Service Manual Professional TD

Type:TD60.C

Service Manual TD60.C

Type: TD60.C

Contents

Updates..................................................................................................................................................................................................................................................4

Introduction .........................................................................................................................................................................................................................................5

Product overview.............................................................................................................................................................................................................................6

Knob and button descriptions...................................................................................................................................................................................................6

LCD description ..............................................................................................................................................................................................................................6

Programme table ..............................................................................................................................................................................................................................7

Programme descriptions ..............................................................................................................................................................................................................8

Settings....................................................................................................................................................................................................................................................9

Service menu ................................................................................................................................................................................................................................... 10

Service menu content................................................................................................................................................................................................................. 11

Fault indicators................................................................................................................................................................................................................................ 13

Components and measurement values............................................................................................................................................................................14

Technical data...................................................................................................................................................................................................................................15

Wiring diagram ............................................................................................................................................................................................................................... 16

Service Manual TD60.C

Updates

Revi-

sion

Date Description Initials

01 2009-08-12 Conference version BPA

02 2010-04-29 Supplemented with information MAS

03 2010-07-19 Added information about automatic lint ﬁlter detection BPA

Service Manual TD60.C

Introduction

You are holding the service manual for TD60 tumble dryers.

It should be easy to service a tumble dryer. It is important that you, as a service technician, are

provided the necessary conditions to work in an efﬁcient and satisfactory manner. Our hope is

that this service manual will prove a useful tool in your daily work.

The type designation can be found on the machine plate located on the right-hand side of the

front panel (concealed by the door).

Type designation Product number

Serial number

Year Week

TD60.C

Service Manual TD60.C

General product information

Lint ﬁlter sensor

A lint ﬁlter sensor was introduced in August 2010. If the lint ﬁlter is not fully seated or inserted

incorrectly in the lint ﬁlter holder, the machine will not start. Moreover, an error message is dis-

played: “Insert ﬁlter”. The system comprises a sensor in the lint ﬁlter holder and a magnet in the

lint ﬁlter. When the lint ﬁlter is correctly inserted, the magnet triggers the sensor, which closes the

circuit in the machine.

Fig.1 The sensor installed in the lint ﬁlter holder.

Fig.2 Lint ﬁlter holder and lint ﬁlter as seen from the side. On the left, the sensor

in the lint ﬁlter holder; on the right, the magnet in the lint ﬁlter.

Service Manual TD60.C

Troubleshooting strategy

At Asko, we believe in always remaining focused on the customer, and as an ASKO service techni-

cian, you are one of the most important ambassadors of our brand. As such, it is important that

the customer ﬁnds the service callout a pleasant experience. Troubleshooting is an important part

of the service callout, and as such we have drawn up a troubleshooting strategy that describes, in

broad terms and step by step, what you need to do to ﬁnd and diagnose faults.

• Ask the customer to describe the problem.

• Check whether the customer’s description matches any service code.

• Check that the machine is correctly installed:

- Electrical connection - Drainage

- Water connection - Machine correctly levelled

Fault found?

Incorrect installation or external factors that affect performance and functionality (for ex-

ample, water pressure, electrical supply, drainage).

The machine operates normally. No deviations can be found. The customer probably needs

to be informed about proper use of the machine. If necessary, also inform the customer

about guarantee conditions and charges and any charges due.

Yes

Open the service menu:

1. Check the settings

2. Run a test cycle

3. Note any fault codes

If the above actions do not uncover the fault:

• Conduct general troubleshooting. Use the documentation available at ServiceSaver (serv-

ice manuals, service memos, wiring diagrams and other documents).

Yes

Fault found?

Fault diagnosed?

Repair and check function/

safety.

Contact technical support

for assistance.

Carry out the actions sug-

gested by technical support.

Satisﬁed customer!

OK?

Yes

Service Manual TD60.C

Product overview

TD60.C

Programmes: A total of 7 programmes.

Settings: 4 settings (Language, Child-safe, Buzzer, Heater 2)

Knob and button descriptions

Programme selector (J1)

Turn clockwise or anti-clockwise to cycle through

the different programmes and options in the various

menus.

Start Stop

Start button (S2)

• Start programme

Start Stop

Stop button (S3)

• Stop programme (press and hold for 3 seconds).

LCD description

S2 S3

Auto normal dry

Programme name Low temperature Estimated remain-

ing time

J1 LCD

Service Manual TD60.C

Programme Material Tempe-

rature

Max.

load

(kg)

Energy consump-

tion (approx. kWh)

Programme time

800

rpm

160 0

rpm

800

rpm

160 0

rpm

Auto extra dry Cotton, linen Auto nor-

mal dry

64.53.52:251:55

Auto dry Cotton, linen Auto nor-

mal dry

64.33.22:151:45

*Auto normal dry Cotton, linen Auto nor-

mal dry

62.0- 1:10-

Auto extra dry, low tempe-

rature

Cotton, linen Low 6 3.9 2.8 2:00 1:30

Auto dry, low temperature Permanent press,

polyester/cotton

Low 3 1.7 - 0:55 -

Auto normal dry, low tem-

perature

Acrylic, rayon,

acetate

Low 3 2.0 - 1:15 -

Auto iron dry Cotton, linen Low 6 3.0 2.2 1:35 1:10

*Programme tested in accordance with EN 60456/A11/A12/.

Here we present a few examples of the energy and time consumption of a few different

programme settings. Consumption can vary depending on room temperature, humidity,

load, variations in the power supply and selected options.

The following apply for the speciﬁed consumption values:

Temperature of intake air: 23°C

Moisture content of intake air: 55%

Drying temperature: Normal or low

Heater output: 3000 W

Programme table

Service Manual TD60.C

Programme designation Description

Auto extra dry This programme is for items that are particularly difﬁcult to dry, e.g. jeans with very thick seams.

Auto dry These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto

dry programme shuts off the heat slightly later than Auto normal dry. Use trial and error to ﬁnd

out what works best. Use these programmes when you want items to be completely dry.

Auto normal dry These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto

dry programme shuts off the heat slightly later than Auto normal dry. Use trial and error to ﬁnd

out what works best. Use these programmes when you want items to be completely dry.

Auto extra dry, low temperature This programme is for items that are particularly difﬁcult to dry, e.g. jeans with very thick seams.

Auto dry, low temperature These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto

dry programme shuts off the heat slightly later than Auto normal dry. Use trial and error to ﬁnd

out what works best. Use these programmes when you want items to be completely dry.

Auto normal dry, low temperature These programmes shut off the heat once the load is dry but before it is “overly dry”. The Auto

dry programme shuts off the heat slightly later than Auto normal dry. Use trial and error to ﬁnd

out what works best. Use these programmes when you want items to be completely dry.

Auto iron dry This programme shuts off the heat once the load is just damp enough for ironing or pressing.

Programme descriptions
