ASROCK H81 Pro BTC Manuel utilisateur

User Manual

Version 1.1

Published October 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMITM and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 9

1.5 I/O Panel 11

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 16

2.3 Installing Memory Modules (DIMM) 17

2.4 Expansion Slots (PCI Express Slots) 19

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

Chapter 3 Software and Utilities Operation 25

3.1 Installing Drivers 25

3.2 A-Tuning 26

3.3 Intel® Smart Connect Technology 30

3.4 Start8 35

Chapter 4 UEFI SETUP UTILITY 38

4.1 Introduction 38

4.1.1 UEFI Menu Bar 38

4.1.2 Navigation Keys 39

4.2 Main Screen 40

4.3 OC Tweaker Screen 41

4.4 Advanced Screen 49

4.4.1 CPU Conguration 50

4.4.2 Chipset Conguration 52

4.4.3 Storage Conguration 54

4.4.4 Intel® Smart Connect Technology 55

4.4.5 Super IO Conguration 56

4.4.6 ACPI Conguration 58

4.4.7 USB Conguration 60

4.4.8 Trusted Computing 61

4.5 Tools 62

4.6 Hardware Health Event Monitoring Screen 65

4.7 Boot Screen 66

4.8 Security Screen 69

4.9 Exit Screen 70

•

H81 Pro BTC

English

Chapter 1 Introduction

ank you for purchasing ASRock H81 Pro BTC motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock H81 Pro BTC Motherboard (ATX Form Factor)

• ASRock H81 Pro BTC Quick Installation Guide

• ASRock H81 Pro BTC Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• All Solid Capacitor design

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® in LGA1150 Package

• Digi Power design

• 4 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® H81

Memory • Dual Channel DDR3 Memory Technology

• 2 x DDR3 DIMM Slots

• Supports DDR3 1600/1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 16GB

(see CAUTION1)

• Supports Intel® Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)

• 5 x PCI Express 2.0 x1 Slots

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• Dual Graphics Output: support HDMI and D-Sub ports by

independent display controllers

• Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

H81 Pro BTC

English

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI Port

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Port

Audio • 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Realtek RealWoW! Technology

• Supports Wake-On-LAN

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x Serial Port: COM1

• 1 x Parallel Port (ECP/EPP support)

• 1 x D-Sub Port

• 1 x HDMI Port

• 2 x USB 2.0 Ports

• 2 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

• 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

English

Connector • 1 x IR Header

• 1 x COM Port Header

• 1 x Power LED Header

• 1 x TPM Header

• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 1 x Power Fan Connector (3-pin)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 2 x SLI/XFire Power Connectors

• 1 x Front Panel Audio Connector

• 1 x SPDIF Out Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

BIOS

Feature

• 32Mb AMI UEFI Legal BIOS with multilingual GUI support

• ACPI 1.1 Compliant wake up events

• SMBIOS 2.3.1 support

• CPU, DRAM, PCH 1.05V Voltage multi-adjustment

Support

• Drivers, Utilities, AntiVirus Soware (Trial Version), Google

Chrome Browser and Toolbar, Start8 (30 days trial)

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis/Power Fan Tachometer

• CPU Quiet Fan (Auto adjust chassis fan speed by CPU tem-

perature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-

bit / 7 32-bit / 7 64-bit

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

H81 Pro BTC

English

Please realize that there is a certain risk involved with overclocking, including adjust-

ing the setting in the BIOS, applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may aect your system’s stability, or even cause

damage to the components and devices of your system. It should be done at your own

risk and expense. We are not responsible for possible damage caused by overclocking.

Due to limitation, the actual memory size may be less than 4GB for the reservation for

system usage under Windows® 32-bit operating systems. Windows® 64-bit operating

systems do not have such limitations. You can use ASRock XFast RAM to utilize the

memory that Windows® cannot use.

English

1.3 Unique Features

ASRock A-Tuning

A-Tuning is ASRock’s multi purpose soware suite with a new interface, more new

features and improved utilities, including XFast RAM, Dehumidier, Good Night

LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM. is conve-

nient BIOS update tool allows you to update the system BIOS in a few clicks without

preparing an additional oppy diskette or other complicated ash utility. Just save

the new BIOS le to your USB storage and launch this tool by pressing <F6> or

<F2> during POST to enter the BIOS setup menu to access ASRock Instant Flash.

Please be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

ASRock APP Charger

Simply by installing the ASRock APP Charger makes your iPhone/iPad/iPod Touch

charge up to 40% faster than before on your computer. ASRock APP Charger allows

you to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Suspend to RAM

(S3), hibernation mode (S4) or power o (S5).

ASRock XFast LAN

ASRock XFast LAN provides faster internet access, which includes the benets

listed below. LAN Application Prioritization: You can congure your application’s

priority ideally and add new programs to the list. Lower Latency in Game: Aer

setting online game’s priority higher, it can lower the latency in games. Trac

Shaping: You can watch Youtube HD videos and download simultaneously. Real-

Time Analysis of Your Data: With the status window, you can easily recognize

which data streams you are currently transferring.

ASRock XFast RAM

ASRock XFast RAM is included in A-Tuning. It fully utilizes the memory space

that cannot be used under Windows® 32-bit operating systems. ASRock XFast RAM

shortens the loading time of previously visited websites, making web surng faster

than ever. And it also boosts the speed of Adobe Photoshop 5 times faster. Another

advantage of ASRock XFast RAM is that it reduces the frequency of accessing your

SSDs or HDDs in order to extend their lifespan.

Autres manuels pour H81 Pro BTC

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK AMD A620 Series Manuel utilisateur

ASROCK

ASROCK W480 Creator Manuel utilisateur

ASROCK

ASROCK N68-S3 FX Manuel utilisateur

ASROCK

ASROCK Super Alloy H110M-HDV Manuel utilisateur

ASROCK

ASROCK A75M-HVS Manuel utilisateur

ASROCK

ASROCK P55 DELUXE3 - Manuel utilisateur

ASROCK

ASROCK H81M-ITX/WiFi Manuel utilisateur

ASROCK

ASROCK PRO Series Manuel utilisateur

ASROCK

ASROCK A520M-HDVP/DASH Manuel utilisateur

ASROCK

ASROCK A785GM Manuel utilisateur

ASROCK

ASROCK IMB-181-D Manuel de service

ASROCK

ASROCK A785GXH 128M Manuel utilisateur

ASROCK

ASROCK B150M Pro4/D3 Manuel utilisateur

ASROCK

ASROCK H71M-DGS Manuel utilisateur

ASROCK

ASROCK X370M Pro4 R2.0 Manuel utilisateur

ASROCK

ASROCK G41M-PS Manuel utilisateur

ASROCK

ASROCK WOLFDALE1333-GLAN-M2 - V1.0 Manuel utilisateur

ASROCK

ASROCK 970M Pro3 Manuel utilisateur

ASROCK

ASROCK M3N78D FX Manuel utilisateur

ASROCK

ASROCK CONROE1333-DVI/H Manuel utilisateur

ASROCK

ASROCK P45DE3 Manuel utilisateur

ASROCK

ASROCK B150 Combo Manuel utilisateur

ASROCK

ASROCK H170M Pro4S Manuel utilisateur

ASROCK

ASROCK N68-GS Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
