AD2700B-ITX /

AD2500B-ITX

User Manual

Version 1.0

Published October 2011

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identi cation or explanation and to the owners’ bene t, without intent to infringe.

Disclaimer:

Speci cations and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, of cers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of pro ts, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction......................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Speci cations................................................................. 6

1.3 Motherboard Layout (AD2700B-ITX) ............................. 11

1.4 Motherboard Layout (AD2500B-ITX) ............................. 12

1.5 I/O Panel (AD2700B-ITX) ............................................ 13

1.6 I/O Panel (AD2500B-ITX) ............................................ 14

2 Installation........................................................... 15

2.1 Screw Holes................................................................... 15

2.2 Pre-installation Precautions ......................................... 15

2.3 Installation of Memory Modules (SO-DIMM).................. 16

2.4 Expansion Slot (PCI Slot) ................................................ 17

2.5 ASRock Smart Remote Installation Guide ..................... 18

2.6 Jumpers Setup .......................................................... 19

2.7 Onboard Headers and Connectors ............................ 20

2.8 Serial ATA (SATA) / Serial ATA2 (SATA2) Hard Disks

Installation .................................................................. 23

2.9 Hot Plug and Hot Swap Functions for SATA / SATA2

HDDs ............................................................................ 23

2.10 SATA / SATA2 HDD Hot Plug Feature and Operation

Guide ......................................................................... 24

2.11 Driver Installation Guide ............................................. 26

2.12 Installing Windows®7 on SATA / SATAII HDDs ........ 26

3 UEFI SETUP UTILITY ................................................. 27

3.1 Introduction .................................................................... 27

3.1.1 UEFI Menu Bar .................................................... 27

3.1.2 Navigation Keys ................................................... 28

3.2 Main Screen................................................................... 28

3.3 Advanced Screen........................................................... 30

3.3.1 CPU Con guration ............................................... 31

3.3.2 Chipset Con guration........................................... 32

3.3.3 Storage Con guration .......................................... 33

3.3.4 Super IO Con guration ........................................ 34

3.3.5 ACPI Con guration............................................... 35

3.3.6 USB Con guration ............................................... 36

3.3.7 Voltage Con guration........................................... 37

3.4 Hardware Health Event Monitoring Screen ................... 38

3.5 Boot Screen ................................................................... 39

3.6 Security Screen ............................................................. 40

3.7 Exit Screen .................................................................... 41

4 Software Support................................................. 42

4.1 Install Operating System................................................ 42

4.2 Support CD Information ................................................. 42

4.2.1 Running Support CD............................................ 42

4.2.2 Drivers Menu........................................................ 42

4.2.3 Utilities Menu........................................................ 42

4.2.4 Contact Information.............................................. 42

Chapter 1: Introduction

Thank you for purchasing ASRock AD2700B-ITX / AD2500B-ITX motherboard, a

reliable motherboard produced under ASRock’s consistently stringent quality con-

trol. It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the con guration

guide to BIOS setup and information of the Support CD.

Because the motherboard speci cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock AD2700B-ITX / AD2500B-ITX Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock AD2700B-ITX / AD2500B-ITX Quick Installation Guide

ASRock AD2700B-ITX / AD2500B-ITX Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

1.2 Specifications

Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm

- All Solid Capacitor design (AD2700B-ITX)

- Solid Capacitor for CPU power (AD2500B-ITX)

CPU - Intel®Dual-Core AtomTM Processor D2700 (2.13 GHz)

(AD2700B-ITX)

- Intel®Dual-Core AtomTM Processor D2500 (1.86 GHz)

(AD2500B-ITX)

- Supports Hyper-Threading Technology (AD2700B-ITX)

(see CAUTION 1)

Chipset - Southbridge: Intel®NM10 Express

Memory - 2 x DDR3 SO-DIMM slots

- Supports DDR3 1066/800 non-ECC, un-buffered

memory

- Max. capacity of system memory: 4GB (see CAUTION 2)

Expansion Slot - 1 x PCI slot

Graphics - Intel®PowerVR SGX545

- DirectX 9.0, Pixel Shader 3.0

- Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

Audio - 5.1 CH HD Audio (VIA®VT1705 Audio Codec)

LAN (AD2700B-ITX) - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef cient Ethernet 802.3az

- Supports PXE

LAN (AD2500B-ITX) - Realtek PCIE x1 LAN RTL8105E

- Speed: 10/100 Ethernet

- Supports Wake-On-LAN

- Supports PXE

Rear Panel I/O I/O Panel

(AD2700B-ITX) - 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Parallel Port (ECP/EPP Support)

- 1 x Serial Port: COM1

- 1 x VGA Port

- 2 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

Rear Panel I/O I/O Panel

(AD2500B-ITX) - 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Parallel Port (ECP/EPP Support)

