Asus AGP-V3000 Manuel utilisateur

3DexPlorer®3000

AGP-V3000 Graphics Card

USER’S MANUAL

Hardware & Video Drivers

ASUS AGP-V3000 User’s Manual

USER’S NOTICE

Product Name: ASUS AGP-V3000

Manual Revision: 1.01

Release Date: August 1997

No part of this manual, including the products and softwares described in it, may be repro-

duced, transmitted, transcribed, stored in a retrieval system, or translated into any language

in any form or by any means, except documentation kept by the purchaser for backup pur-

poses, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-

TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-

TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF

PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-

NESS AND THE LIKE), EVEN IF ASUS HAS BEENADVISED OF THE POSSIBILITY

OF SUCH DAMAGESARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL

OR PRODUCT.

Products and corporate names appearing in this manual may or may not be registered trade-

marks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.

• IBM and OS/2 are registered trademarks of International Business Machines.

• Symbios is a registered trademark of Symbios Logic Corporation.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Sound Blaster AWE32 and SB16 are trademarks of Creative Technology Ltd.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

The product name and revision number are both printed on the board itself. Manual revisions

are released for each board design represented by the digit before and after the period of the

manual revision number. Manual updates are represented by the third digit in the manual

revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contactASUS

at http://www.asus.com.tw or through any of the means indicated on the following page.

SPECIFICATIONSAND INFORMATION CONTAINED IN THIS MANUALARE FUR-

NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT

ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-

MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBLITY OR LIABILITY FOR

ANYERRORS ORINACCURACIESTHATMAYAPPEARINTHIS MANUAL,INCLUD-

ING THE PRODUCTS AND SOFTWARES DESCRIBED IN IT.

ASUS AGP-V3000 User’s Manual 3

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC.

Marketing Info

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112, ROC

Telephone: +886-2-894-3447

Fax: +886-2-894-3449

Email: [email protected]

Technical Support

Fax: +886-2-895-9254

BBS: +886-2-896-4667

Email: [email protected]

WWW: www.asus.com.tw

Gopher: gopher.asus.com.tw

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL

Marketing Info

Address: 721 Charcot Avenue, San Jose, CA 95131, USA

Telephone: +1-408-474-0567

Fax: +1-408-474-0568

Email: [email protected]

Technical Support

BBS: +1-408-474-0569

Email: [email protected]

WWW: www.asus.com

ASUS COMPUTER GmbH

Marketing Info

Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany

Telephone: 49-2102-445011

Fax: 49-2102-442066

Email: [email protected]

Technical Support

BBS: 49-2102-448690

Email: [email protected]

Hotline: 49-2102-499712

ASUS AGP-V3000 User’s Manual

CONTENTS

I. Introduction .....................................................................................7

Item Checklist ..................................................................................7

Key Benefits ....................................................................................7

Features ............................................................................................7

II. Hardware Installation ...................................................................8

ASUS AGP-V3000 Layout ..............................................................8

ASUS AGP-V3000 with VIP Module Example ..............................8

Installation Procedures .............................................................10

New Systems ......................................................................10

Systems with Existing VGA Card ......................................10

III. Windows 95.................................................................................11

Operating System Requirements ................................................... 11

Windows 95 and Windows 95 OSR2.0/2.1..............................11

Installation in Windows Memphis Beta1/Beta2.......................11

1. Installing for an Installed ASUS AGP-V3000 ....................12

1.1 Windows 95 .................................................................12

1.2 Win95 OSR 2.0/2.1......................................................12

2. Replacing an Existing VGACard .......................................14

3. Video Driver Uninstallation ................................................15

3.1 Using the Autorun Screen............................................15

3.2 Using the Windows 95 Control Panel .........................15

4. DirectX 5 Installation ..........................................................16

ASUS AGP-V3000 User’s Manual 5

CONTENTS

IV. Microsoft Windows NT ..............................................................17

Installation Procedures .......................................................17

V. Windows 3.x ..................................................................................18

1.1. Installation Procedures in DOS ...................................18

1.2. Installation Procedures in Windows 3.x ......................19

1.3. Installation of Video for Windows...............................20

VI. Display Information ...................................................................21

Resolution Table ............................................................................21

