AXE2D+EC64 User Manual
ATCOM®Digital Card AXE2D
User Manual
Version: 2.0
2013-06-03
AXE2D User Manual
Release note
Version Changed note Editor Date
1.0 First Release Robert 2011-01-20
2.0 Release the User manual Deniel 2013-06-03
AX1D User Manual
Content
Chapter 1 The Introduction of AXE2D...............................................................................................1
Chapter 2 Hardware Introduction........................................................................................................3
Chapter 3 Test Environment................................................................................................................7
Chapter 4 Software Installation...........................................................................................................8
Chapter 5 Software Configuration.................................................................................................... 10
Chapter 6 Reference.......................................................................................................................... 13
AXE2D User Manual
Contact ATCOM
The Introduction of ATCOM
ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping
innovating with customer’s needs oriented , working with partners to establish a total solution for
SMB VoIP with IP phone , IP PBX and Asterisk cards.
With over 10 years’ experience of R&D, manufacturing and service in network and VoIP filed;
mission of creating the biggest value for IP terminals, we commit ourselves in supplying the
competitive IP phone and other terminals for IP PBX, softswitch, IMS, NGN providers and
carriers; supplying the competitive total VoIP solution for SMB market. We keep improving the
customer’s experience and creating the bigger value with our reliable products. Until now , our
VoIP products has been sold to over 60 countries and used by millions of end users.
Contact sales:
Address District C, east of 2nd floor, #3, Crown industry buildings, Chegongmiao
Industry area, Futian district, Shenzhen, China
Tel +(86)755-23487618
Fax +(86)755-23485319
E-mail sales@atcomemail.com
Contact Technical Support:
Tel +(86)755-23481119
E-mail Support@atcomemail.com
Website address: http://www.atcom.cn/
Download Center: http://www.atcom.cn/download.html
AXE2D User Manual
1
Chapter 1 The Introduction of AXE2D
Overview of the AXE2D
AXE2D Asterisk card is the telephony PCI card which supports four ISDN PRI E1/T1/J1 ports,
optional with teleco-grade hardware echo cancellation. Using AXE2D digital PRI card, open
source Asterisk PBX and stand alone PC, users can create their IP PBX telephony solution include
all the sophisticated features of traditional PBX, and extend features such as voicemail in IP PBX.
Features
AXE2D: Dual ISDN PRI E1/T1/J1 ports
Support original Dahdi, Zaptel(No patch)
Support Asterisk, Freeswitch, Yate
Support Elastix, Trixbox, AsteriskNOW, PBX in a Flash
100% compatible with all features of Asterisk PBX
32-bit bus master DMA data exchanges across PCI interface at 132 Mbytes/sec for minimum host
processor intervention
Supports standard telephony and data protocols(Including PRI, CAS, CCS for voice and PPP,
HDLC, Cisco HDLC and Frame Relay for data modes)
Supports chan_ss7 and Openr2
Optional hardware echo cancellation
Select the hardware echo cancellation direction
Applications
ISDN PRI IP PBX
ISDN least cost router
Calling Card Platforms
IVR system
Call Center
Traditional Calls/VoIP Calls Conference
VoIP Gateway
Callback Service
Optional DSP Hardware Echo Cancellation Module
G.168–2002 echo cancellation in hardware
1024 taps/128 ms tail per channel on all channel densities
DTMF decoding and tone recognition
Voice quality enhancement: music protection, acoustic echo control, and adaptive noise reduction
Does not increase the physical size of the card, and no additional slot is required
AXE2D User Manual
2
Voice Modes
Pri CPE and PRI NET:
EuroISDN
4ESS(AT&T)
5ESS(Lucent)
DMS100
Hardware Requirement
1.6-Ghz Pentium IV
512 MB RAM
3.3V or 5V PCI 2.2 slot
PCI Card Dimension
131.5mm (Length)*94mm (height)
Operating System
Linux (all versions, releases and distributions from 1.0 up)
AXE2D User Manual
3
Chapter 2 Hardware Introduction
AXE2D
The Front and Rear View of EC128
LED Red: If the driver of the card is loaded correctly and the /etc/dahdi/system.conf file is
configured correctly, the LED Red of the four ports will be red clearly.
LED Green: If the PRI line is connected correctly, and it synchronizes to the other end
successfully, then the LED Green will be green clearly.
If the PRI line is connected correctly, and it is synchronizing to the other end, then both of the
AXE2D User Manual
4
LED Green and LED Red will be on clearly.
SW1: It is used for selecting E1, T1, J1 mode, by default ATCOM will set it up according to your
requirement before shipping out. Customer can set up E1, T1/J1 like the following:
For E1 Mode For T1 and J1 Mode
SW2: It is used when you have more than one PRI card in your server, if you have two cards in
your server, then turn it to 0 in one card, and turn it to 1 in the other card; if you have four cards in
your server, then turn it to 0,1,2,3 respectively.
SW3: It is used to select the hardware echo cancelation direction, by default we set it up to delete
the echo for local side, if customers want to delete the echo for the far end side, please turn the
buttons to on state.
AXE2D User Manual
5
Delete the echo for local side Delete the echo for the far end side
J17, J18: They are used to connect to other cards, when you have several cards in your server.
Using clock line to connect each other, all of the cards work in one server can synchronize
accurately. If customer have PRI card and analog card in one server, the analog card can
synchronize accurately with telecom in this way, and it is useful for fax.
J18 and J17
JP5: It is used for selecting the PCI power feeding for the card, by default we choose the 3.3v for
the card, customer do not need to reset the jumper; the card can also choose 5.0v for power feedin
g in the case that the 3.3v in the motherboard of PC is not enough for the card, but this
phenomenon happens rarely.
For Choosing 3.3v Power For Choosing 5.0v Power
AXE2D User Manual
6
JP4: It is used for selecting the power feeding for the hardware echo cancellation module, by
default we choose the 3.3v; the module can also choose 5.0v for power feeding in the case that the
3.3v in the motherboard of PC is not enough for the module, but this phenomenon happens rarely.
For the latest version, the module does not need this jumper.
For Selecting 3.3v Power
For Selecting 5.0v Power
