Asus RT-AC1300G PLUS Manuel utilisateur

User Guide

RT-AC1300G PLUS

Dual Band Gigabit WiFi Router

Hardware Version: V2

No part of this manual, including the products and software described

in it, may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language in any form or by any means, except

documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired,

modied or altered, unless such repair, modication of alteration is authorized

in writing by ASUS; or (2) the serial number of the product is defaced or

missing.

ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND,

EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED

WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,

EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,

OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,

LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS

AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR

PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE

FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE

AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A

COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY

FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be

registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’benet, without intent

to infringe.

E16013

Second Edition

October 2019

Table of contents

1 Getting to know your wireless router

1.1 Welcome! ........................................................................................6

1.2 Package contents.........................................................................6

1.3 Your wireless router.....................................................................7

1.4 Positioning your router..............................................................9

1.5 Setup Requirements ................................................................ 10

1.6 Router Setup............................................................................... 11

1.6.1 Wired connection..................................................................11

1.6.2 Wireless connection.............................................................12

2 Getting started

2.1 Logging into the Web GUI ..................................................... 14

2.2 Quick Internet Setup (QIS) with Auto-detection ........... 15

2.3 Connecting to your wireless network................................ 19

3 Conguring the General settings

3.1 Using the Network Map ......................................................... 20

3.1.1 Setting up the wireless security settings......................21

3.1.2 Managing your network clients.......................................22

3.1.3 Monitoring your USB device.............................................23

3.2 Creating a Guest Network...................................................... 26

3.3 Using the Trac Manager ...................................................... 28

3.3.1 Managing QoS (Quality of Service) Bandwidth..........28

3.3.2 Monitoring Trac .................................................................31

3.4 Setting up Parental Control................................................... 32

3.5 Using the USB Application..................................................... 33

3.5.1 Using Servers Center............................................................33

Table of contents

4 Conguring the Advanced Settings

4.1 Wireless......................................................................................... 36

4.1.1 General......................................................................................36

4.1.2 WPS ............................................................................................39

4.1.3 Wireless MAC Filter...............................................................41

4.1.4 RADIUS Setting ......................................................................42

4.1.5 Professional.............................................................................43

4.2 LAN................................................................................................. 45

4.2.1 LAN IP ........................................................................................45

4.2.2 DHCP Server............................................................................46

4.2.3 Route .........................................................................................48

4.3 WAN ............................................................................................... 49

4.3.1 Internet Connection.............................................................49

4.3.2 Port Trigger..............................................................................52

4.3.3 Virtual Server/Port Forwarding........................................54

4.3.4 DMZ............................................................................................57

4.3.5 DDNS .........................................................................................58

4.3.6 NAT Passthrough...................................................................59

4.4 IPv6................................................................................................. 60

4.5 VPN Server................................................................................... 61

4.6 Firewall.......................................................................................... 62

4.6.1 General......................................................................................62

4.6.2 URL Filter ..................................................................................62

4.6.3 Keyword lter .........................................................................63

4.6.4 Network Services Filter .......................................................64

4.7 Administration ........................................................................... 66

4.7.1 Operation Mode ....................................................................66

4.7.2 System.......................................................................................67

4.7.3 Firmware Upgrade................................................................68

Table of contents

4.7.4 Restore/Save/Upload Setting ...........................................68

4.8 System Log .................................................................................. 69

5 Utilities

5.1 Device Discovery....................................................................... 70

5.2 Firmware Restoration .............................................................. 71

6 Troubleshooting

6.1 Basic Troubleshooting............................................................. 73

6.2 Frequently Asked Questions (FAQs) .................................. 76

Appendices

Notices ....................................................................................................... 85

ASUS Contact information.................................................................... 99

1 Getting to know your wireless

router

NOTES:

• Ifanyoftheitemsaredamagedormissing,contactASUSfor

technical inquiries and support, Refer to the ASUS Support Hotline

list at the back of this user manual.

• Keeptheoriginalpackagingmaterialincaseyouwouldneedfuture

warranty services such as repair or replacement.

RT-AC1300G PLUS V2 Wireless Router Network cable (RJ-45)

Power adapter Quick Start Guide

Warranty card

1.1 Welcome!

Thank you for purchasing an ASUS RT-AC1300G PLUS Wireless

Router!

The ultra-thin and stylish RT-AC1300G PLUS features a 2.4GHz

and 5GHz dual bands for an unmatched concurrent wireless HD

streaming; SMB server, and UPnP AV server for 24/7 le sharing.

1.2 Package contents

1.3 Your wireless router

1Power LED

O: No power.

On: Device is ready.

Flashing slow: Rescue mode

Flashing quick:WPS is processing.

2LAN LED

O: No power or no physical connection.

On: Has physical connection to a local area network (LAN).

3WAN (Internet) LED

O: No power or no physical connection.

On: Has physical connection to a wide area network (WAN).

4USB LED

O: No power or no physical connection.

