ASROCK Z97 Extreme9 Manuel utilisateur

Z97 Extreme9Z97 Extreme9

Version 1.1

Published October 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 7

1.4 I/O Panel 10

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 16

2.3 Installing Memory Modules (DIMM) 17

2.4 Expansion Slots (PCI Express Slots) 19

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

2.7 Smart Switches 26

2.8 Dr. Debug 27

2.9 SLITM , 3-Way SLITM , 4-Way SLITM and Quad SLITM Operation

Guide 29

2.9.1 Installing Two SLITM-Ready Graphics Cards 29

2.9.2 Installing Three SLITM-Ready Graphics Cards 31

2.9.3 Installing Four SLITM-Ready Graphics Cards 33

2.9.4 Driver Installation and Setup 35

2.10 CrossFireXTM, 3-Way CrossFireXTM, 4-Way CrossFireXTM and

Quad CrossFireXTM Operation Guide 36

2.10.1 Installing Two CrossFireXTM-Ready Graphics Cards 36

2.10.2 Installing Three CrossFireXTM-Ready Graphics Cards 37

2.10.3 Installing Four CrossFireXTM-Ready Graphics Cards 38

2.10.4 Driver Installation and Setup 39

2.11 M.2_SSD (NGFF) Module Installation Guide 40

2.12 HDD Saver Cable Installation Guide 43

2.13 Dual LAN and Teaming Operation Guide 44

Chapter 3 Software and Utilities Operation 45

3.1 Installing Drivers 45

3.2 A-Tuning 46

3.3 Intel® Rapid Start Technology 52

3.4 Intel® Smart Connect Technology 57

3.5 ASRock APP Shop 62

3.5.1 UI Overview 62

3.5.2 Apps 63

3.5.3 BIOS & Drivers 66

3.5.4 Setting 67

3.6 Start8 68

Chapter 4 UEFI SETUP UTILITY 71

4.1 Introduction 71

4.1.1 UEFI Menu Bar 71

4.1.2 Navigation Keys 72

4.2 Main Screen 73

4.3 OC Tweaker Screen 74

4.4 Advanced Screen 83

4.4.1 CPU Conguration 84

4.4.2 Chipset Conguration 86

4.4.3 Storage Conguration 88

4.4.4 Intel® Rapid Start Technology 90

4.4.5 Intel® Smart Connect Technology 91

4.4.6 Intel® ThunderboltTM 92

4.4.7 Super IO Conguration 93

4.4.8 ACPI Conguration 94

4.4.9 USB Conguration 96

4.4.10 Trusted Computing 98

4.5 Tools 99

4.6 Hardware Health Event Monitoring Screen 103

4.7 Boot Screen 104

4.8 Security Screen 107

4.9 Exit Screen 108

•

English

Z97 Extreme9

Chapter 1 Introduction

ank you for purchasing ASRock Z97 Extreme9 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock Z97 Extreme9 Motherboard (ATX Form Factor)

• ASRock Z97 Extreme9 Quick Installation Guide

• ASRock Z97 Extreme9 Support CD

• 1 x I/O Panel Shield

• 2 x ASRock SLI_Bridge Cards

• 1 x ASRock SLI_Bridge_3S Card

• 1 x ASRock 3-Way SLI Bridge Card

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x HDD Saver Cable

• 2 x Screws for M.2 Sockets

• 1 x Screw for mini-PCIe Slot

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• High Density Glass Fabric PCB

• Multiple Filter Cap (MFC) (Filter dierent noise by 3

dierent capacitors: DIP solid cap, POSCAP and MLCC)

CPU • Supports 5th Generation, New 4th and 4th Generation Intel®

CoreTM i7/i5/i3/Pentium®/Celeron® Processors (Socket 1150)

• Digi Power design

• 12 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

• Supports Intel® K-Series unlocked CPUs

• Supports ASRock BCLK Full-range Overclocking

Chipset • Intel® Z97

Memory • Dual Channel DDR3 Memory Technology

• 4 x DDR3 DIMM Slots

• Supports DDR3 3200+(OC)/2933+(OC)/2800(OC)/2400

(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-

buered memory

• Max. capacity of system memory: 32GB (see CAUTION1)

• Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

• 15 Gold Contact in DIMM Slots

Expansion

Slot

• 4 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE4/PCIE5:

single at x16 (PCIE1); dual at x16 (PCIE1) / x16 (PCIE4);

triple at x8 (PCIE1) / x8 (PCIE2) / x16 (PCIE4); quad at x8

(PCIE1) / x8 (PCIE2) / x8 (PCIE4) / x8 (PCIE5))

