ASROCK FM2A75 Pro4 Manuel utilisateur
1
FM2A75 Pro4
User Manual
Version 1.0
Published August 2012
Copyright©2012 ASRock INC. All rights reserved.
2
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock, its directors, ofcers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from
any defect or error in the manual or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in Cali-
fornia, USA, please follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com
3
Contents
1. Introduction ................................................................ 5
1.1 Package Contents ..................................................................... 5
1.2 Specications ............................................................................. 6
1.3 Unique Features ........................................................................ 10
1.4 Motherboard Layout ................................................................. 14
1.5 I/O Panel .................................................................................. 15
2. Installation .................................................................. 17
Pre-installation Precautions ................................................................ 17
2.1 CPU Installation ......................................................................... 18
2.2 Installation of CPU Fan and Heatsink ...................................... 18
2.3 Installation of Memory Modules (DIMM) .................................... 19
2.4 Expansion Slots (PCI and PCI Express Slots) ........................... 21
2.5 CrossFireXTM and Quad CrossFireXTM Operation Guide ............ 22
2.6 Dual Graphics Operation Guide ................................................ 26
2.7 Dual Monitor and Surround Display Features ........................... 28
2.8 ASRock Smart Remote Installation Guide ................................. 31
2.9 Jumpers Setup ........................................................................... 33
2.10 Onboard Headers and Connectors ....................................... 34
2.11 Smart Switches .......................................................................... 39
2.12 Dr. Debug .............................................................................. 40
2.13 Serial ATA3 (SATA3) Hard Disks Installation ......................... 44
2.14 Hot Plug and Hot Swap Functions for SATA3 HDDs ................. 44
2.15 SATA3 HDD Hot Plug and Hot SwapFeature and Operation
Operation Guide ........................................................................ 45
2.16 Driver Installation Guide ............................................................ 47
2.17 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit
With RAID Functions ................................................................. 47
2.18 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit
Without RAID Functions ............................................................ 48
4
3. UEFI SETUP UTILITY .................................................. 49
3.1 Introduction ................................................................................ 49
3.1.1 UEFI Menu Bar ................................................................ 49
3.1.2 Navigation Keys ............................................................... 50
3.2 Main Screen ............................................................................... 50
3.3 OC Tweaker Screen................................................................... 51
3.4 Advanced Screen ...................................................................... 55
3.4.1 CPU Conguration ........................................................... 56
3.4.2 North Bridge Conguration .............................................. 57
3.4.3 South Bridge Conguration ............................................. 58
3.4.4 Storage Conguration ...................................................... 59
3.4.5 Super IO Conguration .................................................... 60
3.4.6 ACPI Conguration .......................................................... 61
3.4.7 USB Conguration ........................................................... 63
3.4.8 Network Conguration ..................................................... 64
3.5 Tool ............................................................................................ 65
3.6 Hardware Health Event Monitoring Screen ............................... 67
3.7 Boot Screen ............................................................................... 69
3.8 Security Screen ......................................................................... 71
3.9 Exit Screen ................................................................................ 73
4. Software Support ....................................................... 74
4.1 Install Operating System ............................................................ 74
4.2 Support CD Information ............................................................. 74
4.2.1 Running Support CD ....................................................... 74
4.2.2 Drivers Menu ................................................................... 74
4.2.3 Utilities Menu ................................................................... 74
4.2.4 Contact Information ......................................................... 74
5
1. Introduction
Thank you for purchasing ASRock FM2A75 Pro4 motherboard, a reliable mother-
board produced under ASRock’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock’s commitment to
quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration
guide to BIOS setup and information of the Support CD.
Because the motherboard specications and the BIOS software might
be updated, the content of this manual will be subject to change without
notice. In case any modications of this manual occur, the updated ver-
sion will be available on ASRock website without further notice. You may
nd the latest VGA cards and CPU support lists on ASRock website as
well. ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock FM2A75 Pro4 Motherboard
(ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm)
ASRock FM2A75 Pro4 Quick Installation Guide
ASRock FM2A75 Pro4 Support CD
4 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield
ASRock Reminds You...
To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64
bit, it is recommended to set the BIOS option in Storage Conguration to
AHCI mode.
