Asus X014D Manuel utilisateur

E12014

User Guide

Third Edition/ September 2016

Model:ASUS_X014D (ZB452KG)

Before you start, ensure that you have read all the

safety information and operating instructions in this

User Guide to prevent injury or damage to your

device.

NOTE: For the latest updates and more detailed

information, please visit www.asus.com.

Front features

Touch screen

display

Receiver

LED indicator

Touch keys

Sensor

Front camera

Side features

NOTE: Pry open the rear cover from the groove.

Power Key

Audio jack

Micro USB port

Groove

Microphone

Rear features

NOTES:

• Removetherearcovertodisplaythedual

micro SIM and microSD card slots.

• ThemicroSIMcardslotssupport,WCDMA,

and GSM/EDGE network bands.

• ThemicroSDcardslotsupportsmicroSDand

microSDHCcardformats.

Rear camera

Camera ash

Rear cover

Speaker

Volume key

Charging your ASUS Phone

To charge your ASUS Phone:

1. ConnecttheUSBconnectorintothepower

adapter’s USB port.

2. ConnecttheotherendofthemicroUSBcable

to your ASUS Phone.

3. Plug the power adapter into a wall socket.

NOTES:

• Useonlythepoweradapterthatcamewith

your device. Using a different power adapter

may damage your device.

• UsingthebundledpoweradapterandASUS

Phone signal cable to connect your ASUS

Phone to a power outlet is the best way to

charge your ASUS Phone.

• Theinputvoltagerangebetweenthewall

outletandthisadapterisAC100V-240V.

The output voltage of the micro USB cable is

+5.2V 1A,5W.

IMPORTANT!

• WhenusingyourASUSPhonewhileitis

plugged to a power outlet, the grounded

power outlet must be near to the unit and

easily accessible.

• WhenchargingyourASUSPhonethrough

your computer, ensure that you plug the micro

USB cable to your computer’s USB 2.0 / USB

3.0 port.

• AvoidchargingyourASUSPhoneinan

environment with ambient temperature of

above 35oC(95oF).

1. Locate the groove on the

bottom-rightcornerof

your ASUS Phone.

Installing a micro SIM card

To install a micro SIM card:

2. Pry the cover loose

and then pull the

rear cover off.

3. Insert the micro SIM card into one of the micro

SIM card slots.

Micro SIM card slot 1

Micro SIM card slot 2

IMPORTANT: Both micro SIM card slots support

3G/2GWCDMAnetworkband.Butonlyone

microSIMcardcanconnectto3GWCDMA

service at a time.

1. Locate the groove on the

bottom-rightcornerof

your ASUS Phone.

Installing a microSD card

To install a microSD card:

CAUTION!

• Donotusesharptoolsorsolventonyour

device to avoid scratches on it.

• UseonlyastandardmicroSIMcardonyour

ASUS Phone. A nano to micro SIM adapter

oratrimmedSIMcardmaynotproperlyt

into and may not be detected by your ASUS

Phone.

• DO NOT install an empty nano to micro

SIM adapter into the micro SIM card slot to

avoid irreversible damage.

2. Pry the cover loose

and then pull the

rear cover off.

3. Insert the microSD card into the

microSD card slot.

MicroSD card slot

CAUTION!Changesormodicationsnotexpressly

approved by the part responsible for compliance could

void the user’s authority to operate the equipment.

Thisdevicecomplieswithpart15oftheFCCRules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

This equipment has been tested and found to

complywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee

that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which

can be determined by turning the equipment off

and on, the user is encouraged to try to correct

the interference by one or more of the following

measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweenthe

equipment and receiver.

• Connecttheequipmentintoanoutletona

circuit different from that to which the receiver

is connected.

• Consultthedealeroranexperiencedradio/TV

technician for help.

Federal Communications

Commission (FCC) Statement

CAUTION!Changesormodicationsnotexpressly

approved by the part responsible for compliance could

void the user’s authority to operate the equipment.

RF Exposure Information (SAR)

This device has been tested and meets applicable

limitsforRadioFrequency(RF)exposure.

SpecicAbsorptionRate(SAR)referstotherateat

whichthebodyabsorbsRFenergy.SARlimitsare

1.6Wattsperkilogram(overavolumecontaining

a mass of 1 gram of tissue) in countries that follow

theUnitedStatesFCClimitand2.0W/kg(averaged

over 10 grams of tissue) in countries that follow the

CounciloftheEuropeanUnionlimit.TestsforSAR

are conducted using standard operating positions

withthedevicetransmittingatitshighestcertied

power level in all tested frequency bands.

ToreduceexposuretoRFenergy,useahands-free

accessory or other similar option to keep this device

awayfromyourheadandbody.Carrythisdevice

at least 15 mm away from your body to ensure

exposurelevelsremainatorbelowtheas-tested

levels.Choosethebeltclips,holsters,orother

similarbody-wornaccessorieswhichdonotcontain

metallic components to support operation in this

manner.CaseswithmetalpartsmaychangetheRF

performance of the device, including its compliance

withRFexposureguidelines,inamannerthat

hasnotbeentestedorcertied,andusesuch

accessories should be avoided.

ThehighestFCCSARvaluesforthedeviceareas

follows:

• 0.476W/Kg(Head)

• 0.989W/Kg(Body)

TheFCChasgrantedanEquipmentAuthorization

forthisdevicewithallreportedSARlevelsevaluated

asincompliancewiththeFCCRFexposure

guidelines.SARinformationonthisdeviceisonle

withtheFCCandcanbefoundundertheDisplay

Grant section of www.fcc.gov/oet/ea/fccid after

searchingonFCCID:MSQX014D