- 1 x Serial Port: COM1

- 1 x VGA Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

USB 3.0 - 2 x USB 3.0 ports by ASMedia ASM1042, support USB

(AD2700B-ITX) 1.0/2.0/3.0 up to 5Gb/s

Connector - 2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

Hot Plug functions

- 1 x IR header

- 1 x CIR header

- CPU/Chassis FAN connector

- 24 pin ATX power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature - 16Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock Software Suite

(CyberLink DVD Suite - OEM and Trial; Creative Sound

Blaster X-Fi MB - Trial; ASRock MAGIX Multimedia Suite -

OEM)

Unique Feature - ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 3)

- ASRock APP Charger (see CAUTION 4)

- ASRock SmartView (see CAUTION 5)

- ASRock XFast USB (see CAUTION 6)

- ASRock XFast LAN (see CAUTION 7)

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 8)

- ASRock U-COP (see CAUTION 9)

- Boot Failure Guard (B.F.G.)

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU/Chassis Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft® Windows® 7 32-bit compliant

Certiﬁcations - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 10)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. About the setting of “Hyper Threading Technology”, please check page

31.

2. Due to the chipset limitation, the actual memory size may be less than

4GB for the reservation for system usage under Windows®OS.

3. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems rst like MS-DOS or Windows®. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS le to your USB ash drive,

oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional oppy diskette or other complicated

ash utility. Please be noted that the USB ash drive or hard drive must

use FAT32/16/12 le system.

4. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply install the APP Charger

driver, it makes your iPhone charge much quickly from your computer and

up to 40% faster than before. ASRock APP Charger allows you to quickly

charge many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1), Suspend to

RAM (S3), hibernation mode (S4) or power off (S5). With APP Charger

driver installed, you can easily enjoy the marvelous charging experience.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

5. ASRock SmartView, a new function for internet browsers, is the smart

start page for IE that combines your most visited web sites, your history,

your Facebook friends and your real-time newsfeed into an enhanced

view for a more personal Internet experience. ASRock motherboards are

exclusively equipped with the ASRock SmartView utility that helps you

keep in touch with friends on-the-go. To use ASRock SmartView feature,

please make sure your OS version is Windows®7, and your browser ver-

sion is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

6. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the properties of the device.

7. ASRock XFast LAN provides a faster internet access, which includes

the bene ts listed below. LAN Application Prioritization: You can con g-

ure your application’s priority ideally and/or add new programs. Lower

Latency in Game: After setting online game’s priority higher, it can lower

the latency in games. Traf c Shaping: You can watch Youtube HD videos

and download simultaneously. Real-Time Analysis of Your Data: With

the status window, you can easily recognize which data streams you are

transferring currently.

8. Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause instability of the system or damage the CPU.

9. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

10. EuP stands for Energy Using Product, was a provision regulated by the

European Union to de ne the power consumption for the completed sys-

tem. According to EuP, the total AC power of the completed system

should be under 1.00W in off mode condition. To meet EuP standards,

an EuP ready motherboard and an EuP ready power supply are required.

According to Intel’s suggestion, the EuP ready power supply must meet

the standard of 5v, and the standby power ef ciency should be higher

than 50% under 100 mA current consumption. For EuP ready power sup-

ply selection, we recommend you to check with the power supply manu-

facturer for more details.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ASROCK Carte mère

ASROCK

ASROCK Z170 Extreme7+ Manuel utilisateur

ASROCK

ASROCK M810LR Manuel utilisateur

ASROCK

ASROCK X570 CREATOR Manuel utilisateur

ASROCK

ASROCK 970DE3/U3S3 Manuel utilisateur

ASROCK

ASROCK E3C224 Manuel utilisateur

ASROCK

ASROCK Z590 Extreme WiFi 6E Manuel utilisateur

ASROCK

ASROCK Z68 Extreme7 Gen3 Manuel utilisateur

ASROCK

ASROCK 990FX Extreme6 Manuel utilisateur

ASROCK

ASROCK H670 Steel Legend Manuel utilisateur

ASROCK

ASROCK 870 EXTREME3 Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z170 Gaming K4 Series Manuel utilisateur

ASROCK

ASROCK H61M-VS R2.0 Manuel utilisateur

ASROCK

ASROCK K7VT2 Manuel utilisateur

ASROCK

ASROCK IMB-380-D Manuel utilisateur

ASROCK

ASROCK B85M DASH/OL R2.0 Manuel utilisateur

ASROCK

ASROCK FM2A75 Pro4-M Manuel utilisateur

ASROCK

ASROCK Fatal1ty Z68 Professional Gen3 Manuel utilisateur

ASROCK

ASROCK WRX80 CREATOR Manuel utilisateur

ASROCK

ASROCK H87M Manuel utilisateur

ASROCK

ASROCK ALIVEN570SLI-ESATA2 Manuel utilisateur

ASROCK

ASROCK P67 EXTREME6 - Manuel utilisateur

ASROCK

ASROCK ALIVENF5-ESATA2 -2943 - Manuel utilisateur

ASROCK

ASROCK FM2A55 Pro Manuel utilisateur

ASROCK

ASROCK G41M-GS Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
