ASROCK B150 PRO4/D3 Manuel utilisateur

B150 Pro4/D3

User Manual

Version 1.0

Published June 2015

Version 1.0

Published June 2015

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

Chapter 2 Installation 10

2.1 Installing the CPU 11

2.2 Installing the CPU Fan and Heatsink 14

2.3 Installing Memory Modules (DIMM) 15

2.4 Expansion Slots (PCI Express Slots) 17

2.5 Jumpers Setup 18

2.6 Onboard Headers and Connectors 19

2.7 CrossFireXTM and Quad CrossFireXTM Operation Guide 23

2.7.1 Installing Two CrossFireXTM-Ready Graphics Cards 23

2.7.2 Driver Installation and Setup 25

Chapter 3 Software and Utilities Operation 26

3.1 Installing Drivers 26

3.2 ASRock Live Update & APP Shop 27

3.2.1 UI Overview 27

3.2.2 Apps 28

3.2.3 BIOS & Drivers 31

3.2.4 Setting 32

3.3 Enabling USB Ports for Windows® 7 Installation 33

Chapter 4 UEFI SETUP UTILITY 36

4.1 Introduction 36

4.1.1 UEFI Menu Bar 36

4.1.2 Navigation Keys 37

4.2 Main Screen 38

4.3 OC Tweaker Screen 39

4.4 Advanced Screen 47

4.4.1 CPU Conguration 48

4.4.2 Chipset Conguration 50

4.4.3 Storage Conguration 52

4.4.4 Super IO Conguration 53

4.4.5 ACPI Conguration 54

4.4.6 USB Conguration 56

4.4.7 Trusted Computing 57

4.5 Tools 58

4.6 Hardware Health Event Monitoring Screen 61

4.7 Security Screen 62

4.8 Boot Screen 63

4.9 Exit Screen 66

PB 1

English

B150 Pro4/D3

Chapter 1 Introduction

ank you for purchasing ASRock B150 Pro4/D3 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock B150 Pro4/D3 Motherboard (ATX Form Factor)

• ASRock B150 Pro4/D3 Quick Installation Guide

• ASRock B150 Pro4/D3 Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

2 3

English

1.2 Specications

Platform • ATX Form Factor

• Solid Capacitor design

• High Density Glass Fabric PCB

CPU • Supports 6th Generation Intel® CoreTM i7/i5/i3/Pentium®/

Celeron® Processors (Socket 1151)

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® B150

• Supports Intel® Small Business Advantage 4.0

Memory • Dual Channel DDR3/DDR3L Memory Technology

• 4 x DDR3/DDR3L DIMM Slots

• Supports DDR3/DDR3L 1600/1333/1066 non-ECC, un-

buered memory

• Supports ECC UDIMM memory modules (operate in non-

ECC mode)

• Max. capacity of system memory: 64GB

• Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

Expansion

Slot

• 2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4

mode)

• 3 x PCI Express 3.0 x1 Slots (Flexible PCIe)

• Supports AMD Quad CrossFireXTM and CrossFireXTM

Graphics * Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• - Supports Intel® HD Graphics Built-in Visuals : Intel®

Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 510/530

• Pixel Shader 5.0, DirectX 12

• Max. shared memory 1792MB

• Dual graphics output: Support DVI-D and HDMI ports by

independent display controllers

2 3

English

B150 Pro4/D3

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2304) @ 24Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port

(Compliant HDMI monitor is required)

• Supports Accelerated Media Codecs: HEVC, VP8, VP9

• Supports HDCP with DVI-D and HDMI Ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI Ports

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wa ke- On-WAN

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x DVI-D Port

• 1 x HDMI Port

4 5

English

• 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage • 6 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

Connector • 1 x COM Port Header

• 1 x TPM Header

• 1 x Power LED and Speaker Header

• 1 x CPU Fan Connector (4-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

* e CPU Fan Connector supports the CPU fan of maxi-

mum 1A (12W) fan power.

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

BIOS

Feature

• 128Mb AMI UEFI Legal BIOS with multilingual GUI sup-

port

• ACPI 1.1 Compliant wake up events

• SMBIOS 2.3.1 Support

• CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCSA

Voltage Multi-adjustment

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

4 5

English

B150 Pro4/D3

OS • Microso® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-

bit

* To install Windows® 7 OS, a modied installation disk with

xHCI drivers packed into the ISO le is required. Please refer to

page 33 for more detailed instructions.

* For the updated Windows® 10 driver, please visit ASRock's

website for details: http://www.asrock.com

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

* For detailed product information, please visit our website: http://www.asrock.com

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK CONROE1333-ESATA2 - V1.0 Manuel utilisateur

ASROCK

ASROCK Fatal1ty H97 Performance Series Manuel utilisateur

ASROCK

ASROCK 939Dual-VSTA Manuel utilisateur

ASROCK

ASROCK Taichi Carrara X670E Manuel utilisateur

ASROCK

ASROCK Industrial 4x4 R1000 Mode d’emploi

ASROCK

ASROCK H97M Anniversary Manuel utilisateur

ASROCK

ASROCK B550M-HDV Manuel utilisateur

ASROCK

ASROCK QC5000M-ITX/PH Manuel utilisateur

ASROCK

ASROCK Z87 Extreme4 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z370 Gaming K6 Series Manuel utilisateur

ASROCK

ASROCK B365M Pro4-F Manuel utilisateur

ASROCK

ASROCK 880GMH USB3 R2.0 Manuel utilisateur

ASROCK

ASROCK Fatal1ty B150 Gaming K4 Manuel utilisateur

ASROCK

ASROCK E3C224D41-14S Manuel utilisateur

ASROCK

ASROCK A75 Extreme6 Manuel utilisateur

ASROCK

ASROCK H77M-ITX Manuel utilisateur

ASROCK

ASROCK 880G Pro3 Manuel utilisateur

ASROCK

ASROCK N68- S Manuel utilisateur

ASROCK

ASROCK 775i915P-SATA2 Manuel utilisateur

ASROCK

ASROCK P4VM890 - V1.1 Manuel utilisateur

ASROCK

ASROCK H110TM-ITX Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z97 Manuel utilisateur

ASROCK

ASROCK B75M-DGS R2.0 Manuel utilisateur

ASROCK

ASROCK H61M-GE Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
