Asus E8711 Manuel utilisateur

USER MANUAL

E8711

ASUS Tablet

E8711_ME373CG_User_Manual.indd 1 26/9/13 9:03:18 AM

Charging your device

Ensure to fully charge your ASUS Tablet before using it in

battery mode for extended periods. Remember that the power

adapter charges your ASUS Tablet as long as it is plugged into

an AC power source. Be aware that it takes much longer to

charge the ASUS Tablet when it is in use.

IMPORTANT! Do not leave the ASUS Tablet connected to

the power supply once it is fully charged. ASUS Tablet is not

designed to be left connected to the power supply for extended

periods of time.

Airplane precautions

Contact your airline provider to learn about related inight

services that can be used and restrictions that must be followed

when using your ASUS Tablet in-ight.

IMPORTANT! You can send your ASUS Tablet through x-ray

machines (used on items placed on conveyor belts), but do not

expose them from magnetic detectors and wands.

Safety precautions

This ASUS Tablet should only be used in enviroments with

ambient temperatures between 0°C (32°F) and 35°C (95°F).

Long time exposure to extremely high or low temperature

may quickly deplete and shorten the battery life. To ensure the

battery’s optimal performance, ensure that it is exposed within

the recommended environment temperature.

E8711_ME373CG_User_Manual.indd 2 26/9/13 9:03:18 AM

ASUS Tablet

Package contents

NOTES:

• If any of the items is damaged or missing, contact your

retailer.

• The bundled power adapter varies with country or region.

Power adapter

ASUS Tablet Micro SIM card tray eject pin

Micro USB cable Technical documentations and

warranty card

E8711_ME373CG_User_Manual.indd 3 26/9/13 9:03:19 AM

ASUS Tablet

Your ASUS Tablet

Front view

Front camera

Touch screen

panel

Audio speaker

Audio speaker Ambient light sensor

Proximity sensor

E8711_ME373CG_User_Manual.indd 4 26/9/13 9:03:20 AM

ASUS Tablet

Rear view

Micro USB 2.0 port

Volume button

Power button

MicroSD card slot*

Speaker/Headset port

Rear camera

Microphone

* The microSD card slot supports microSD, microSDHC, and microSDXC card formats.

** The micro SIM card slot supports WCDMA and GSM network bands.

MicroSIM card slot**

E8711_ME373CG_User_Manual.indd 5 26/9/13 9:03:20 AM

ASUS Tablet

Charging your ASUS Tablet

To charge your ASUS Tablet:

Connect the micro USB cable to the power adapter.

Plug the micro USB connector into your ASUS Tablet.

Plug the power adapter into a grounded power outlet.

Charge your ASUS Tablet for eight (8) hours before

using it in battery mode for the rst time.

E8711_ME373CG_User_Manual.indd 6 26/9/13 9:03:21 AM

ASUS Tablet

IMPORTANT!

• Use only the bundled power adapter and micro USB cable

to charge your ASUS Tablet. Using a dierent power adapter

may damage your ASUS Tablet.

• Peel the protective lm o from the power adapter and micro

USB cable before charging the ASUS Tablet to prevent risk or

injury.

• Ensure that you plug the power adapter to the correct power

outlet with the correct input rating. The output voltage of this

adapter is DC 5.2V, 1.35A.

• When using your ASUS Tablet while plugged-in to a power

outlet, the grounded power outlet must be near the unit and

easily accessible.

• Do not place objects on top of your ASUS Tablet.

NOTES:

• Your ASUS Tablet can be charged via the USB port on a

computer only when it is in sleep mode (screen o) or turned

o.

• Charging through a USB port of a computer may take longer

time to complete.

• If your computer does not provide enough power for

charging your ASUS Tablet, charge your ASUS Tablet via the

grounded power outlet instead.

E8711_ME373CG_User_Manual.indd 7 26/9/13 9:03:22 AM

ASUS Tablet

Installing a micro SIM card

Before you can make calls, send text messages, or connect to a

mobile broadband network using your ASUS Tablet, you need

to install a micro SIM (Subscriber Identity Module) card.

To install a micro SIM card:

1. Insert the tip of the bundled micro SIM card tray eject pin to

eject the micro SIM card tray.

2. Pull out the micro SIM card tray and place the micro SIM

card on the tray with the metal contacts facing up, as

shown.

Metal contacts

E8711_ME373CG_User_Manual.indd 8 26/9/13 9:03:22 AM

ASUS Tablet

3. Align and insert the micro SIM card tray back to the slot.

E8711_ME373CG_User_Manual.indd 9 26/9/13 9:03:22 AM

ASUS Tablet

Appendices

Canada, Industry Canada (IC) Notices

This Class B digital apparatus complies with Canadian ICES-003,

RSS-210, and CAN ICES-3(B)/NMB-3(B).

Operation is subject to the following two conditions: (1) this

device may not cause interference, and (2) this device must

accept any interference, including interference that may cause

undesired operation of the device. The IC ID for this device is

3568A-K00E.

Radio Frequency (RF) Exposure Information

The radiated output power of the Wireless Device is below

the Industry Canada (IC) radio frequency exposure limits. The

Wireless Device should be used in such a manner such that

the potential for human contact during normal operation is

minimized.

This device has been evaluated for and shown compliant with

the IC Specic Absorption Rate (“SAR”) limits when installed

in specic host products operated in portable exposure

conditions.

Canada’s REL (Radio Equipment List) can be found at the

following web address:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.

do?lang=eng

E8711_ME373CG_User_Manual.indd 10 26/9/13 9:03:22 AM
