ATECH CRM 250S Manuel utilisateur
1
TECHNICAL FEATURES
kg
kg
CRM
250S
230V 1P
200 Hz 1100W*3 6-8 BAR
10
Lt/dak.
Lt/min.
12000
dev/dak
RPM
x1,x2 = 650,350 mm
y1,y2 = 180,230 mm
z1,z2= 170,150 mm
W = 110
L = 110
H = 180
370 380
MODEL TYPE
MODEL
SERIAL NO
SERI NO
PROD.DATE
ÜRETİM TAR.
TOTAL POWER
RATED VOLTAGE
NOMİNAL GERİLİM
230V AC 1P NPE
RATED CURRENT
NOMINAL AKIM
WEIGHT
AIR PRESSURE
AIR CONSUMP.
10A
380KG.
6
-
8 BAR
10 Lt/min
IDLING REV.
DEVİR SAYISI 12000 x3
RPM
CRM 250S
2
DIMENSIONS FIGURE 1
PARTS LIST FIGURE 2
RESİM-FIGURE-РИСУНОК 1
3
FIGURE 4
FIGURE 3
4
FIGURE 5
5
SPARE PART LIST
PART NO PICTURE STOCK CODE PART NAME
1 3UA810030-0017 TEMPLATE LEFT PISTON MOUNTING
2 3UA810030-0016 TEMPLATE RIGHT PISTON MOUNTING
3 3UA810030-0015 LEFT SUPPORT MOUNTING
4 3UA810030-0014 RIGHT SUPPORT MOUNTING
5 3UA810030-0011 KN 152 SUPPORT- SEMI/COMPLETE
6 3UA280030-0011 CLAMP MOUNTING
7 3UA040030-0008*8
3UA040030-0007*2
PIPE HANDLE 3 M8*32
8 3UA040030-0002 PIPE HANDLE 1 (M10*50)
9 2TU011441-0975 SPRAY MIST CONNECTION PLATE
10 2TU012210-1258 FIXING PLATE
11 2TU012610-0044 CLAMP PISTON CONNECTION
12 2TU011210-1007 TRACER PIN
13 2TU011110-1345 JOYSTICK FIXING BOLT
14 1PN010000-0012 SPRAY VALVE
6
15 1EL090000-0500 JOYSTICK ARM
16 1EL070004-0014 MOTOR 1.1Kw 12,000
17 1SK050000-0069 Ø10.0 L100- SINGLE HEAD
18 1SK050000-0068 Ø5.0 L100- SINGLE HEAD
19 1YY030000-0016 TOP HEAD GAS SPRING 1
20 1YY030000-0017 BOTTOM HEAD GAS SPRING 2
21 1YY030000-0015 FRONT GAS SPRING 3
22 1YY030000-0014 REAR GAS SPRING 3
23 1SR020000-0007 BALL JOINT
24 1SR020000-0006 ROD EYE
25 2TU013210-0205 BACK GAUGE
26 2TU013210-0211 UPPER CLAMP PAD
27 1PL010000-0033 FRONT CLAMP TIP
7
ENGLISH
CONTENTS
1. General information
1.1. Introduction
1.2. Service Information
2. Safety
2.1. Safety Symbols and Their Meanings
2.2. Accidents Prevention
2.3. General Safety Information
3. Machine’s Description
4. Transport of the Machine
5. Installation of the Machine
5.1. Preparation
5.2. Connecting to Power Source
6. Machine’s Safety Information
7. Operation
7.1 Preparation
7.2 Operation
8. Maintenance, Service and Repair
8.1 Maintenance
8.2 Changing the cutting tool
8.3 Adjust the air pressure (pneumatic systems)
9. Warranty conditions
10. Mounting Manual
10.1 Installation of the Dampers
10.2 Installation of the Motion Lever
10.3 Installation of the Conveyor
8
1. GENERAL INFORMATION
1.1. Introduction
The user’s manual given by the manufacturer contains necessary information about the machine parts. Each machine
operator should read these instructions carefully, and the machine should be operated after fully understanding them.
Safe and efficient use of the machine for long term depends on understanding and following the instructions contained in
this manual. The technical drawings and details contained in this manual constitute a guide for the operator.
1.2. Service Information
In case of any technical problem please contact your nearest ATech dealer, or ATech head office through the following
phone, fax or e-mail address.
Technical labels with the model description of the machine are fixed onto the front side of each machine.
The machine’s serial number and manufacturing year are stipulated on the technical label.