• 1 x PCI Express 2.0 x16 slot (PCIE3: x2 mode)

• 1 x mini-PCI Express Slot

• PLX PEX 8747 embedded

• Supports AMD Quad CrossFireXTM, 4-Way CrossFireXTM,

3-Way CrossFireXTM and CrossFireXTM

• Supports NVIDIA® Quad SLITM, 4-Way SLITM, 3-Way SLITM

and SLITM

• 15 Gold Contact in VGA PCIe Slot (PCIE1 and PCIE4)

English

Z97 Extreme9

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• Dual graphics output: Support HDMI and DiaplayPort 1.2

ports by independent display controllers

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2304) @ 24Hz

• Supports DisplayPort 1.2 with max. resolution up to 4K x 2K

(4096x2304) @ 24Hz or 4K x 2K (3840x2160) @ 60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI and DisplayPort 1.2 Ports

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

and DisplayPort 1.2 Ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek

ALC1150 Audio Codec)

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• Supports Purity SoundTM 2

- Nichicon Fine Gold Series Audio Caps

- 115dB SNR DAC with Dierential Amplier

- TI® NE5532 Premium Headset Amplier (Supports up to

600 Ohms headsets)

- Direct Drive Technology

- EMI Shielding Cover

- PCB Isolate Shielding

• Supports DTS Connect

English

LAN • Gigabit LAN 10/100/1000 Mb/s

• 1 x Giga PHY Intel® I218V, 1 x GigaLAN Intel® I211AT

• Supports Intel® Remote Wake Technology (on Intel® I218V)

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports Dual LAN with Teaming

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x HDMI Port

• 1 x DisplayPort 1.2

• 1 x Optical SPDIF Out Port

• 1 x eSATA Connector

• 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED

LED)

• 1 x Clear CMOS Switch

• HD Audio Jacks: Rear Speaker / Central / Bass / Line in /

Front Speaker / Microphone

Storage • 6 x SATA3 6.0 Gb/s Connectors by Intel® Z97, support RAID

(RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage

Technology 13 and Intel Smart Response Technology), NCQ,

AHCI, Hot Plug and ASRock HDD Saver Technology

• 4 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061,

support NCQ, AHCI, Hot Plug and ASRock HDD Saver

Technology (SATA3_A4 connector is shared with the eSATA

port)

• 2 x SATA Express Connectors (SATAE_2 is shared with

SATA3_1 and SATA3_2; SATAE_1 is shared with SATA3_4,

SATA3_5 and M.2 Socket (M2_2))

* Support to be announced

• 1 x eSATA Connector by ASMedia ASM1061, supports NCQ,

AHCI and Hot Plug

Autres manuels pour Z97 Extreme9

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK P55DE PRO - V1.0 Manuel utilisateur

ASROCK

ASROCK FM2A78M-ITX+ Manuel utilisateur

ASROCK

ASROCK IMB-181-D Manuel utilisateur

ASROCK

ASROCK 775XFIRE-ESATA2 - 02-2006 Manuel utilisateur

ASROCK

ASROCK H55M Manuel utilisateur

ASROCK

ASROCK 880GXH/USB3 Manuel utilisateur

ASROCK

ASROCK K10N7SLI Manuel utilisateur

ASROCK

ASROCK B75M-ITX Manuel utilisateur

ASROCK

ASROCK H67M Manuel utilisateur

ASROCK

ASROCK G41M-VS Manuel utilisateur

ASROCK

ASROCK B550M Steel Legend Manuel utilisateur

ASROCK

ASROCK X570 Phantom Gaming-ITX/TB3 Manuel utilisateur

ASROCK

ASROCK B150M-HDV/D3 Manuel utilisateur

ASROCK

ASROCK 939A785GMH Manuel utilisateur

ASROCK

ASROCK K10N78FULLHD-HSLI - R2.0 Manuel utilisateur

ASROCK

ASROCK A785GM-LE128M Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z370 Gaming K6 Series Manuel utilisateur

ASROCK

ASROCK A520M-HDV Manuel utilisateur

ASROCK

ASROCK P41C-DE Manuel utilisateur

ASROCK

ASROCK M3A760GMH - V1.0 Manuel utilisateur

ASROCK

ASROCK athena A2 Kit Manuel utilisateur

ASROCK

ASROCK H61M-PS Manuel utilisateur

ASROCK

ASROCK B660 Steel Legend Manuel utilisateur

ASROCK

ASROCK X299E-ITX/ac Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
