AP224B Series GPON HGU ONT
Solutions Provider for FTTx, RFoG, and HFC
Connection finished, please check the indicators.
ON: power on
OFF: power off
ON: ONU activation
OFF: no ONU activation
Flickering: ONU activation on
ON: connected but no data transmission
OFF: power off or no connection between port and net
Flickering: data transmission
ON: connected but no data transmission
OFF: power off or no connection to terminal device
Flickering: data transmission
ON: connected but no data transmission
OFF: power off or no connection to terminal device
Flickering: data transmission.
ON: connected but no data transmission
OFF: power off or no connection to terminal device
Flickering: data transmission
If there is something wrong with the indicators, please check the line connections.
Lay the devices on horizontally flat surface.
Shut down the power supply and unplug all line connections during a lightning storm.
Keep the device away from heaters and keep the ventilation.
Use configured rated power adapter.
