ASROCK FM2A75 PRO04+ Manuel utilisateur

User Manual

Version 1.0

Published August 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction ................................................................ 1

1.1 Package Contents ..................................................................... 1

 1.2 Specications............................................................................. 2

1.3 Unique Features ........................................................................ 6

1.4 Motherboard Layout ................................................................. 11

1.5 I/O Panel .................................................................................. 13

2. Installation .................................................................. 15

Pre-installation Precautions ................................................................ 15

2.1 CPU Installation ......................................................................... 16

2.2 Installation of CPU Fan and Heatsink ...................................... 17

2.3 Installation of Memory Modules (DIMM) .................................... 18

2.4 Expansion Slots (PCI and PCI Express Slots)........................... 20

2.5 Jumpers Setup........................................................................... 21

2.6 Onboard Headers and Connectors ....................................... 22

2.7 CrossFireXTM and Quad CrossFireXTM Operation Guide............ 27

2.8 Dual Graphics Operation Guide ................................................ 30

3. Software and Utilities Operation............................... 32

3.1 Installing Drivers ........................................................................ 32

3.2 A-Tuning .................................................................................... 33

3.3 Qualcomm®Atheros®Security Wake On Internet Technology .. 37

3.4 Start8 ......................................................................................... 44

4. UEFI SETUP UTILITY.................................................. 47

4.1 Introduction ................................................................................ 47

4.1.1 UEFI Menu Bar................................................................ 47

4.1.2 Navigation Keys............................................................... 48

4.2 Main Screen............................................................................... 48

4.3 OC Tweaker Screen................................................................... 49

4.4 Advanced Screen ...................................................................... 52

  4.4.1 CPUConguration........................................................... 53

  4.4.2 NorthBridgeConguration .............................................. 54

  4.4.3 SouthBridgeConguration ............................................. 55

  4.4.4 StorageConguration...................................................... 56

  4.4.5 SuperIOConguration.................................................... 57

  4.4.6 ACPIConguration.......................................................... 58

  4.4.7 USBConguration........................................................... 60

4.4.8 Trusted Computing .......................................................... 61

4.5 Tool ............................................................................................ 62

4.6 Hardware Health Event Monitoring Screen ............................... 65

4.7 Boot Screen ............................................................................... 66

4.8 Security Screen ......................................................................... 68

4.9 Exit Screen ................................................................................ 69

1. Introduction

Thank you for purchasing ASRock FM2A75 Pro4+ motherboard, a reliable moth-

erboard produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

softwareandutilities.Chapter4containsthecongurationguideoftheBIOSsetup.

 Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice.Incaseanymodicationsofthismanualoccur,theupdatedver-

sion will be available on ASRock website without further notice. You may

ndthelatestVGAcards and CPU support listsonASRockwebsiteas

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

ourwebsiteforspecicinformationaboutthemodelyouareusing.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A75 Pro4+ Motherboard (ATX Form Factor)

ASRock FM2A75 Pro4+ Quick Installation Guide

ASRock FM2A75 Pro4+ Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®8 / 8 64-bit / 7 / 7 64-bit, it is

recommendedtosettheBIOSoptioninStorageCongurationtoAHCI

mode.

1.2 Specications

Platform - ATX Form Factor

- All Solid Capacitor design

A-Style - Home Cloud

CPU - Supports Socket FM2+ 95W / FM2 100W processors

- 4 + 2 Power Phase design

Chipset - AMD A75 FCH (Hudson-D3)

Memory - Dual Channel DDR3 Memory Technology

- 4 x DDR3 DIMM Slots

- Supports DDR3 2600+(OC)/2400(OC)/2133/1866/1600/

1333/1066 non-ECC, un-buffered memory (see CAUTION 1)

* DDR3 2600+ is only supported with two DIMMs.

- Max. capacity of system memory: 64GB (see CAUTION 2)

- Supports Intel®ExtremeMemoryProle(XMP)1.3/1.2

 -SupportsAMDMemoryProle(AMP)

Expansion Slot - 1 x PCI Express 3.0 x16 Slot (PCIE2 @ x16 mode)

* PCIE 3.0 is only supported with FM2+ CPU. With FM2

CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x16 Slot (PCIE4 @ x4 mode)

- 2 x PCI Express 2.0 x1 Slots

- 3 x PCI Slots

- Supports AMD Quad CrossFireXTM, CrossFireXTM and Dual

Graphics

Graphics - Integrated AMD Radeon HD 8000/7000 series graphics in

A-series APU

- DirectX 11.1, Pixel Shader 5.0with FM2+ CPU. DirectX 11,

Pixel Shader 5.0 with FM2 CPU.

- Max. shared memory 2GB

 -ThreeVGAoutputoptions:D-Sub,DVI-DandHDMIPorts

- Supports Triple Monitor

- Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

 -SupportsDual-linkDVI-Dwithmax.resolutionupto

2560x1600 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI

monitor is required) (see CAUTION 3)

- Supports Blu-ray Stereoscopic 3D with HDMI Port

 -SupportsAMDSteadyVideoTM 2.0: New video post

processing capability for automatic jitter reduction on

home/online video

 -SupportsHDCPwithDVI-DandHDMIPorts

 -SupportsFullHD1080pBlu-ray(BD)playbackwithDVI-D

and HDMI Ports

Audio - 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

- Premium Blu-ray Audio support

- TI®NE5532PremiumHeadsetAmplier(Supportsupto600

ohm headsets)

