Asus 3DP-V264GT Manuel utilisateur

3DP-V264GT/PRO

3DP-V264GT2/TV

3D Graphic Cards

USER'S MANUAL

Hardware & Video Drivers

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual

USER'S NOTICE

Product Name: ASUS 3DP-V264GT/PRO, 3DP-V264GT2/TV

Manual Revision: 1.01

Release Date: May 1997

No part of this product, including the product and software may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any lan-

guageinanyformbyanymeanswithouttheexpresswrittenpermissionofASUSTeK

COMPUTER INC. (hereinafter referred to as ASUS) except documentation kept

by the purchaser for backup purposes.

Specifications are subject to change without notice. ASUS provides this manual

“as is” without warranty of any kind, either express or implied, including but not

limited to the implied warranties or conditions of merchantability or fitness for a

particular purpose. In no event shallASUS be liable for any loss or profits, loss of

business, loss of use or data, interruption of business, or for indirect, special, inci-

dental, or consequential damages of any kind, even if ASUS has been advised of

the possibility of such damages arising from any defect or error in this manual or

product. ASUS may revise this manual from time to time without notice.

Products mentioned in this manual are mentioned for identification purposes only.

Product names appearing in this manual may or may not be registered trademarks

or copyrights of their respective companies.

• IBM is a registered trademark of International Business Machines Corp.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Sound Blaster AWE32 and SB16 are trademarks of Creative Technology Ltd.

• Adobe andAcrobat are registered trademarks of Adobe Systems Incorporated.

The product name and revision number are both printed on the board itself. Manual

revisions are released for each board design represented by the digit before and

after the period of the manual revision number. Manual updates are represented by

the third digit in the manual revision number. For previous or updated manuals,

BIOS, drivers, or product release information you may visit the ASUS home page

at http://www.asus.com.tw/ or contact ASUS from the following page.

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual 3

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC.

Marketing Info:

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan, ROC

Telephone: 886-2-894-3447

Fax: 886-2-894-3449

Email: [email protected]

Technical Support:

Fax: 886-2-895-9254

BBS: 886-2-896-4667

Email: [email protected]

WWW: http://www.asus.com.tw/

Gopher: gopher.asus.com.tw

FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL

Marketing Info:

Address: 721 Charcot Avenue, San Jose, CA 95131, USA

Telephone: 1-408-474-0567

Fax: 1-408-474-0568

Email: [email protected]

Technical Support:

BBS: 1-408-474-0555

Email: [email protected]

ASUS COMPUTER GmbH

Marketing Info:

Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany

Telephone: 49-2102-445011

Fax: 49-2102-442066

Email: [email protected]

Technical Support:

BBS: 49-2102-448690

Email: [email protected]

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual

CONTENTS

I. Introduction ......................................................................................7

Video Features............................................................................7

II. Features ...........................................................................................8

Resolution Table.........................................................................9

ASUS V264GT/PRO Layout ......................................................... 11

Adding Additional Memory .....................................................11

ASUS 3DP-V264GT2/TV Layout.................................................12

Adding Additional Memory .....................................................12

III. Hardware Installation ................................................................13

Installation Procedures: ............................................................13

IV. Driver Installation .......................................................................15

Video Driver Installation for Windows 95.....................................15

Software MPEG & Video Player for Windows 95 ........................19

Display Settings for Windows 95 ..................................................20

Video Driver Installation for Windows 3.x....................................21

Software MPEG & Video Player for Windows 3.x .......................23

V. Video Software...............................................................................25

ATI Desktop Control Panel ......................................................25

ATI Desktop Features...............................................................25

FlexDesk+ ......................................................................................26

FlexDesk+ Basic Settings ........................................................26

FlexDesk+ Advanced Settings .................................................28

DPMS (for Windows) ....................................................................29

Timer Settings ..........................................................................29

Buttons .....................................................................................29

DeskScape......................................................................................30

DeskScape Functions ...............................................................30

Buttons .....................................................................................31

WinSwitch......................................................................................31

Screen Adjustment ...................................................................32

DPMS Parameters ....................................................................34

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual 5

VI. Video Player.................................................................................35

Windows Video Player...................................................................35

Features ..........................................................................................35

Playing Audio CDs (Only in window 95) .........................36

Playing Media Files...........................................................37

Playing Interactive Discs (Video CD 2.0) ..........................37

Capturing Audio/Video (only on 3DP-V264GT/PRO).....38

Capturing Still Frames........................................................39

Capturing Video..................................................................39

Playing Captured Video andAudio ....................................40

Intelligent Video In (only on 3DP-V264GT/PRO) ...........40

Features...............................................................................40

Using the VIDEO IN ..........................................................40

Using ImpacTV..............................................................................42

