Asko CBB761S Manuel utilisateur
instructions for use
COOKER HOOD
CBB761S
CBB861S
EN 2
EN Instructions for use EN 3 - EN 17
Pictograms used
Important information
Tip
EN 3
CONTENTS
Your cooker hood
Introduction 4
Use
Description hood 5
Description button control 5
Operation 6
Cleaning filters 8
Description remote control 9
Operation 10
Cleaning filters 13
Maintenance
Cleaning 14
Lighting 16
Battery of the remote 16
Technical data 17
Environmental aspects 18
EN 4
Introduction
On reading these user manuals you will soon become familiar with
the features of this appliance. Please read the appliance’s safety and
maintenance instructions.
Please retain the operating and installation instructions as these may be
useful for future reference.
Please read the separate safety instructions
prior to use.
YOUR COOKER HOOD
EN 5
USE
Description hood
1. Button control
2. LED spot
3. Edge extraction panel
4. Grease filter
5. Magnet
Description button control
6. Filter reset button, signals when filters require cleaning
7. Filter indicator
8. Lighting button, switches on/off and dims the lighting
9. Light indicator
10. Speed down button, reduces air extraction capacity and switches off
11. Speed up button, switches on and increases air extraction capacity
12. Speed level 1 indicator
13. Speed level 2 indicator
14. Speed level 3 indicator
15. Speed level 4/boost indicator
16. Timer function, turns off hood after time
17. Timer indicator
2 3 1 2
5 54
6 8 10 11 16
7 9 12 13 14 15 17
EN 6
USE
Operation
Switching extraction on and off
• Press the ‘+’ button.
The cooker hood will switch on at the lowest setting.
• Press the ‘+’ button again for a higher fan setting. Press and hold
the ‘+’ button for 1 second to select the highest setting (boost).
• Press the ‘-’ button to select a lower setting.
The extraction setting is indicated in the speed level indicators.
Each light area represents a speed level. Speed level indicator 4
also serves as a boost indicator when it blinks.
• If the extraction setting is set at 1, you can switch off the cooker
hood by quickly pressing and releasing the ‘-’ button.
• To switch off the cooker hood from, press and hold the ‘-’ button
for at least 1 second.
Switch on boost setting:
• Press and hold the ‘+’ button for at least 1 second.
The boost setting is switched on for 10 minutes. The speed level 4
indicator will flash during this period. The original extraction setting
will be reactivated after this period.
• Press and release the ‘-’ button to switch off the boost setting.
Note!
If the boost setting has been selected, you cannot activate the timer
function.
Switching on the timer
• Press the timer button.
The timer indicator will start to blink.
The cooker hood will switch off automatically after 10 minutes.
EN 7
• Switch off the timer function by pressing a random button (except
the one for lighting).
The cooker hood can be used in extraction mode or recirculation
mode. The air extraction capacity is adapted to the selected mode. The
hood will start up in the default extraction mode. Is has to be reset for
recirculation mode.
With an RMS kit (recirculation modification set) the air will first be
cleaned by the grease filters and then odours will be filtered by the
charcoal filter. The cleaned air is recirculated back into the kitchen.
Switching on recirculation mode
• Simultaneously press and hold the timer button and the light button
until the filter indicator flashes 3 times.
The carbon filter indicator is activated.
Switching off recirculation mode
• Simultaneously press and hold the timer button and the light button
until the filter indicator lights up for 3 seconds and then turns off.
Clean Air function
The Clean Air function allows you to freshen the air in your kitchen for a
maximum of 24 hours at level 1.
• Switch off the cooker hood.
• Press and hold the timer button for approximately 3 seconds.
The cooker hood will switch on automatically for 10 minutes every
hour at the lowest speed setting. During extraction the display
will show a fast moving ‘snake’. When the hood switches off after
10 minutes, the display will show a slow moving ‘snake’ until the
hood switches on again after 50 minutes.
• Switch off the Clean Air function in the meantime by pressing a
random button (any button other than the light button).
USE
EN 8
Switching the light on and off
• Quickly press and release the light button.
The light switches on at maximum strength.
• Press and hold the lighting button to set the lighting strength.
• To turn off the light, quickly press and release the light button while
the light is on.
The lighting changes from maximum to minimum strength and
vice versa.
Changing the colour temperature
You can adjust the lighting temperature.
• Press and hold the light button. Press the ‘-’ button to make the light
‘colder’ or press the ‘+’ button to make the light ‘warmer’.
Cleaning filters
Saturation of grease and carbon filters
The filters should be replaced or cleaned when the filter indicator is lit.
See ‘Maintenance’ chapter.
Grease filter
The filter indicator will light up after 30 operating hours.
• The grease filters should then be cleaned.
• Reset the memory by pressing and holding the ‘-’ button until the
filter indicator stops flashing.
Carbon filter
The filter indicator will flash after 120 operating hours.
• The carbon filter should then be cleaned or replaced.
• Reset the memory by pressing and holding the ‘-’ button until the
filter indicator stops flashing.
USE
EN 9
USE
Description remote control
The remote control is available as an accessory for this cooker
hood and is not included with this appliance.
1 6
2
37
4
8
10
5 9
1. Timer function
2. Increase light intensity
3. Colder light temperature
4. Decrease light intensity
5. Decrease air extraction capacity
6. Clean air function
7. Warmer light temperature
8. Switch on/off lighting
9. Increase air extraction capacity
10. Fan on/off
EN 10
USE
Buttons must be pressed and held. This is to prevent functions from
being accidentally switched on or off.
Operation
Pairing the remote
This remote control must be paired to the cooker hood before first use.
• Start up the appliance (power on). Press and hold the -’and ‘+ for
3 seconds. The hood will start ‘pairing mode’ for 5 minutes.
• Activate the ’Remote pairing mode’ by holding ‘c’ and ‘w’ for 3 sec.
• During pairing all the indicators on the hood and remote will blink. All
indicators will turn off when the connection is established.
If the connection is not established repeat the entire pairing process.
Remote control will go into standby after 30 seconds. The remote will
wake up when it is picked up or detects movement.
Switching extraction on and off
• Press and hold the ‘Fan’ key on the remote for 1 second.
The cooker hood will switch on at the lowest setting.
• Press the ‘+’ key again for a higher fan setting. Press and hold the
‘+’ key for 1 second to select the highest setting (boost).
• Press the ‘-’ key to select a lower setting.
The extraction setting is indicated by the speed level indicators on the hood.
• To switch off the cooker hood, press and hold the ‘Fan’ key for
1 second.
