AstroStart RS-113 Manuel utilisateur

PATENTS PENDING

PATENT NO. CAN. 1.130.426

PATENT NO. U.S. 4.345.554 193-113-221-A0

REMOTE CONTROL ENGINE STARTER

MODEL RS-113

For all automatic

transmission gas- and

diesel-powered

vehicles. (Carburetor

models require an

optional solenoid.)

DO NOT INSTALL ON

MANUAL

TRANSMISSION

VEHICLES.

Made in Canada by:

ASTROFLEX Inc.

INTRODUCTION

Thank you for choosingthe

ASTRO

START

Remote Control Engine Starter. Your Remote

Starter is the result of intensive research by a company specializing in the design of

high-quality electronic automotive products.

ASTRO

START is designed to provide many

years of reliable, trouble-free service. Its advanced microchip circuitry incorporates

billions of possible access codes which makes it practically impossible to interfere with

another remote control vehicle. Your Remote Starter offers the ultimate in safety, is

simple to use and has many features to make your life easier. Please read the following

instructions carefully so that you understand how your

ASTRO

START works and can take

advantage of all these features. Some of the functions described below may not be

applicable to your vehicle.

SAFETY PRECAUTIONS

¾Always turn off main switch when vehicle is parked in an enclosed, unventilated area

or is in for servicing.

¾Always turn off main switch when not using your Remote Starter for extended periods

of time.

¾Keep remote controls away from children.

¾Have your engine tuned regularly to ensure optimum performance of your Remote

Starter.

¾Make sure your windshield wipers are turned off before leaving vehicle.

¾Check safety features regularly; they prevent your Remote Starter from operating

under certain conditions. (See “SAFETY CHECKS”.)

¾Make sure you comply with all local regulations which may prohibit leaving your engine

running when vehicle is unattended in a public place.

¾Always advise service personnel that your vehicle is equipped with a Remote Starter.

¾We strongly recommend that you have your Remote Starter checked annually.

Contact the dealer in your area.

BEFORE USING YOUR REMOTE STARTER

Before leaving your vehicle, set the various controls in order to use your Remote

Starter.

Set heating/air-conditioning to desired position. (When Remote Starter starts your

engine, it will also turn on your climate control system.)

Make sure:

¾windshield wipers are “OFF”.

¾gearshift is in PARK;

USING MAIN SWITCH

Main switch is usually installed under dashboard. It is

a toggle ON/OFF switch that is used to cancel start

functions only.

It does not disable other

commands which remain

active.

REMOTE CONTROL

Your remote control works off a small, long-life 12-volt alkaline battery (GP-23A) that

should last up to 6 months. Range of your remote control can be affected by a weak

battery, interference from nearby metal structures, hydro poles, or crowded parking lots.

With an electronic CODE LEARNING device, up to three additional remote controls can

be programmed for your vehicle. See your dealer for replacement batteries or additional

remote controls.

USING YOUR REMOTE CONTROL

(1-, 2- or 3-button remote)

To make sure that commands are transmitted properly, press desired button for 2

seconds. Indicator light will flash momentarily then remain on while transmitting

command. A command will not be transmitted properly if you do not press button long

enough (i.e., until indicator light goes out by itself).

Example: To start, press button "A” until indicator light goes out.

CONFIRMING COMMANDS

In most cases, your system will confirm that command has been received properly. This

will be done either by sounding horn (if horn was connected during installation) or

flashing parking lights. In this manual, confirmation signals are written in an abbreviated

form; for example:

(horn: 1, lights: 2) Means that horn will sound once and parking lights will flash twice.

RS-113 COMMAND CODES

Command 1 BT 2 BTS 3 BTS 4 BTS Confirmatio

Start/stop A A A 1A Lights

Activate Antitheft B 1B Lights

Lock B 1B Lights

Deactivate Antitheft C 1C Lights

Unlock C 1C Lights

Trunk release B&C 1B&C Lights

Sentinel mode B * A&B 1A&B Lights

Start only A&B * A&C 1A&C Lights, horn

Car finder A&B / A&C A&B / A&C Lights, horn

Controlled output A&B / A&C A&B / A&C Lights

Channels 2,3 and 4 on 4-button remote are not used on RS-113.

Confirmation of these commands can be programmed as ACTIVE or INACTIVE

during installation. When programmed as INACTIVE, there is no confirmation.

* Function “B” on 2-button remote control corresponds to command “A&B”.

* Function “A&B on 2-button remote control corresponds to command “A&C”.

Shaded areas correspond to options

that can be programmed during

installation. A maximum of two of

these commands can be selected;

see option list opposite. “Car finder”

and “Controlled output” functions

can be allocated to either of A&B or

A&C commands depending on

available options.

A&B

Sentinel

Controlled output

Car finder

A&C

Start only

Controlled output

Car finder

Start only

Car finder

Start only

Option 1 is programmed at factory. Ask your dealer if this option was changed during

installation and if so, check 9appropriate box.