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Qualcomm®Atheros®AR8171

- Supports Qualcomm®Atheros®Security Wake On Internet

Technology

- Supports Wake-On-LAN

 -SupportsEnergyEfcientEthernet802.3az

- Supports PXE

Rear Panel I/O - 1 x PS/2 Mouse/Keyboard Port

- 1 x D-Sub Port

 -1xDVI-DPort

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 6 x USB 2.0 Ports

- 1 x eSATA Connector

- 2 x USB 3.0 Ports (AMD A75 FCH (Hudson-D3))

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- 1 x Clear CMOS Switch with LED

- HD Audio Jacks: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone

Storage - 5 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

Connector - 1 x IR Header

- 1 x COM Port Header

- 1 x Chassis Intrusion Header

- 1 x TPM Header

- 1 x Power LED Header

- 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

- 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)

- 1 x Power Fan Connector (3-pin)

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

- 1 x 24 pin ATX Power Connector

 -1x8pin12VPowerConnector

- 1 x Front Panel Audio Connector

- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

- 1 x USB 3.0 Header by AMD A75 FCH (Hudson-D3)

(Supports 2 USB 3.0 ports)

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 compliance wake up events

- Supports jumperfree

- SMBIOS 2.3.1 support

 -DRAM,VDDP,VDDRVoltagemulti-adjustment

Support CD -Drivers,Utilities,AntiVirusSoftware(TrialVersion),

CyberLink MediaEspresso 6.5 Trial, Google Chrome

Browser and Toolbar, Start8 (30 days trial)

Hardware - CPU temperature sensing

Monitor - Chassis temperature sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan multi-speed control

- CASE OPEN detection

 -Voltagemonitoring:+12V,+5V,+3.3V,Vcore

OS - Microsoft® Windows®8.1 32-bit / 8.1 64-bit / 8 32-bit /

8 64-bit / 7 32-bit / 7 64-bit

Certications - FCC, CE, WHQL

- ErP/EuP ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. Whether 2600/2400/2133/1866/1600MHz memory speed is

supported depends on the CPU you adopt. If you want to adopt

DDR3 2600/2400/2133/1866/1600 memory module on this

motherboard, please refer to the memory support list on our

website for the compatible memory modules.

ASRock website http://www.asrock.com

2. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage un-

der Windows®8 / 7. For Windows®64-bit OS with 64-bit CPU,

there is no such limitation. You can use ASRock XFast RAM to

utilize the memory that Windows®cannot use.

3. xvYCC and Deep Color are only supported under Windows®8

64-bit / 8 / 7 64-bit / 7. Deep Color mode will be enabled only

if the display supports 12bpc in EDID. HBR is supported under

Windows®8 64-bit / 8 / 7 64-bit / 7.

1.3 Unique Features

ASRock A-Tuning

A-Tuning is ASRock’s multi purpose software suite with a new

interface, more new features and improved utilities, including

XFast RAM, Dehumidier, Good Night LED, FAN-Tastic Tun-

ing, OC Tweaker and a whole lot more.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more efcient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows®

toshortenbootuptime.BycallingS3andS4atspecictiming

during the shutdown and startup process, Instant Boot allows

you to enter your Windows®desktop in a few seconds.

ASRock Instant Flash

 ASRockInstantFlashisaBIOSashutilityembeddedinFlash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems rst like MS-

DOS or Windows®. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

savethe new BIOSletoyour USB ash drive,oppydisk or

hard drive, then you can update your BIOS only in a few clicks

withoutpreparing anadditionaloppy diskette orother compli-

cated ash utility. Please be noted that the USB ash drive or

harddrivemustuseFAT32/16/12lesystem.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK FM2A85X Pro Manuel utilisateur

ASROCK

ASROCK P45TS-R Manuel utilisateur

ASROCK

ASROCK B560M-HDV/M.2 Manuel utilisateur

ASROCK

ASROCK EP2C622D24LM Manuel utilisateur

ASROCK

ASROCK H61M-DP3 Manuel utilisateur

ASROCK

ASROCK Z590M Phantom Gaming 4 Manuel utilisateur

ASROCK

ASROCK H81M-HDS R2.0 Manuel utilisateur

ASROCK

ASROCK Z77 Extreme9 Manuel utilisateur

ASROCK

ASROCK IMB-A180-H Manuel utilisateur

ASROCK

ASROCK Z590 Phantom Gaming 4/ac Manuel utilisateur

ASROCK

ASROCK H55M-USB3 - V1.0 Manuel utilisateur

ASROCK

ASROCK K8UPGRADE-NF3 Manuel utilisateur

ASROCK

ASROCK H81M Manuel utilisateur

ASROCK

ASROCK A68M-ITX Manuel utilisateur

ASROCK

ASROCK EPC602D8A Manuel utilisateur

ASROCK

ASROCK Z790 LiveMixer Manuel utilisateur

ASROCK

ASROCK N68-VGS3 FX Manuel utilisateur

ASROCK

ASROCK ALIVENF5-VSTA R2.0 Manuel utilisateur

ASROCK

ASROCK Z97M-ITX/ac Manuel utilisateur

ASROCK

ASROCK P5B-DE Manuel utilisateur

ASROCK

ASROCK Q1900TM-ITX Manuel utilisateur

ASROCK

ASROCK K8 COMBO-Z Manuel utilisateur

ASROCK

ASROCK X299 Steel Legend Manuel utilisateur

ASROCK

ASROCK Z170 Pro4 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
