Atecpool AMHP80 Manuel utilisateur

INSTALLATION AND USER MANUAL

Atecpool MegaHigh Inverter

Heat Pump

AMHP80

AMHP170

atecpool.com

MODEL

Model AMHP80 AMHP170

Heating Capacity at Air 26°C, Water 26°C, Humidity 80%

Heating Capacity kW 80~17.5 175~36.3

Power Input kW 10.65~2.86 20.97~5.85

COP 16.1~6.1 16.0~6.2

Heating Capacity at Air 15°C, Water 26°C, Humidity 70%

Heating Capacity kW 60~13.8 135~28.3

Power Input kW 12.21~1.65 27.55~3.32

COP 8.4~4.91 8.5~4.9

Cooling Capacity at Air 43°C, Water 26°C

Cooling Capacity kW 42~15 96~59.4

Power Input kW 10.24~2.94 22.32~11.2

EER 5.1~4.1 5.3~4.3

Rated Power Input kW 13 28

Rated Current A 20 45

Power Supply V/Ph/Hz

Refrigerant R410A

Compressor Type Mitsubishi DC inverter

Heat Exchanger Titanium

Expansion Valve Electronic EEV

Air Flow Direction Vertical

Fan Quantity 2 2

Fan Power Input W 200x2 1300x2

Fan Rotate Speed rpm 850 850

cfm 8000 25000

Water Flow Volume m /h 25 45

Net Dimensions(LxWxH) mm 1750x840x1750 2170x1150x2130

Operating Air Temperature °C 0°C~50°C 0°C~50°C

Noise 1m dB(A) ≤60 ≤65

Net Weight kg 370 810

Water Connection mm 63 110

AMHP80

2 .2 T he dime ns ions for S wimming P ool H ea t P ump Unit

2.SPECIFICATION

Model:

unit mm

Airow direc tion

11 0

11 50

21 30

43 4

17 4

45 4

AMHP170

3.1 I ns talla tion illus tra tion

3.INSTALLATION AND CONNECTION

Ins talla tion items :

The factory only provides the main unit and the water unit; the other items in the illustration

are necessary spare parts for the water system ,that provided by users or the installer .

Attention:

Please follow these steps when using for the rst time

1.Open valve and charge water.

2.Make sure that the pump and the water-in pipe have been lled with water.

3.Close the valve and start the unit.

ATTN: It is necessary that the water-in pipe is higher than the pool surface.

The schematic diagram is for reference only . Please check the water inlet/outlet label on the

heat pump while plumbing installation.

Ch lorinator ce ll

W ater o utlet

P ool

Val ve

Water s upply

Water in let Water pump

S an d  lter

(o r other type  lter)