On: Has physical connection to USB device.

52.4GHz LED / 5GHz LED

O: No 2.4GHz or 5GHz signal.

On:Wireless system is ready.

Flashing:Transmitting or receiving data via wireless connection.

6Reset button

This button resets or restores the system to its factory default settings.

Wireless Dual Band

802.11ac Gigabit Router

912

711

NOTES:

• Useonlytheadapterthatcamewithyourpackage.Usingother

adapters may damage the device.

• Specications:

DC Power adapter DC Output: +12V with max 1.5A current;

Operating

Temperature 0~40oCStorage 0~70oC

Operating Humidity 50~90% Storage 20~90%

7Power switch

Switch to power on or off the system.

8Power (DC-IN) port

Insert the bundled AC adapter into this port and connect your router to a power source.

9USB port

Insert a USB device such as USB hard disk or USB flash drive into the port.

Insert your iPad’s USB cable into the port to charge your iPad.

10 WPS button

This button launches the WPS Wizard.

11 WAN (Internet) port

Connect a network cable into this port to establish WAN connection.

12 LAN 1 ~ 4 ports

Connect network cables into these ports to establish LAN connection.

1.4 Positioning your router

For the best wireless signal transmission between the wireless

router and the network devices connected to it, ensure that you:

• Placethewirelessrouterinacentralizedareaforamaximum

wireless coverage for the network devices.

• Keepthedeviceawayfrommetalobstructionsandawayfrom

direct sunlight.

• Keepthedeviceawayfrom802.11b/gor20MHzonlyWi-Fi

devices, 2.4GHz computer peripherals, Bluetooth devices,

cordlessphones,transformers,heavy-dutymotors,fluorescent

lights, microwave ovens, refrigerators, and other industrial

equipment to prevent signal interference or loss.

• Alwaysupdatetothelatestfirmware.VisittheASUSwebsiteat

http://www.asus.com to get the latest firmware updates.

• Toensurethebestwirelesssignal,orientthefourexternal

antennas as shown in the drawing below.

90°90 °

1.5 Setup Requirements

To set up your wireless network, you need a computer that meets

the following system requirements:

• EthernetRJ-45(LAN)port(10Base-T/100Base-TX)

• IEEE802.11a/b/g/n/acwirelesscapability

• AninstalledTCP/IPservice

• WebbrowsersuchasInternetExplorer,Firefox,Safari,or

Google Chrome

NOTES:

• Ifyourcomputerdoesnothavebuilt-inwirelesscapabilities,you

may install an IEEE 802.11a/b/g/n WLAN adapter to your computer

to connect to the network.

• Withitsdualbandtechnology,yourwirelessroutersupports2.4GHz

and 5GHz wireless signals simultaneously. This allows you to do

Internet-related activities such as Internet surng or reading/writing

e-mail messages using the 2.4GHz band while simultaneously

streaming high-denition audio/video les such as movies or music

using the 5GHz band.

• SomeIEEE802.11ndevicesthatyouwanttoconnecttoyournetwork

may or may not support 5GHz band. Refer to the device's manual for

specications.

• TheEthernetRJ-45cablesthatwillbeusedtoconnectthenetwork

devices should not exceed 100 meters.

Autres manuels pour RT-AC1300G PLUS

Table des matières

Autres manuels Asus Routeur réseau

Asus

Asus GX1005B Manuel utilisateur

Asus

Asus WL-566gM Manuel utilisateur

Asus

Asus ZenWiFi AC Mini CD6 Series Manuel utilisateur

Asus

Asus RT-N66U Dark Knight Manuel utilisateur

Asus

Asus RT-AX92U Manuel utilisateur

Asus

Asus XD4S Manuel utilisateur

Asus

Asus RT-N300 B1 Manuel utilisateur

Asus

Asus RT-AC66U Manuel utilisateur

Asus

Asus ZenWiFi Pro ET12 Manuel utilisateur

Asus

Asus Wireless-N300 Manuel utilisateur

Asus

Asus RT-AC1900P Manuel utilisateur

Asus

Asus RT-N600RU Manuel utilisateur

Asus

Asus ROG Rapture GT-AX6000 Manuel utilisateur

Asus

Asus RT-AC52U Manuel utilisateur

Asus

Asus RT-AC2600 Manuel utilisateur

Asus

Asus ZenWiFi Pro ET12 Manuel utilisateur

Asus

Asus WL-500gP Manuel utilisateur

Asus

Asus Republic of Gamers GT-AX5400 Manuel utilisateur

Asus

Asus DSL-N10 Manuel utilisateur

Asus

Asus RT-N10LX Manuel utilisateur

Asus

Asus DSL-N12E_C1 Manuel utilisateur

Asus

Asus ROG Rapture GT-AC5300 Manuel utilisateur

Asus

Asus ROG Rapture GT-AX6000 Manuel utilisateur

Asus

Asus 4G-AC86U Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
