User's manual

5.8 GHz Expansion

Handset EP590-3

For use with AT&T model

EP5995

Congratulations on your purchase

of this AT&T product.

Before using this telephone system, you must

read Important safety information on

pages 19-23 of this manual.

NEED HELP?

Our representatives are here

to help you with any questions concerning

the operation of this product, available

accessories, or any other related issues.

Call toll free

1 (800) 222-3111

In Canada, call

1 (866) 288-4268

or visit our website at

www.telephones.att.com

Model no.: AT&T EP590-3

Product name: 5.8 GHz cordless telephone

Serial no.: SN:

(found at the bottom of the charger)

Purchase date:

Place of purchase:

Depending on your service subscription, you may see the caller’s number, or the

caller’s name and number. This product can provide information only if both

you and the caller are in areas offering caller ID service, and if both telephone

companies use compatible equipment. The time and date are sent by the service

provider along with the call information.

Information about caller ID with call waiting

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones.

This product has a caller ID with call waiting feature that

works with service from your local telephone service

provider.

Caller ID with call waiting lets you see the name of the

caller before answering the phone, even when you’re on

another call.

You may need to change your telephone service

to use this feature. Contact your telephone service

provider if:

• You have both caller ID and call waiting, but as separate

services (you may need combined service).

• You have only caller ID service, or only call waiting

service.

• You don’t subscribe to any caller ID or call waiting

services.

You can use this product with regular caller ID service, or you

can use this product’s other features without subscribing to

either caller ID or combined caller ID with call waiting service.

There are fees for caller ID services, and they may not be

available in all areas.

IMPORTANT

You must charge the

battery pack before use.

See page 4

for easy instructions.

Table of contents

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, call 1 (866) 288-4268.

Quick reference guide........................ 1

Before you begin.................................. 3

Parts checklist ...................................... 3

Battery installation & charging ......... 4

Adding new handsets.......................... 5

To replace a handset........................... 7

Belt clip & optional headset.............. 9

In case of difficulty.............................10

Important safety information..........19

FCC Part 68 and ACTA ...................24

FCC Part 15 .......................................26

Limited warranty..............................28

STOP!

/ANSWERING SYSTEM

Press to show the number of old

and new messages recorded on the

answering system.

/SPEAKER

Press to activate the handset

speakerphone.

Press again to resume normal handset

use.

For complete instructions, please refer to the manual

provided with AT&T EP5995 cordless telephone/

speakerphone answering system. If your manual for model

EP5995 has been misplaced, you may download it from

www.telephones.att.com.

CENTER

LEFT RIGHT

DOWN

Quick reference guide

FLASH CANCEL

SOFTKEYS

Press a softkey to select a menu

item displayed just above the key.

/PHONE/FLASH

Press to make and answer a call.

During a call, press to receive an

incoming call, if call waiting is activated.

/OFF/CANCEL

During a call, press to hang up.

While using menus, press to

cancel an operation, back up to

the previous menu, or exit the

menu display.

NavKey

Press the CENTER NavKey

to display menus.

Press the UP or DOWN NavKey

or to navigate through

menus. See page 2 in this

user’s manual for menu screen

examples.

Press the CENTER NavKey

to select highlighted menu item.

STATUS LIGHT

Blinks to indicate there are new

voicemail and/or new memo.

Pictures

Main menu

Pictures

SET

Pictures

Animations

SET

Quick reference guide

Directory

Call Log

SAVE DELETE

Alice

0-888-883-2445

Jan 9 10:39AM

Intercom

BASE

Global Page

Settings

Set Time

Edit Handset Name

Show Handset Name

Language

Contrast

Sounds

Ringer Volume

Ringer Melody

Record Ringer

Keypad Tone

Ringer Volume

Sounds

Messages 7

STOP DELETE

Memo

Jan 10 10:51AM

Duration 0:11

REPEAT SKIP

Messages

PLAY DELETE

0 New Messages

10 Old Messages

Messages

Before you begin

This cordless telephone

operates with the maximum

power allowed by the

Federal Communications

Commission (FCC). Even so,

the handset and telephone

base can communicate over

only a certain distance

— which can vary with the

locations of the telephone

base and handset, the

weather, and the layout of

your home or office.

If you receive a call while

you are out of range, the

handset might not ring — or

if it does ring, the call might

not connect well when you

press /PHONE/FLASH. Move

closer to the telephone

base, then press /PHONE/

FLASH to answer the call.

If the handset is out of

range during a phone

conversation, there might

be interference. To improve

reception, move it closer to

the telephone base.

When you move out of

range without pressing

/OFF/CANCEL, the telephone

will be disconnected after

five seconds.

Parts checklist

Remember to save your sales receipt and original packaging

in case you ever need to ship your telephone for warranty

service. Check to make sure the telephone package

includes the following:

Charger

Telephone

handset Belt clip

Battery pack

FLASH CANCEL

Power

adapter

Battery compartment

cover

FLASH CANCEL

Place handset in charger to

charge for at least 16 hours

before first use.

CHARGE light remains on

while charging.

Low battery indicator

Return handset to telephone base or charger

to recharge when this symbol flashes.

(Handset will beep when battery is low.)

Plug power cord into jack

on underside of charger,

then plug power adapter

into electrical outlet.

Caution: Use only

supplied rechargeable

battery or AT&T

replacement battery

model 103 (SKU 00249.

Part Number 89-0429-

00-00).

Battery installation & charging

After installation, place the handset in the charger or the

telephone base and allow the battery pack to charge for

at least 16 hours before use. You can keep the battery

pack charged by returning the handset to the charger or

the telephone base after use. When battery power is fully

depleted, a full recharge takes about 16 hours.

Insert supplied bat-

tery as indicated.

The top edge (with

contacts and tab)

needs to be inserted

first, then push down

on the lower portion.

Replace compartment cover.

12:00AM

REDIAL CALLER ID

HANDSET 2

Low Battery

NOTE: When fully

charged, the battery

in the handset can provide

5 hours of talk time or 3

days of standby time (when

idle).

Adding new handsets

The AT&T EP5995 cordless telephone/speakerphone

answering system can accommodate up to eight cordless

handsets. You can add new handset (AT&T model EP590-3,

purchased separately) anytime. Up to three handsets can be

on a call at the same time.

The handset provided with your telephone

system is automatically registered as

Handset 1. Additional handsets will be

assigned in numerical order (2, 3, 4, etc.)

when they are registered.

Before using a separately purchased

handset, it must be registered with the

telephone base. Put the new handset on

the telephone base or a handset charger.

Press SELECT/MENU at the telephone base,

followed by ^DIR once and the screen will

show Register Handset. Press SELECT/MENU

on the telephone base to confirm.

When the handset has synchronized with

the telephone base, the screen on the

handset will show Registration in progress.

When the handset is successfully registered

to the telephone base, the telephone base

will generate a confirmation tone.The

newly registered handset will be assigned

the lowest extension number which has not

previously been assigned to another system

handset (1-8).

The new handset will sound a confirmation

tone.

Press the MENU key

on the base. Find

'Register Handset' in

menu. Press SELECT.

12:00AM

Registration

in progress...

12:00AM

FLASH CANCEL

Handset 1

FLASH CANCEL

Handset 2

FLASH CANCEL

Handset 3Telephone base

FLASH CANCEL

Handset 6

FLASH CANCEL

Handset 7

FLASH CANCEL

Handset 8

FLASH CANCEL

Handset 4

FLASH CANCEL

Handset 5

NOTE: The maximum number of handsets in use at any time is three, and

the possible combinations include:

•Three handsets and the base on an external call.

• Two handsets and the base on an external call, and one handset accessing

the answering system.

•One handset and the base are on an external call, and two handsets are on

intercom.

Adding new handsets

If the screen on the telephone base shows Registration

failed, an error tone will sound. Try again.

NOTE: The new handset will be assigned the next available handset number.

A maximum of eight handsets can be registered to each telephone base.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels AT&T Combiné

AT&T

AT&T TL90071 Manuel utilisateur

AT&T

AT&T BL103-0K Manuel utilisateur

AT&T

AT&T AT3101 Manuel utilisateur

AT&T

AT&T GL2113-0 Manuel utilisateur

AT&T

AT&T SB67108 - AT&T Manuel utilisateur

AT&T

AT&T E580-1 Manuel utilisateur

AT&T

AT&T CLP99573 Manuel utilisateur

AT&T

AT&T 5865 Manuel utilisateur

AT&T

AT&T TL76008 Manuel utilisateur

AT&T

AT&T 2300 Manuel utilisateur

AT&T

AT&T E597-1 Manuel utilisateur

AT&T

AT&T G1AR Manuel d'instructions

AT&T

AT&T TL90073 Manuel utilisateur

AT&T

AT&T CL82219 Manuel utilisateur

AT&T

AT&T E2662B Manuel utilisateur

AT&T

AT&T BL102-2S Manuel utilisateur

AT&T

AT&T CL82107 Manuel utilisateur

AT&T

AT&T CL80121 Manuel utilisateur

AT&T

AT&T CL80100 Manuel utilisateur

AT&T

AT&T TL77008 Manuel utilisateur

AT&T

AT&T DLP70110 Manuel utilisateur

AT&T

AT&T TL90071 Manuel utilisateur

AT&T

AT&T SB8740 Manuel utilisateur

AT&T

AT&T CRL30102 Manuel utilisateur

Manuels Combiné populaires d'autres marques

Swissvoice

Swissvoice ePure HD Manuel utilisateur

Philips

Philips TD6736/BH051P Manuel utilisateur

ASCOM

ASCOM I62 - Manuel utilisateur

LG-Ericsson

LG-Ericsson LIP-9010 Manuel utilisateur

GE 1583 Manuel utilisateur

iiNet

iiNet Handset Manuel utilisateur

ASCOM

ASCOM 9p23 Manuel utilisateur

AirCell

AirCell ST 3100 Manuel utilisateur

Eaton

Eaton HHIR-LCD-PROG Instructions de montage

Mitel

Mitel 112 Manuel utilisateur

SBC

SBC SBC-381H Manuel utilisateur

Mitel

Mitel 5602 Manuel utilisateur

ASCOM

ASCOM d81 Messenger Instructions d'installation

SpectraLink

SpectraLink 7522 Manuel utilisateur

Avaya

Avaya L100 Series Comment utiliser

ooma

ooma HD2 Handset Manuel utilisateur

Yealink

Yealink IPW56 Manuel utilisateur

Sony

Sony SBH52 Manuel utilisateur
