Asus ASUS VivoTab Manuel utilisateur
VivoTab User Manual
E7895
ASUS is devoted to creating environment-friendly products
and packaging to safeguard consumers’ health while
minimizing the impact on the environment. The reduction
of the number of the manual pages complies with the
reduction of carbon emission.
For the detailed user manual and related information, refer
to the user manual included in the VivoTab or visit the ASUS
Support Site at http://support.asus.com/.
E7895_ME400C_Series_User_Manual_1 1 11/30/12 10:40:23 AM
Charging your batteries
Ensure to fully charge your battery pack before using your
VivoTab in battery mode for extended periods. Remember that
the power adapter charges the battery pack as long as it is
plugged into an AC power source. Be aware that it takes much
longer to charge the battery pack when the VivoTab is in use.
IMPORTANT! Do not leave the VivoTab connected to the power
supply once it is fully charged. VivoTab is not designed to be left
connected to the power supply for extended periods of time.
Airplane Precautions
Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your VivoTab in-ight.
IMPORTANT! You can send your VivoTab through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety Precautions
This VivoTab should only be used in enviroments with ambient
temperatures between 0°C (32°F) and 35°C (95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.
E7895_ME400C_Series_User_Manual_2 2 11/30/12 10:40:24 AM
ASUS VivoTab
3
Micro USB cable
VivoTab Power adapter
Technical documentations
and warranty card
Cleaning cloth
Package contents
NOTES:
• If any of the items is damaged or missing, contact your
retailer.
• The bundled power adapter varies with country or region.
E7895_ME400C_Series_User_Manual_3 3 11/30/12 10:40:24 AM
ASUS VivoTab
4
Your VivoTab
Front view
Front camera
This built-in 2-megapixel camera allows you to take
pictures or record videos using your VivoTab.
Camera indicator
The camera indicator lights up when either of the
built-in cameras is in use.
Ambient light sensor
The ambient light sensor detects the amount of
light in your environment. It allows the system to
automatically adjust the brightness of the display
depending on the ambient light condition.
E7895_ME400C_Series_User_Manual_4 4 11/30/12 10:40:25 AM
ASUS VivoTab
5
Touch screen panel
The touch screen panel allows you to operate your
VivoTab using touch gestures or a stylus pen.
Windows® 8 touch button
Touch this button to go back to the Start screen. If you
are already in the Start screen, touch this button to go
back to the last app you opened.
E7895_ME400C_Series_User_Manual_5 5 11/30/12 10:40:25 AM
ASUS VivoTab
6
Rear view
Headphone output/microphone input combo jack
port
This port allows you to connect the VivoTab’s audio-
out signal to amplied speakers or headphones. You
can also use this port to connect your VivoTab to an
external microphone.
IMPORTANT! For microphone input function, the
jack only supports headset microphone.
Volume button
Press this button to increase or decrease the volume.
E7895_ME400C_Series_User_Manual_6 6 11/30/12 10:40:27 AM
ASUS VivoTab
7
Manual reset hole
If the system becomes unresponsive, insert a
straightened paper clip into the hole to force-restart
your VivoTab.
IMPORTANT! Forcing the system to restart may result
to data loss. We strongly recommend that you back
up your data regularly.
Microphone
The built-in mono microphone can be used for
video conferencing, voice narrations or simple audio
recordings.
Camera LED ash
Use the LED ash when taking pictures or recording
videos in a low-light environment.
You can set the LED ash to any of these settings:
Setting Description
AUTO The system automatically uses the LED
ash when taking pictures depeding on the
lighting condition.
ON The system uses the LED ash constantly
when taking pictures in any lighting
condition.
TORCH The system uses the LED ash as a constant
lighting xture or torch when taking photos
or recording videos.
OFF The system disables the LED ash.
E7895_ME400C_Series_User_Manual_7 7 11/30/12 10:40:28 AM
ASUS VivoTab
8
Rear camera
This built-in 8-megapixel camera allows you to take
high-denition pictures or record high-denition
videos using your VivoTab.
Power button
Press the power button to turn your VivoTab on, put
it to sleep or hibernate and wake it up from sleep or
hibernate mode.
Press and hold the power button for about ve (5)
seconds to force shut down your VivoTab when it
becomes unresponsive.
IMPORTANT! Forcing the system to restart may result
to data loss. We strongly recommend that you back
up your data regularly.
Battery charge indicator
This two-color LED provides a visual indication of
the battery’s charge status.
Refer to the table below for details:
Color Status
White Fully charged.
Orange Charging mode.
Dim The AC adapter is not plugged to the
VivoTab.
E7895_ME400C_Series_User_Manual_8 8 11/30/12 10:40:28 AM
ASUS VivoTab
9
Micro HDMI port
This port is for a micro HDMI (High-Denition
Multimedia Interface) connector and is HDCP
compliant for HD DVD, Blu-ray and other protected
content playback.
MicroSD card slot
The VivoTab comes with a built-in memory card
reader slot that supports microSD, microSDHC and
microSDXC card formats.
Built-in NFC (Near Field Communication) tag
The built-in NFC tag allows you to conveniently share
contacts, pictures, business cards, and other les.
To use the NFC tag, put your VivoTab’s NFC tag near
another NFC-enabled device.
Audio speaker
Your VivoTab is equipped with a built-in high quality
stereo speaker. Audio features are software controlled.
Micro USB 2.0 port
Use the micro USB (Universal Serial Bus) 2.0 port to
charge the battery pack or supply power to your
VivoTab.
E7895_ME400C_Series_User_Manual_9 9 11/30/12 10:40:29 AM
ASUS VivoTab
10
Charging your VivoTab
Connect the micro USB cable to the power adapter.
Plug the micro USB connector into your VivoTab.
Plug the power adapter into a grounded socket outlet.
To charge your VivoTab:
