ASROCK IMB-183 Manuel utilisateur

IMB-183

User Manual

Version 1.0

Published December 2013

Version 1.0

Published December 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMITM and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

CAUTION:

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Contents

1 Introduction ....................................................... 5

1.1 Package Contents ......................................................... 5

................................................................. 6

1.3 Motherboard Layout....................................................... 8

1.4 I/O Panel........................................................................ 10

2 Installation ......................................................... 11

2.1 Screw Holes................................................................... 11

2.2 Pre-installation Precautions ........................................... 11

2.3 Installation of Memory Modules (SO-DIMM).................. 12

2.4 Expansion Slots ............................................................ 13

2.5 Jumpers Setup............................................................... 14

2.6 Onboard Headers and Connectors................................ 16

3 UEFI SETUP UTILITY......................................... 22

3.1 Introduction .................................................................... 22

3.1.1 UEFI Menu Bar .................................................... 22

3.1.2 Navigation Keys ................................................... 23

3.2 Main Screen................................................................... 23

3.3 Advanced Screen........................................................... 24

 ............................................... 25

........................................... 27

 .......................................... 29

3.3.4 Intel(R) Smart Connect Technology ..................... 30

 ........................................ 31

............................................... 32

 ............................................... 33

........................................... 34

3.4 Hardware Health Event Monitoring Screen ................... 35

3.5 Boot Screen ................................................................... 36

3.6 Security Screen ............................................................. 38

3.7 Exit Screen .................................................................... 39

4 Software Support .............................................. 40

4.1 Install Operating System................................................ 40

4.2 Support CD Information ................................................. 40

4.2.1 Running Support CD............................................ 40

4.2.2 Drivers Menu........................................................ 40

4.2.3 Utilities Menu........................................................ 40

4.2.4 Contact Information.............................................. 40

Chapter 1: Introduction

Thank you for purchasing ASRock IMB-183 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-



guide to BIOS setup and information of the Support CD.



updated, the content of this manual will be subject to change without no-





the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit



www.asrock.com/support/index.asp

1.1 Package Contents

ASRock IMB-183 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock IMB-183 Driver CD

ASRock IMB-183 Jumper setting instruction

1 x I/O Panel Shield



Form

Factor Dimensions Mini-ITX (6.7-in x 6.7-in)

Processor

System

CPU Socket LGA1150 for Intel®Core i7/i5/i3/Celeron

(Haswell)

Core

Number (By CPU, Max 4)

Max Speed (By CPU)

L3 Cache (By CPU)

Chipset H81

BIOS UEFI

Expansion

Slot

PCI 0

Mini-PCIe 1 (PCIe+USB)

mSATA 1 (SATA+USB)

PCIe 1 (x4)

CFast Card

Socket 0

Memory

Technology Dual Channel DDR3 1066/1333/1600 MHz

SDRAM

Max. 16GB

Socket 2 x SO-DIMM

Graphics

Controller Intel®HD Graphics (By CPU)

VRAM Shared Memory

VGA 0

LVDS 1

HDMI Supports HDMI 1.4a, max resolution 4096x2304

DVI-I 1

DisplayPort 0

Multi Display Yes (Dual Monitor)

Ethernet

Ethernet 10/100/1000 Mbps

Controller GbE LAN1: Intel®I217V

Connector 1 x RJ-45

SATA

Max Data

Transfer

Rate

2 x SATA3 (6.0Gb/s)

Rear I/O

VGA 0

DVI-I 1

HDMI 1

DisplayPort 0

Ethernet 1

USB 4 (2 x USB 3.0 compliant, 2 x USB 2.0

compliant)

Audio 2 (Mic-In, Line-Out)

eSATA 1

PS/2 0

Internal

Connector

USB 2 x USB 2.0 headers

LVDS/

Inverter 1

VGA 1

Serial 4 (RS-232)

SATA 2 x SATA3 (6.0Gb/s)

mPCIe 1

Parallel 0

mSATA 1

IrDA 0

GPIO 8-bit 4 x GPI + 4 x GPO

SATA PWR

Output Con 1

Speaker

Header 1

PS2

Keyboard/

Mouse

Header

DMIC

Header 1

HDMI_

SPDIF

Header

Customer

Solution

Header

Watchdog

Timer

Output Output from super I/O to drag RESETCON#

Interval 256 Segments, 0,1,2…255 Sec/Min

Power

Requirements

Input PWR DC 12-19 input

Power On

AT/ATX Supported

AT : Directly PWR on as power input ready

ATX : Press button to PWR on after power

input ready

Environment Temperature 0ºC – 60ºC

1.3 Motherboard Layout

Mic In

AUDIO

CODE C

BUZZ1

BIOS

Chip

USB8_9

HD_AUDIO1

IMB-183

2123

CI1

1 2 345678910 11 12 13 14

LVDS1

AMP _CT L1

JGPIO _PW R1

CPU_FA N1

PCIE1

JGPIO 1

DC_JACK1

mini-PCIe

SATA_ PWR 1

HDM I_ SPD IF1

CS1

TPM 1

USB4_5

PS2_K B_ MS1

VGA1

CLRCM OS1

CHA_FAN1

SPEAK ER1

USB 3.0

T: USB0

B: USB1

LAN1

USB 2.0

T: USB2

B: USB3

Line Out

DMI C1

UPS_I N1

mini-SATA

HDMI1

ESATA1

INT_DC1

BLT_ CTL 1

BKT_P WR1

PNL_P WR1

BLT_ PWM 1

HDL ED R ESE T

PLE D PW RBT N

PANE L1

CI2

SATA3 _2

SATA3 _1

VCCM_ SEL 1

Indust ri al

COM 1 COM2 CO M3 COM 4

1 1 11

PWR _JP 1

DVI1

JGP IO_ SET 1

1 :

2-pin UPS Module Power Input Connector

2 :

PS2 Keyboard/Mouse Header

3 : 4-pin ATX Power Input/Output Connector

4 :

USB2.0 Headers

(USB4_5, USB8_9)

5 : SATA3 Connectors (SATA3_1, SATA3_2)

6 : Digital Input / Output Pin Header

7 :

SATA Power Output Connector

8 : VCCM Power Selection

9 : Digital Input / Output Power Selection (JGPIO_PWR1)

10 : COM Port Header (COM1)

11 : COM Port Header (COM2)

12 : COM Port Header (COM3)

13 : COM Port Header (COM4)

14 :

System Panel Header

15 : LVDS Panel Connector

16 :

Panel Power Selection (PNL_PWR1)

17 : BLT_CTL1

18 : Backlight Power Selection (BKT_PWR1)

19 : Backlight Control Level (BLT_PWM1)

20 : Customer Solution Header

21 : ATX/AT Mode Selection

22 :

4-Pin CPU FAN Connector

23 : DMIC Header

24 : HDMI_SPDIF Header

25 : Clear CMOS Header

26 : 3W Audio AMP Output Wafer

27 :

Front Panel Audio Header

28 : TPM Header

29 : Speaker Control

30 : VGA Header

31 :

Digital Input / Output

Default Value Setting (JGPIO_SET1)

32 : Chassis Intrusion Headers

(CI1, CI2)

33 :

3-Pin Chassis FAN Connector

1.4 I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Off 100Mbps connection

On Link Green 1Gbps connection

ACT/LINK

LED

SPEED

LED

LAN Port

124

356789

1 DC Jack (DC_JACK1)

2 USB 3.0 Ports (USB3_01)

3 DVI-I Port (DVI1)

4 HDMI Port (HDMI1)

5 eSATA Port (ESATA1)

6 LAN RJ-45 Port*

7 USB 2.0 Ports (USB23)

8 Microphone (Pink)

9 Line out (Lime)

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK WOLFDALE1333-GLAN Manuel utilisateur

ASROCK

ASROCK 775Dual-VSTA Manuel utilisateur

ASROCK

ASROCK NUC-1215U Manuel utilisateur

ASROCK

ASROCK Fatal1ty X370 Gaming-ITX/ac Manuel utilisateur

ASROCK

ASROCK Phantom Gaming 4 Z690 Manuel utilisateur

ASROCK

ASROCK B760M Steel Legend WiFi Manuel utilisateur

ASROCK

ASROCK M3A790GXH/128M Manuel utilisateur

ASROCK

ASROCK X370 KILLER SLI Manuel utilisateur

ASROCK

ASROCK P4I45D Manuel utilisateur

ASROCK

ASROCK 939NF4G-SATA2 Manuel utilisateur

ASROCK

ASROCK X370 GAMING Manuel utilisateur

ASROCK

ASROCK G31M-VS Manuel utilisateur

ASROCK

ASROCK FM2A55M-HD Manuel utilisateur

ASROCK

ASROCK B85 Pro4 Manuel utilisateur

ASROCK

ASROCK P67 EXTREME6 - Manuel utilisateur

ASROCK

ASROCK RACK EP2C612D16C-4L Manuel utilisateur

ASROCK

ASROCK AM1H-ITX Manuel utilisateur

ASROCK

ASROCK B365 Pro4 Manuel utilisateur

ASROCK

ASROCK STX-1000 Manuel de service

ASROCK

ASROCK Fatal1ty FM2A88X+ Killer Series Manuel utilisateur

ASROCK

ASROCK E350M1 - Manuel utilisateur

ASROCK

ASROCK Q87M vPro Manuel utilisateur

ASROCK

ASROCK 770 Extreme3 Manuel utilisateur

ASROCK

ASROCK SuperAlloy Z170 Pro4S Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