If there is no display, you may............................................42

need to enable ImpacTV. ....................................................42

VII. Other Driver Installation ..........................................................43

Video Driver Installation for Windows NT 4.0 .............................43

Video Driver Installation for Windows NT 4.0 .............................45

Video Driver Installation for Windows NT 3.5x ...........................46

Video Driver Installation for IBM OS/2 ........................................47

AutoCAD Video Driver Installation ..............................................48

Microstation Video Driver Installation ..........................................49

Select System Information (optional) ............................................50

Quick Setup (optional)...................................................................50

VDIF Files (optional).....................................................................51

Advanced Setup (optional) ............................................................52

A. Troubleshooting ............................................................................53

Diagnostics.....................................................................................53

Troubleshooting .............................................................................53

System Lockup ..............................................................................53

CONTENTS

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual

FCC & DOC COMPLIANCE

FederalCommunicationsCommission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with manufacturer's instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the inter-

ference by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING: Theuseofshieldedcablesforconnectionofthemonitortothegraphics

card is required to assure compliance with FCC regulations. Changes or modifica-

tions to this unit not expressly approved by the party responsible for compliance

could void the user's authority to operate this equipment.

CanadianDepartmentof Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the Cana-

dian Department of Communications.

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual 7

The 3DP-V264GT/PRO & 3DP-V264GT2/TV adapters take advantage of 32-bit

PCI bus to provide high performance graphics. The 3DP-V264GT/PRO & 3DP-

V264GT2/TV are graphics controllers that integrate 3D, 2D, video accelerators,

palette DAC, and dual clock synthesizer into a single chip. The 3DP-V264GT/PRO

& 3DP-V264GT2/TV deliver superior texture mapping performance for 3D games,

3D Web browsing, TV quality video scaling for MPEG playback, industry-leading

mach64 2D performance, video expansion capability for video conferencing, and

other applications.

Active power management techniques are used to monitor activity levels within

these graphics controllers and to perform real-time power reductions such as dy-

namic clock control and graphics engine shutdown. Because full-speed operation

can be restored without delay, these techniques do not impact performance.

For multimedia video and game function acceleration, the 3DP-V264GT/PRO &

3DP-V264GT2/TV have color interpolation for full screen, full motion video, and

provides fast 30 frame/second animation engine, double buffering, fast host to screen

bitblts, virtual sprite, smooth page scrolling and object caching for game functions.

PC users with this adapter could enjoy smooth motion video and SEGA/SNES-class

games.

ForVideoplaybackfeatures,3DP-V264GT/PRO&3DP-V264GT2/TVsupportsoft-

ware MPEG decoder. The driver not only provides smooth video playback, but also

provides user friendly utilities that allows customizing appearances.

You can use 3DP-V264GT/PRO & 3DP-V264GT2/TV to connect your computer to

a television. This feature is ideal for playing games, giving presentations, watching

movies, and browsing the Internet.

Now you can watch videos, games on your computer! 3DP-V264GT/PRO & 3DP-

V264GT2/TV let you watch full-motion video on the whole screen or in a window.

You can capture still frames and movie clips.

Video Features

• 32-bit PCI Local Bus graphics adapter

• Integrated 24-bit RAMDAC (200MHz Output Pixel Clock Interface)

• Max resolution at 1600x1200 high color at 60Hz refresh rate with 4MB

• DDC1 /2B monitor supported

• DPMS (Display Power Management Signaling) for Green PC Power Saving

I. Introduction

(Features)

8 ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual

Memory on 3DP-V264GT/PRO

• ATI RAGE Graphics Accelerator, 64-bit SGRAM memory interface

• Comes with 4MB SGRAM standard and upgradeable to 8MB SGRAM

Memory on 3DP-V264GT2/TV

• ATI RAGE Graphics Accelerator, 64-bit EDO DRAM memory interface

• Comes with 2MB EDO DRAM standard and upgradeable to 4MB EDO DRAM

3DAccelerator

• Complete 3D primitives - Points, Lines, Triangles, Trapezoids and Rectangles

• Full screen or windows double buffering for smoother animation

• Dithering down to 6 or 16 bits per pixels (bpp) from 24bpp 3D engine for smaller

memory foot print

• 3DFeatures:PerspectivelyCorrectTextureMapping, Gouraud Shading, Z-Buffer,

Mip Maps, Lit and Video Textures, Dither , Alpha Blending and Interpolation,

and Fog Effects.

2D Accelerator

• Hardware acceleration-Rectangle Fill, Line Draw, BitBlt, Polygon Fill, Panning/

Scrolling, Bit Masking, Monochrome Expansion, Scissoring, and full ROP .

