

Chapter 4. Optional module

37 1. Using 1D or 2D barcode scanner

40 2. Barcode emulator setting

44 3. Barcode scanning

45 4. Wi Power On /O

45 5. Wi function On /O

46 6. How to connect AP (1)

47 7. How to connect AP (2)

23. Screen adjustment

26 24. Volume and sounds setting

27 25. Sounds and notication

26. Set up the Clock and Alarms

28 27. Wireless Manager

28 28. Using keypad

29. Inputting Data

30. Using <Fun> Button

29 31. Use of stylus

30 32. Connecting PDA to PC

Page Contents

Chapter 4. Optional module(continues)

48 8. Bluetooth connection and termination

49 9. Bluetooth Pairing

51 10. Bixolon SPP-R200 Printer Demo

11. How to use Phone

52 12. Dialing

53 13. Receiving Phone Call

53 14. Hang o Phone Call

54 15. Contact List

54 16. How to search a contact information

55 17. Add to contact list

56 18. How to use Text Message

56 19. Sending Message

57 20. Receiving Message

57 21. Replying Message

58 22. GPS demo application execution

59 23. Use of camera

60 24. HF13.56 demo application execution

60 25. Mifare tag recognition

61 26. ISO15693 tag recognition

61 27. SmartCard demo application execution

28. UHF 900Mhz demo application execution

Chapter 5. Appendix

66 1. Product specication

■

◆

●

Before using manual for AT870N

User guide inclusive of text, images, logos, product names is either the property of, or used with permission by ATID CO.LTD. The information may not be distributed,

modi ed, displayed, reproduced (in whole or in part) without the prior written permission of ATID CO.LTD.

There are some di erences between user guide and actual function of device.

User guide can be adjusted by ATID CO.LTD without consent of user discretionally.

User guide is written for users who want to use and maintain the AT870N. Please read and understand these instruction prior to operating this unit.

Safety information

Your safety is extremely important. Read and follow all warnings and cautions in this document before you handle and operate ATID equipment. If you do not follow

the safety warnings and cautions, you might be seriously injured, and the equipment and data also might be damaged.

WARNIING

A warning requires you must pay attention to the operating procedure practice, condition, and statement strictly, or might be injured seriously.

CAUTION

A caution alerts you that you must be observe strictly when you operating procedure, practicing, con guring, for preventing from damage and destruction of

equipment, and loss of data.

NOTICE

A notice provide you the information which you must needs while you using AT870N.

Chapter 1. Caution when using AT870N

•

Caution when using AT870N

Please aware of the manual contents in advance before you handle and operate your AT870N and other ATID Products.

How to use battery correctly

In case that you dropped the main body or battery in water, please do not put into the stove or heater for drying. Just keep it in natural drying or contact purchase

place.

Please note that the battery terminal doesn’t have to be contacted to metallic object.

If you do not use the battery for a long time, please keep it at room temperature after charging.

Operating time of battery can be shorter than usual in accordance with loss of battery and use time. In this case, please contact us.

You have to use provided adaptor when charging the device.

Turn o the device properly then detach or replace the battery.

Caution when using AT870N

separately.

If you habe a problem on product, do not try to repair or disassemble it by yourself, please contact our customer service center.

Please note that using the device in environmentof high temperature and humidity for long hours can make a malfunction of device.

•

User careless or products repair would damage the stored data. Manufacturer is not responsible for this damage, so please do back-up the important data

•

I the power immediately, then

please contact our customer service center.

If you have any other questions on use of device, please contact our customer service center.

Chapter 2. Product composition

Product Composition

Product composition

*Please contact our customer service in defect of product composition and need to be changed.

3. Standard battery

6. Hand strap

2. Power Adapter and AC cable

1. AT870N main body

4. USB sync cable

7. Stylus pen

AT870N is baseduponMicrosoft window Mobile 6.5. As the state of the artproduct,

it is equippedwith barcode scanner, RFID Tag reader, MSRcardreader, printer, smart cardreader, MODEM, Camera andso on anditcanbe appliedtoIndustry, Enterprise, Logistics and so on, can be used

Camera (option)

Camera ash

(option)

Cradle connector

Earphone jack Charger jack

Sync Cable

Connector

Phone receiver WLAN LED

(option) Internal HF

Charge LED

Touch Screen

Keypad

Reset button Microphone

UHF

Scan button (F7,F8)

Gun handle

1D/2D Scanner

(option)

Chapter 2. Product composition

Name of each part

Battery latch

Hand strap hole

Battery

Volume button

UHF Connecting

port

Function of each part

Chapter 2. Product composition

NAME FUNCTION

Enableyouto connecttoadaptorwhichprovidedfrom factory.Charger jack

Enableyouto connecttoPC orchargingthe battery whileusing cradle.

Cradle connector

Camera (option) Itis possible toimage captureandsave.

Earphone jack Enable youtoconnecttoearphone.

Enable youtoconnectandsenddatatoPC via USBsynccable.Sync cable connector

ChargerLED willbe Redwhenthe batteryis charging, or will be greenwhenitis charged completely.Charger LED

Enable youtoinputkey value (number,alphabets,symbol), or executingassignedprograms.Keypad

Displayrunning programs, andcouldexecute, use, and exitprograms viato touchthescreen.Touch screen

Enable youtoperformawarm Reset, Press<Power>buttonsimultaneously, Enable youtoperformahardResetReset button

Displays whetherthewirelessWLAN power supply

WLAN LED (option)

Laserbeamemittedthroughthis window. Please be carefulthe foreignsubstances andpreventing fromthedamage.

Warning! Do notlookatthe laserbeam directly.

1D/2D Scanner (option)

Internal HF HF13.56MhzEmbeddedmodulemountinglocation.

Enable youtoattacha handstrap orastylus forthe convenience of using, while need tousethe device foralong periodtime.Hand strap hole

Enable youtoconductcommunicationMicrophone

Enableyouto detachingandattachingthe mainbattery.Battery latch

Enabletosupply the powerto the product.Battery

Itis possible toscan barcode orRFIDtagScan button (F7, F8)

Enable youtoinstall aUHF900Mhztag readermodule.UHF Connecting port