START COMMANDS

STARTING AND STOPPING YOUR ENGINE

To start your engine, enter command from table (horn: 0, lights: 1). System

automatically sets ignition contact time depending on your vehicle. Parking lights will

stay on all the time engine is running.

To stop engine, enter same command.

Trigger input

Your Remote Starter is equipped with a negative trigger input. This input can

be connected to another remote control device or timer output. If this input is

connected, consult device manual or ask your technician which command is

associated with start/stop function. All start/stop functions controlled by this

input operate in same way as input controlled by remote control.

START ONLY

With horn confirmation.

Programmable as Active or Inactive during installation.

This command sounds the horn to confirm your vehicle has started when you cannot

see it. Enter command from table; if command has been received properly, you will get

a confirmation (horn: 1, lights: 1). Remote Starter will then send another message to

confirm that engine has started properly (horn: 2, lights: 1). Parking lights will remain on

all the time engine is running. You may repeat this command as often as you wish; it

does not stop engine.

CONTINUOUS MODE

Continuous Mode consists of sending a “Start” command while engine is already

running with key in ignition so that you can then remove ignition key.

This mode allows you to leave engine running when you leave vehicle for a short period

of time and also leaves heating/air-conditioning system on.

Enter a “Start” command while engine is running. Parking lights, engine and preset

accessories will stay on for programmed time. Remove key, exit vehicle and lock doors.

Steering column will be locked and all safety devices will remain active.

SENTINEL (LOW TEMPERATURE) MODE

Programmable as Active or Inactive during installation.

In Sentinel Mode, system can start your engine automatically when temperature falls

below -15ºC (5ºF). Engine will run for programmed time, after which Sentinel Mode will

wait 2½ hours and then start engine again if temperature is still below -15ºC (5ºF). All

actions that normally stop engine when it is started by remote control (applying brakes,

opening hood, etc.) have same effect in this mode.

To activate Sentinel Mode

Enter command from table (horn: 0, lights: 1).

Lights will flash once then, if temperature is below -15ºC (5ºF), engine will start

after a 4½-second pause. This pause lets you distinguish between a regular

start and an automatic (low temperature) start. If temperature is above -15ºC

(5ºF), Sentinel waits until it goes below -15ºC (5ºF) before starting. If system

cannot execute command (for example, hood is open), confirmation will be

different (horn: 0, lights: 3).

To deactivate this mode, enter command again (horn: 0, lights: 2).

UPON ENTERING YOUR VEHICLE ...

¾Do not apply brakes; this will turn off engine immediately.

¾Insert ignition key and turn it to “ON” position.

WARNING: DO NOT TURN IGNITION KEY TO “START” POSITION.

¾Drive as usual.

WHAT WILL STOP YOUR ENGINE

For your safety, engine will not start or will stop if:

¾Remote control sends a stop message.

¾Hood is open.

¾Brakes are applied.

¾Gearshift is not in “PARK” or “NEUTRAL”.

¾Engine exceeds 3000 rpm.

¾Main switch is OFF.

ANTITHEFT (STARTER DISABLE)

Programmable as Active or Inactive during installation.

Your Remote Starter is equipped with an ANTITHEFT system. This system consists of

an output that can control a relay to cut the starter circuit of your vehicle (optional

connections.)

The ANTITHEFT system activates automatically when ignition key is turned from “ON”

to “OFF” and stays off for at least one minute; it can also be activated manually by

sending “Activate ANTITHEFT” command (see table).

The ANTITHEFT system is deactivated for one minute when you send “Deactivate

ANTITHEFT” command (see table). If you do not start your vehicle during this one-

minute period, system reactivates automatically to prevent anyone from starting your

vehicle, even with ignition key.

The wiring can be connected so that horn goes off if someone tries to start your vehicle

when it is in ANTITHEFT ACTIVE mode.

OTHER COMMANDS

LOCKING AND UNLOCKING DOORS

If your vehicle is equipped with electric door locks, several functions can be operated by

remote control. These features are optional and may require purchasing additional

equipment. Consult your dealer for advice.

Following systems can be controlled:

¾door locks;

¾opening trunk or unlocking tailgate;

¾interior lights.

Locking doors

Enter “Lock” command from table (horn: 0, lights: 1) or ((horn: 0, lights: 0) ❁

programmable during installation).

Doors are locked and parking lights flash once to confirm command has been

received. ❁

Unlocking doors

Enter “Unlock” command from table (horn: 0, lights: 2) or ((horn: 0, lights: 0)

❁programmable during installation).

Doors are unlocked and parking lights flash twice to confirm command has

been received. ❁

Opening trunk and unlocking doors

This command opens trunk and unlocks doors (horn: 0, lights: 2) or ((horn: 0,

lights: 0) ❁programmable during installation).