4MB Video Memory ................................................................21

VIP Connectors ..............................................................................22

VIP Module Mechanical Specification ....................................22

VII. Hardware Information.............................................................22

VIII. Troubleshooting.......................................................................24

Description .........................................................................24

Recommended Action ........................................................24

ASUS AGP-V3000 User’s Manual

FCC & DOC COMPLIANCE

FederalCommunications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer’s instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the inter-

ference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! The use of shielded cables for connection of the monitor to the

graphics card is required to assure compliance with FCC regulations. Changes

or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

CanadianDepartment of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the Cana-

dian Department of Communications.

7ASUS AGP-V3000 User’s Manual

I. Introduction

Checklist/Features

Thank you for purchasing the ASUS AGP-V3000 Graphics & Video Accelerator.

With the SGS-THOMSON RIVA 128™ built in, the ASUS AGP-V3000 provides

you with fast acceleration in both 2D/3D graphics and high quality scalable video

playback, which can fully support 3D Gaming and Multimedia Applications.

Item Checklist

þASUS AGP-V3000

þThis User’s Manual

þASUS Driver & Utility CD

Key Benefits

• Supports professional graphics design, gaming, learning, and business applications

• Flicker free, high refresh rates reduce eye strain

• Powerful 3D rendering

• Crisp, realistic images

• Striking cinema-quality video

Features

• Built-in SGS-THOMSON RIVA 128™ 128-bit 3D Multimedia Accelerator

• User-friendly Installation for Windows 95 and Windows 3.x.

• Built-inVIPBus Connectors forTVTuner,Video Capture, MPEG-1, and MPEG-II

• AccelerationforWindows 95APIs, including Direct3Dand DirectDraw(+VPE)

• Acceleration for Windows NT APIs, including Direct3D, and DirectDraw

• Massive array of floating point Geometry Processing Units

• 128-bit 2D/GUI/DirectDraw Acceleration

• Video Acceleration (including acceleration for MPEG-I, MPEG-II, and Indeo)

• X and Y up and down video scaling

• 206MHz Palette-DAC

• AGP 1.0 Interface

• 4MB128-bit100MHz SGRAM framebufferinterfacewith1.6GB/sbusbandwidth

• Excellent performance at high resolutions and color depths

8 ASUSAGP-V3000 User’s Manual

II. Hardware Installation

II. Installation

Layout

ASUS AGP-V3000 Layout

4MB SGRAM Memory

Video

Output

Connector

VIP Connector A

VIP Connector B

VGA BIOS

SGS-THOMSON RIVA

128™ 3D Chipset

ASUS AGP-V3000 with VIP Module Example

VIP Module

(Solder Side) AGP-V3000

(Component Side)

9ASUS AGP-V3000 User’s Manual

II. Hardware Installation

II. Installation

Procedures

This section tells you how to install theASUSAGP-V3000 graphics card in your PC

computer.

NOTE:TheASUSAGP-V3000 graphics card can only be installed in motherboards

with an AGP slot.

WARNING! Computer boards and components contain very delicate Integrated

Circuit (IC) chips. To protect the computer board and other components against

damage from static electricity, you must follow some precautions.

1. Make sure that you unplug your power supply when adding or removing

expansion cards or other system components. Failure to do so may cause

severe damage to both your motherboard and expansion cards.

2. Keep all components such as the host adapter in its antistatic bag until you

are ready to install it.

3. Use a grounded wrist strap before handling computer components. If you do

not have one, touch both of your hands to a safely grounded object or to a

metal object, such as the power supply case. Hold components by the edges

and try not to touch the IC chips, leads, or circuitry.

4. Place components onagrounded antistatic padoron the bagthatcame with the

component whenever the components are separated from the system.

