ASHA PMB-101 Manuel utilisateur

Cover

ASHA Beam Prole

PhotodiodePowerMeterBundle

PMB-101

WWW.ASHA-CO.IR2

About Us

In order to design and manufacture programmable optometrical, op-

tomechanical and optoelectronical devices, the science-based compa-

ny, ASHA Beam Prole, was established in 2016.

ASHA has been able to design a wide range of devices, relying on

indigenous capability and knowledge. Also, since being calibratable is

essenal for measuring equipment, clients can carry out their period-

ical calibraon.

Field of activity

The main eld of acvity of this company is the design and produc-

on of laser, opcs and photonics equipment and can be categorized

in the following topics:

»Diode laser driver

»Laser diode stabilizer

»Laser Parameters measuring equipment such as Power Meter, Beam Pro-

ler, and Ultra-fast Detector

»Lithographic masks

»Linear posioner with stepper motor driver

»Calibraon of Power Meters and beam prolers

»Design and producon of soware to facilitate the use of electro-opc

and optomechanical programmable equipment

3WWW.ASHA-CO.IR

Main features

Introduction

Measuring the output of light sources is very important. For exam-

ple, the opcal power of medical lasers is very sensive and can cause

irreparable damage if the funcon of the device goes out of its proper

range. In experimental and research applicaons, it is always neces-

sary to measure the output of laser sources. In addion to the above,

it is crucial to pay special aenon to the necessity of calibraon of

industrial and military laser equipment.

Hence, the semiconductor power meter is designed for high preci-

sion laser applicaons. Producons of this company can well meet the

needs of the scienc and industrial community in the eld of power

metering.

The semiconductor power meter is designed for high precision laser

applicaons. The products of this company can well meet the needs of

the scienc and industrial community in the eld of power metering.

WWW.ASHA-CO.IR4

Features

»Direct connecon to the mulmeter with a special cable (depends on

order)

»Ability to operate in 12 dierent wavelengths from 350 nm to 1100 nm

(depends on order)

»Adjustable for desired light sources in the specied wavelength range

(depends on order)

»Able to have specic Gain for required scale (depends on order)

»Measuring the power of coherent opcal sources

»Measuring the power of connuous light sources

»Possibility to remove background radiaon and photodiode dark current

(depends on order)

»Internal rechargeable baery for portable use

Applications

»Study incident and reected beam power and qualify light sources

»Study the eect of environmental changes on laser sources performance

»Study the variaon of power when passing through (transparent) envi-

ronments

»Examining the quality of lenses and opcal windows

»Measure the intensity of reecon/passing beam from dierent surfaces

Warning! With regard to the items listed in the requirements secon,

to maximize the accuracy of the device, it is strongly recommended to

connect the power meter earth to the standard one.

5WWW.ASHA-CO.IR

Technical Features

Item Min Typ Max Unit

Input Voltage 4.75 5 5.25 V

Input Current 60 250 500 mA

Baery -<2000 - mAh

Baery Life -20 - h

Charge Time - 5- h

Wavelength Range 355 -1064 nm

Opcal Power Working Range*0.01 -240 mW

Display Power Range 0.1 -199.9 mW

Measurable Wavelengths** 355, 405, 450, 532, 633, 650, 780, 808, 850, 970, 1064 nm

Measurement Uncertainty ±5 %

* Measuring power in the range of 10 mW to 240 mW is possible If

connect 5.5 digit voltmeter with 1 uV accuracy to output.

** Maximum FWHM for console display should be ±5 nm and for

voltmeter output should be ±1nm.

Note Console output voltage is equal to one-tenth of opcal source power. So

1 V in output is equal to 100 mW power of the opcal source.

WWW.ASHA-CO.IR6

More Spec. Discripon

Dimenon Detector 35x35x18.5 mm3

Console 180x165x70 mm3

Weight Detector < 200 gr

Console < 1000 gr

Detector Connecon DB9

Output Connecon BNC

Acve Detector Area 10x10 mm2

Input Aperture Ø9 mm

Display 2000 counts - 7segment

Figure1.Ph o to d i o d e P owe r M ete r S en so r wi th A n nu l ar U V V i ewi n g Ta rg e t

7WWW.ASHA-CO.IR

Figure2.PhotodiodePowerMeterConsole-FrontView

Figure3.PhotodiodePowerMeter-BackView

WWW.ASHA-CO.IR8

Contents

About Us ............................................................................ 2

Field of acvity 2

Main features..................................................................... 3

Introducon 3

Features 4

Applicaons 4

Technical Feature 5

Power Meter Parts ............................................................. 9

Packaging Content 9

Detector Parts 10

Console Parts 11

Setup................................................................................ 13

Safety 13

Preparaon and measurement 14

Requirements 16

9WWW.ASHA-CO.IR

Power Meter Parts

Available Accessories

Please make sure that all accessories are available for the box in your

rst use.

»Photodiode Sensor x 1

»Dust Cap x 1

»Photodiode Power Meter Console x 1

»User Manual* x 1

»5V Power Supply x 1

»Mulmeter Connector Cable x 1

»M4 Screw x 2

* Digital version of this user manual is available by scanning the QR-

code under the console.

WWW.ASHA-CO.IR10

Detector Parts

Figure4. SemiconductorPowerMeterSensor-FrontView

1. M4 screw for vercal aligning

2. Sensor Cap(if open, guarantee void)

3. Visible spectrum detector (depends on order)

4. Connector cable

5. M4 screw

6. Input aperture(Opcal Filter)

7. Cap furrow

8. Anodised Aluminum body