Enter “Trunk release” command from table. Trunk is opened, doors are

unlocked, and parking lights flash twice to confirm command has been

received. ❁

❁If confirmation has been programmed as inactive during installation, there is

no confirmation.

If you are not sure you have received confirmation, repeat command. System

will repeat confirmation as often as you wish (if confirmation is programmed

as active.)

DOME LIGHT

Programmable as Active or Inactive during installation.

Dome light will turn on for 30 seconds every time “Unlock” command is sent. This 30-

second duration is cancelled when “Lock” command is sent or brakes are applied.

AUTOMATIC LOCK/UNLOCK

Programmable as Active or Inactive during installation.

This function locks doors when ignition key is in “ON” position, engine is running and

brakes are applied. Doors are unlocked when key is turned from “ON” to “OFF” or when

Continuous Mode is activated.

CAR FINDER

Programmable as Active or Inactive during installation.

This function sounds horn on and off and flashes parking lights to help you locate your

vehicle in a large parking lot or deter potential vehicle thieves or assailants by attracting

attention.

Enter command from table.

Car Finder Mode operates for one minute; you can, however, deactivate it before one

minute is up by repeating command or applying brakes.

CONTROLLED OUTPUT

Programmable as Active or Inactive during installation.

This command controls one of your vehicle’s accessories depending on which one was

connected during installation (headlights, defroster, etc.). For details, consult your

technician.

Enter command from table. Controlled output is activated for one second or one minute,

depending on initial programming. When output has been programmed for one minute,

you can deactivate it by repeating command.

ENGINE RUNTIME

Your engine will stop automatically after a preset time. Parking lights will stay on as long

as engine is running. Runtime is programmable during installation. Manufacturer preset

time is 15 minutes but you can have it changed to suit your needs.

IF ENGINE FAILS TO START

If your system cannot start your vehicle at first attempt, it will wait a few seconds and

then try again (it could try again twice depending on reason for failure to start), after

which it will shut down automatically and wait for new command.

SAFETY CHECKS

In order to maintain high safety standard, proceed with following routine checks every

month.

HOOD SWITCH

¾Start your vehicle with Remote Starter.

¾Open hood.

Engine should stop as soon as hood is opened.

If engine does not stop, first turn main switch to “OFF” position and leave it

“OFF” until situation is rectified; contact your local service center.

DETECTING “PARK” or “NEUTRAL” GEARSHIFT POSITION

Your starter is designed to check gearshift position at all times. Your vehicle

will not start or will stop if gearshift is not in “PARK” or “NEUTRAL”.

If your vehicle requires key to be in ignition in order to release gearshift, your

vehicle is safe as long as keys are kept away from children.

If gearshift can be put into gear without key in ignition,

proceed with following minor routine checks:

¾Put gearshift into gear.

¾Be ready to apply brakes.

¾Start your vehicle with Remote Starter.

¾Repeat these steps in “Drive” and “Reverse”.

If starter engages within ninety (90) seconds, first turn main switch to “OFF”

position and leave it “OFF” until situation is rectified; contact your local

service center.

REPLACING OR BOOSTING VEHICLE BATTERY

If you have to replace or boost battery for any reason, first turn main switch “OFF” and

leave it “OFF” until battery is replaced or fully charged.

Reversing polarity during this operation could permanently damage your Remote

Starter.

Table des matières

Autres manuels AstroStart Démarreur à distance

AstroStart

AstroStart R SS-5225 Manuel utilisateur

AstroStart

AstroStart AF-RFS2625 Manuel utilisateur

AstroStart

AstroStart series 1100 Manuel utilisateur

AstroStart

AstroStart RS-623 Manuel utilisateur

AstroStart

AstroStart 2504A Manuel utilisateur

AstroStart

AstroStart 2101 Manuel utilisateur

AstroStart

AstroStart RSS-2514XR Manuel utilisateur

AstroStart

AstroStart 2205U Manuel utilisateur

AstroStart

AstroStart RS-213 Manuel utilisateur

AstroStart

AstroStart 803M Manuel utilisateur

AstroStart

AstroStart STS-200 Manuel utilisateur

AstroStart

AstroStart 2305A Manuel utilisateur

AstroStart

AstroStart RS-655 Manuel utilisateur

AstroStart

AstroStart DSP611 Manuel utilisateur

AstroStart

AstroStart TS-100 Manuel utilisateur

AstroStart

AstroStart 1105U Manuel utilisateur

AstroStart

AstroStart 4204 Manuel utilisateur

AstroStart

AstroStart QS-1U Manuel utilisateur

AstroStart

AstroStart 2503 Manuel utilisateur

AstroStart

AstroStart RS-20X Manuel utilisateur

AstroStart

AstroStart DSP625 Manuel utilisateur

AstroStart

AstroStart 502 Manuel utilisateur

AstroStart

AstroStart RS-623 Manuel utilisateur

AstroStart

AstroStart RS-613 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel

Rooboost

Rooboost RB-1750WP Manuel utilisateur