10 ASUSAGP-V3000 User’s Manual

Installation Procedures

New Systems

1. Unplug all electrical cords on your computer.

2. Remove the system unit cover.

3. Locate the AGP bus expansion slot. Make sure this slot is unobstructed.

4. Remove the corresponding expansion slot cover from the computer chassis.

5. Ground yourself to an antistatic mat or other grounded source (see WARNING!).

6. Pick up the board (still in its sleeve) by grasping the edge bracket with one hand

and then remove the plastic sleeve.

7. Position the card directly over the AGP slot and insert one end of the board in

the slot first. Firmly but gently press the bus connector on the bottom of the card

down into the slot. Be sure the metal contacts on the bottom of the host adapter

are securely seated in the slot.

8. Anchor the board’s mounting bracket to the computer chassis using the screw

from the slot cover that you set aside previously.

9. Replace the cover on the system unit.

10. Connect your analog monitor’s 15-pinVGAconnector to the card and fasten the

retaining screws (if any).

11. Connect other cables and devices if available -You are now ready to install the

software drivers and utilities.

Systems with Existing VGA Card

1. Install the ASUS AGP-V3000 display drivers with your current VGA card.

2. Shut down your computer and unplug all electrical cords.

3. Replace the existing VGA card with the ASUS AGP-V3000 graphics card.

4. Restart your computer — theASUSAGP-V3000 graphics card should be auto-

matically detected and the display drivers automatically updated.

II. Hardware Installation

II. Installation

Procedures

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Asus Carte vidéo

Asus

Asus NVIDIA GeForce GTX 1060 6 GB ROG STRIX... Guide d'installation

Asus

Asus Graphics Card A9200 Series Manuel utilisateur

Asus

Asus RX 580 Manuel utilisateur

Asus

Asus AGP-V264GT3 Manuel utilisateur

Asus

Asus TwinView V100 Series Manuel utilisateur

Asus

Asus MA3850 Manuel utilisateur

Asus

Asus MA3850 Manuel utilisateur

Asus

Asus G series Manuel utilisateur

Asus

Asus Splendid HD Manuel utilisateur

Asus

Asus V3000 Series Manuel utilisateur

Asus

Asus V9280 Video Suite Manuel utilisateur

Asus

Asus AGP-V5200 Manuel utilisateur

Asus

Asus V9950 Series Manuel utilisateur

Asus

Asus V7100 Manuel utilisateur

Asus

Asus 3DP-V375DX Manuel utilisateur

Asus

Asus Asus Graphics Card EN210SILENTDI1GD3V2LP Manuel utilisateur

Asus

Asus PhysX P1 Manuel utilisateur

Asus

Asus Xonar HDAV 1.3 Deluxe Manuel utilisateur

Asus

Asus agp-v1326 Manuel utilisateur

Asus

Asus EAX300SE-X/TD/128M Manuel d'utilisation et d'entretien

Asus

Asus V8460 Series Manuel utilisateur

Asus

Asus GeForce GTX 1660 TUF Gaming 6GB Manuel utilisateur

Asus

Asus 3DexPlorer GX2 Manuel utilisateur

Asus

Asus V8170 PRO/T/64M Manuel d'instructions

Manuels Carte vidéo populaires d'autres marques

Gainward

Gainward GeForce GTX 690 4GB Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 137-40225-20 Manuel utilisateur

MSI

MSI N220GT series Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 7000 MAC EDITION Manuel utilisateur

SIIG

SIIG aurora Manuel utilisateur

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manuel utilisateur

MSI

MSI R7850 series Manuel utilisateur

DVS

DVS Atomix HDMI Manuel utilisateur

Aztech

Aztech VGS3D-AGP Manuel utilisateur

Advoli

Advoli TB4 Standard Manuel utilisateur

ELSA

ELSA ERAZOR III LT Manuel utilisateur

Gigabyte

Gigabyte GV-R7500L Manuel utilisateur

Themis

Themis TGA-7000 PMC Manuel utilisateur

EMS

EMS XtremeRGB-Ex1 Manuel utilisateur

Nvidia

Nvidia Quadro Workstation Manuel utilisateur

Pioneer

Pioneer PDA-5003 Manuel utilisateur

QDI

QDI N2 Manuel utilisateur

NEC

NEC N8116-48 Manuel utilisateur