6
1.2 Specications
Platform - ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
- All Solid Capacitor design
CPU - Support for Socket FM2 100W processors
- 4 + 2 Power Phase Design
- Supports AMD’s Cool ‘n’ QuietTM Technology
- UMI-Link GEN2
Chipset - AMD A75 FCH (Hudson-D3)
Memory - Dual Channel DDR3 Memory Technology
- 4 x DDR3 DIMM slots
- Support DDR3 2600+(OC)/2400(OC)/2133(OC)/1866/1600/
1333/1066/800 non-ECC, un-buffered memory
(see CAUTION 1)
* 2600+ is only supported with two DIMMs
- Max. capacity of system memory: 64GB (see CAUTION 2)
- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2
- Supports AMD Memory Prole (AMP)
Expansion Slot - 2 x PCI Express 2.0 x16 slots
(PCIE2 @ x16 mode; PCIE4 @ x4 mode)
- 2 x PCI Express 2.0 x1 slots
- 3 x PCI slots
- Supports AMD Quad CrossFireXTM, CrossFireXTM and Dual
Graphics
Graphics - AMD Radeon HD 7000 graphics
- DirectX 11, Pixel Shader 5.0
- Max. shared memory 2GB
- Three VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
- Supports Dual-link DVI with max. resolution up to
2560x1600 @ 75Hz
- Supports D-Sub with max. resolution up to 1920x1600 @
60Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required) (see CAUTION 3)
- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a
- Supports AMD Steady VideoTM: New video post processing
capability for automatic jutter reduction on home/online
video
7
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with DVI and HDMI ports
Audio - 7.1 CH HD Audio with Content Protection
(Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
- Supports THX TruStudioTM
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efcient Ethernet 802.3az
- Supports PXE
Rear Panel I/O I/O Panel
- 1 x PS/2 Mouse/Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 2 x Ready-to-Use USB 2.0 Ports
- 1 x eSATA3 Connector
- 6 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- 1 x Clear CMOS Switch with LED
- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front
Speaker/Microphone
SATA3 - 5 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and “Hot Plug” functions
USB 3.0 - 2 x Rear USB 3.0 ports by AMD A75 FCH (Hudson-D3),
support USB 1.1/2.0/3.0 up to 5Gb/s
- 4 x Rear USB 3.0 ports by Etron EJ188, support
USB 1.1/2.0/3.0 up to 5Gb/s
- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by
AMD A75 FCH (Hudson-D3), supports USB 1.1/2.0/3.0 up
to 5Gb/s
Connector - 5 x SATA3 6.0Gb/s connectors
- 1 x IR header
- 1 x CIR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x Power LED header
8
- 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
- 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin)
- 1 x Power Fan connector (3-pin)
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
- 1 x USB 3.0 header (supports 2 USB 3.0 ports)
- 1 x Dr. Debug (7-Segment Debug LED)
- 1 x Power Switch with LED
- 1 x Reset Switch with LED
- 1 x Clear CMOS Switch with LED
BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support
- Supports “Plug and Play”
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- DRAM, VDDP, VDDR, SB Voltage Multi-adjustment
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial
Hardware - CPU Temperature Sensing
Monitor - Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- CPU/Chassis Fan Multi-Speed Control
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit
compliant
Certications - FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
* For detailed product information, please visit our website: http://www.asrock.com
9
WARNING
Please realize that there is a certain risk involved with overclocking,
including adjusting the setting in the BIOS, applying Untied Overclocking
Technology, or using third-party overclocking tools. Overclocking may
affect your system’s stability, or even cause damage to the components
and devices of your system. It should be done at your own risk and
expense. We are not responsible for possible damage caused by
overclocking.
CAUTION!
1. Whether 2600/2400/2133/1866/1600MHz memory speed is
supported depends on the CPU you adopt. If you want to adopt
DDR3 2600/2400/2133/1866/1600 memory module on this
motherboard, please refer to the memory support list on our
website for the compatible memory modules.
ASRock website http://www.asrock.com
2. Due to the operating system limitation, the actual memory size
may be less than 4GB for the reservation for system usage
under Windows® 7 / VistaTM. For Windows® 64-bit OS with 64-
bit CPU, there is no such limitation. You can use ASRock XFast
RAM to utilize the memory that Windows® cannot use.