Average life usage of production is 10 years. If you have any further failure and complaint, please inform to our
below mentioned technical service by verbal or written
AUTHORIZED DISTRIBUTOR
Atech Machine, Inc., 8539 Ziggy Lane, Gaithersburg, MD 20877 - USA
Tel +1-240-505-1967
Fax +1-350-6627
E-mail [email protected]
Web www.ATechMachinery.com
To minimize the documentation, It is necessary to mention below details at the agreements signed with suppliers and dealers
of the purchased machines
Machine model Voltage and frequency
Machine’s serial number Date of purchase
Description of the machine fault Name of dealer where machine was purchased
Average daily operation period
9
2. SAFETY
2.1. Safety Symbols and Their Meanings
Read the user guide Ensure safe working position, always keep your
balance.
Wear ear protectors Elektrical excitation
Wear safety goggles Don’t place your hands between parts in motion..
If the power cable should be damaged during
operation, don't touch and unplug it. Never
use damaged power cables.
High temperature warning
During saw blade change operations, use
protective gloves
Keep your fingers clear of the movable parts of the
glide arm.
The above symbol DANGER WARNING,
warns you against specific dangers, and you
have definitely to read them..
The IMPORTANT symbol above is one telling to
apply special care and to be careful at carrying out
the specified operation
2.2. Accidents Prevention
2.2.1 Our machines are manufactured in accordance with CE safety directives, which cover national and international
safety directives.
2.2.2 It is the task of the employer to warn his staff against accident risks, to train them on prevention of accidents, to
provide for necessary safety equipment and devices for the operator’s safety.
2.2.3 It is the task of the employer to warn his staff against accident risks, to train them on prevention of accidents, to
provide for necessary safety equipment and devices for the operator’s safety.
2.2.4 Machine should be operated only by staff members, who have read and understood the contents of this manual.
2.2.5 All directives, recommendations and general safety rules contained in this manual have to be observed fully. The
machine cannot be operated in any way for purposes other than those described herein. Otherwise, the
manufacturer shall not be deemed responsible for any damages or injuries. And such circumstances would lead
to the termination of the warranty
2.3. General Safety Information
2.3.1 The power cable should be led in such a way that nobody can step on it or nothing can be placed on it. Special
care has to be taken regarding the inlet and outlet sockets
2.3.2 Don’t overload machines for drilling and cutting. Your machine will operate more safely with power supply in
accordance with the stipulated values.
2.3.3 Use correct illumination for the safety of the operator. (ISO 8995-89 Standard The lighting of indoor work system)
2.3.4 Do not leave any things on the machine.
2.3.5 Don’t use any materials other than those recommended by the manufacturer for cutting operations on the
machine.
2.3.6 Ensure that the work piece is clamped appropriately by the machine's clamp or vice
10
2.3.7 Ensure safe working position, always keep your balance.
2.3.8 Keep your machine always clean for safe operation. Follow the instructions at maintenance and replacement of
accessories. Check the plug and cable regularly. If damaged, let it replace by a qualified electrician. Keep handles
and grips free of any oil and grease.
2.3.9 Unplug first, before conducting and maintenance works.
2.3.10 Ensure that any keys or adjustment tools have been removed before operating the machine..
2.3.11 If you are required to operate the machine outside, use only appropriate extension cables.
2.3.12 Repairs should be carried out by qualified technicians only. Otherwise, accidents may occur.
2.3.13 Before starting a new operation, check the appropriate function of protective devices and tools, ensure that they
work properly. All conditions have to be fulfilled in order to ensure proper operation of your machine. Damaged
protective parts and equipment have to be replaced or repaired properly (by the manufacturer or dealer).
2.3.14 Don’t use machines with improper functioning buttons and switches
2.3.15 Don’t keep flammable, combustive liquids and materials next to the machine and electric connections.
3. MACHINE’S DESCRIPTION
Copy router machines designed to open lock, handle, hinge and window fastening slots onto PVC and Aluminum profiles.
Channels in different dimensions can be opened independently from copying.
Pneumatic clamps.
Pneumatic template pins.
STANDARD ACCESSORIES
OPTIONAL ACCESSORIES
Cutter Ø 5 mm
Mill tip (Ø5
mm)
Cutter
Ø10
mm x 2 pc.
Mill tip (Ø
10mm)
Reference stops (Right - Left Conveyor) Collet Ø8
User’s Instruction Manual
Collet Ø10
Service Tool (22 mm)
Special templates
Collet wrench key
Cooling system
Copying pattern
Air gun
4. TRANSPORT OF THE MACHINE
4.1. The transport should be done by qualified personnel only.
4.2. The machine should be transported by lifting with proper equipment (not touching the ground during the transport).
4.3. Unless customer requests the contrary, the machine will be delivered with wooden packaging.
4.4. Movable parts on the machine should be fixed before carrying out the transport.
4.5. The machine size and weight measurements, given the technical specification sheet.