• Hardware cursor up to 64x64x2

• Acceleration provided in 4/8/16/24/32bpp modes. Packed pixel support (24bpp)

enables true color in 1MB configurations

• Game acceleration for Microsoft’s Direct Draw - Double Buffering, Virtual

Sprites, Transparent Blit, Masked Blit, and Context Chaining

Video In (only on 3DP-V264GT/PRO)

• Television quality video in a window and full screen.

• Composite video and S-Video inputs for VCR, video camera, laser-disc player,

video game consoles, etc.

• Still image and live video capture with a simple mouse click.

• Live motion video desktop, using your favorite video show as wallpaper.

• Zoom-in to any part of the screen.

TV Out

• View computer output directly on your television in either NTSC or PAL formats.

• Enhance your system with advanced flicker reduction and artifact suppression

circuitry.

• Connect using Composite or S-Video output capabilities.

• Display images on both the TV and PC montior simultaneously.

• Provide a big-screen experience for entertainment PCs which is ideal for play-

ing games, giving presentations, watching movies, and browsing the Internet.

II. Features

(Specifications)

ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual 9

Resolution Table

When discussing color depth, 8 bits per pixel (8bpp) is the same as 256 colors and

16bpp = 65, 536 colors, 24bpp = 16.7 million, and 32bpp = 16.7 million colors. The

following is a table for the maximum refresh rates under the specified memory con-

figuration for each card. Please note that the 3DP-V264GT2/TV has 2MB or 4MB

configurations and the 3DP-V264GT/PRO has 4MB or 8MB configurations.

Max Referesh Rates

Resolution Colors 2MB 4MB 8MB

640 x 480 x 8 256 200Hz 200Hz 200Hz

640 x 480 x 16 65, 536 200Hz 200Hz 200Hz

640 x 480 x 24 16.7 Million 200Hz 200Hz 200Hz

640 x 480 x 32 16.7 Million 200Hz 200Hz 200Hz

800 x 600 x 8 256 200Hz 200Hz 200Hz

800 x 600 x 16 65, 536 200Hz 200Hz 200Hz

800 x 600 x 24 16.7 Million 160Hz 160Hz 160Hz

800 x 600 x 32 16.7 Million 120Hz 120Hz 120Hz

1024 x 768 x 8 256 150Hz 150Hz 150Hz

1024 x 768 x 16 65, 536 150Hz 150Hz 150Hz

1024 x 768 x 24 16.7 Million ------- 120Hz 120Hz

1024 x 768 x 32 16.7 Million ------- 100Hz 100Hz

1152 x 864 x 8 256 100Hz 100Hz 100Hz

1152 x 864 x 16 65, 536 100Hz 100Hz 100Hz

1152 x 864 x 24 16.7 Million ------- 85Hz 85Hz

1152 x 864 x 32 16.7 Million ------- 80Hz 80Hz

1280 x 1024 x 8 256 85Hz 85Hz 85Hz

1280 x 1024 x 16 65, 536 ------- 85Hz 85Hz

1280 x 1024 x 24 16.7 Million ------- 75Hz 75Hz

1280 x 1024 x 32 16.7 Million ------- ----- 75Hz

1600 x 1200 x 8 256 60Hz 60Hz 60Hz

1600 x 1200 x 16 65, 536 ------- 60Hz 60Hz

II. Features

(Specifications)

3DP-V264GT2/TV

3DP-V264GT/PRO

10 ASUS 3DP-V264GT/PRO & 3DP-V264GT2/TV User’s Manual

Video Accelerator

• Filtered horizontal and vertical scalers for TV-quality, full-screen and full-mo-

tion video playback

• Integrated video line buffers support filtered video scaling

• Color interpolation during scaling for improved high resolution video quality

• SupportsAMC for additional video expansion capabilities such as: optional TV

tuner card available for video capture, video phone, TV overlay, or TV tuner

applications.

• Optional MPEG-1 decoder for hardware video

• Support for 26-pin VESAcompatible VGAFeature Connector (VFC) that sup-

ports up to 1024x768 resolution.

Software

• 2D driver support

• Register compatible with IBM VGA standards

• BIOS compatible with VESA Super VGA

• Full support of Microsoft DCI and DirectDraw

• 3D driver support

• Microsoft Direct 3D including support for Reality Lab and OpenGL

• ATI 3D RAGE DOS and Windows API

• Intel 3DR

• Easy-to-use Windows utilities

• WinSwitch provides on-the-fly switching of resolution and color depth within

Windows

• DeskTop supports panning and scrolling across a virtual workspace of up to

1600x1200

• Utility for selecting DPMS power-down time-outs

• Video playback application and codec

• Video codec support for MPEG, Indeo, and Cinepak

• ATI MPEG video player application with VCR-like controls

• Extensive software driver support for major applications and operating systems

as follows:

• Windows 3.1,Windows 95,WindowsNT,AutoCAD, Microstation, OS/2,VESA

BIOS Extension support.

II. Features