3. xvYCC and Deep Color are only supported under Windows® 7
64-bit / 7. Deep Color mode will be enabled only if the display
supports 12bpc in EDID. HBR is supported under Windows® 7
64-bit / 7 / VistaTM 64-bit / VistaTM.
10
1.3 Unique Features
ASRock Extreme Tuning Utility (AXTU)
ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to
ne-tune different system functions in a user-friendly interface,
which includes Hardware Monitor, Fan Control, Overclocking,
OC DNA, IES and XFast RAM. In Hardware Monitor, it shows
the major readings of your system. In Fan Control, it shows the
fan speed and temperature for you to adjust. In Overclocking,
you are allowed to overclock CPU frequency for optimal system
performance. In OC DNA, you can save your OC settings as
a prole and share it with your friends. Your friends then can
load the OC prole to their own system to get the same OC set-
tings. In IES (Intelligent Energy Saver), the voltage regulator
can reduce the number of output phases to improve efciency
when the CPU cores are idle without sacricing computing per-
formance. In XFast RAM, it fully utilizes the memory space that
cannot be used under Windows® OS 32-bit CPU.
ASRock Instant Boot
ASRock Instant Boot allows you to turn on your PC in just a few
seconds, provides a much more efcient way to save energy,
time, money, and improves system running speed for your sys-
tem. It leverages the S3 and S4 ACPI features which normally
enable the Sleep/Standby and Hibernation modes in Windows®
to shorten boot up time. By calling S3 and S4 at specic timing
during the shutdown and startup process, Instant Boot allows
you to enter your Windows® desktop in a few seconds.
ASRock Instant Flash
ASRock Instant Flash is a BIOS ash utility embedded in Flash
ROM. This convenient BIOS update tool allows you to update
system BIOS without entering operating systems rst like MS-
DOS or Windows®. With this utility, you can press the <F6> key
during the POST or the <F2> key to enter into the BIOS setup
menu to access ASRock Instant Flash. Just launch this tool and
save the new BIOS le to your USB ash drive, oppy disk or
hard drive, then you can update your BIOS only in a few clicks
without preparing an additional oppy diskette or other compli-
cated ash utility. Please be noted that the USB ash drive or
hard drive must use FAT32/16/12 le system.
Autres manuels pour FM2A75 Pro4
2
Table des matières
Autres manuels ASROCK Carte mère
ASROCK
ASROCK P45X3 DELUXE - Manuel utilisateur
ASROCK
ASROCK 939A790GMH Manuel utilisateur
ASROCK
ASROCK DeskMini B660 Manuel utilisateur
ASROCK
ASROCK Z87 Extreme9/ac Manuel utilisateur
ASROCK
ASROCK K8S8X Manuel utilisateur
ASROCK
ASROCK Z170 Extreme7+ Manuel utilisateur
ASROCK
ASROCK TRX50 WS Manuel utilisateur
ASROCK
ASROCK CONROEXFIRE-ESATA2 Manuel utilisateur
ASROCK
ASROCK FM2A58M-HD+ R2.0 Manuel utilisateur
ASROCK
ASROCK ALIVENF5-VSTA Manuel utilisateur
ASROCK
ASROCK N68C-GS UCC - Manuel utilisateur
ASROCK
ASROCK 939SLI-ESATA2 Manuel utilisateur
ASROCK
ASROCK G31M-VS2 Manuel utilisateur
ASROCK
ASROCK H55M-GE Manuel utilisateur
ASROCK
ASROCK ATW-HC2260 Manuel utilisateur
ASROCK
ASROCK 890GMH/USB3 Manuel utilisateur
ASROCK
ASROCK ALIVENF4G-DVI Manuel utilisateur
ASROCK
ASROCK K10N78 - V1.1 Manuel utilisateur
ASROCK
ASROCK Fatal1ty Z77 Professional Manuel de l'opérateur
ASROCK
ASROCK A780GMH-128M Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
Biostar
Biostar M7VIT Bravo Instructions d'utilisation et d'installation
