Arrowquip EASY FLOW Manuel utilisateur
CONTENTS
Safety Precautions 1
Risk Assessment 2
Before Installing 2
Assembly Instructions
Assembling a Single Easy Flow Race 3
Kicker Panel Installation 7
Anti-Backing Bar Installation 10
Rolling Race Gate Installation 12
Between Two Races 12
Between a Race and a Kicker Panel 13
Between a Race and a Forcing Pen 15
Between a Race and a Vet Cage 16
Other Products 17
Adjusting the Easy Flow Cattle Race 17
Emergency Exit 17
Using the Removable Side Panels 18
Recommended Maintenance 18
Bill of Materials 19
Warranty 20
PLEASE FOLLOW ALL SAFETY INSTRUCTIONS PROVIDED IN THIS MANUAL
BEFORE OPERATION. ARROWQUIP DOES NOT ACCEPT RESPONSIBILITY
FOR ANY ACCIDENTS OR INJURY WHEN THIS SAFETY MANUAL HAS
NOT BEEN READ IN FULL AND KEPT WITH THE PRODUCT AT ALL TIMES.
OPERATORS OF THIS PRODUCT TAKE AND ACCEPT RESPONSIBILTY FOR
ANY HARM OR INJURY TO THE ANIMAL OR OPERATOR WHEN IT PERTAINS
TO HOW THE EQUIPMENT IS USED AND MAINTAINED.
Please keep this manual for frequent reference and to pass on to new users or owners.
SAFETY PRECAUTIONS
PLEASE FOLLOW ALL SAFETY PRECAUTIONS OUTLINED HEREIN. ANY
HARM TO THE ANIMAL OR INJURY TO THE OPERATOR WHICH OCCURS
DUE TO HOW THE PRODUCT IS OPERATED, OR RESULTING FROM A LACK
OF SAFETY PRECAUTIONS ARE THE SOLE RESPONSIBILITY OF THE
OPERATOR.
All farm machinery and equipment is potentially dangerous. Careless use of any Arrowquip
livestock equipment may cause injury or damage to persons, cattle, or property. Arrowquip
has taken precautions in the design and manufacturing of this product to ensure that it is safe
and user-friendly. Therefore, user must assume all responsibility and risk associated with the
possession and use of the equipment.
WARNING: READ BELOW BEFORE OPERATION.
DANGER:
PANELS ARE VERY HEAVY AND WILL DROP WITH EXCESSIVE
PRESSURE WHEN AN ANIMAL IS CONTAINED IN THE RACE.
FAILURE TO OPERATE THE EMERGENCY EXIT PROPERLY
MAY RESULT IN DAMAGE OR INJURY/DEATH.
SAFETY LATCHES MUST BE IN PLACE WHEN ADJUSTING THE
SIDES OF THE EASY FLOW CATTLE RACE. FAILURE TO USE
THE SAFETY LATCHES MAY CAUSE THE PANELS TO DROP,
RESULTING IN DAMAGE TO PERSONS OR PROPERTY.
1 | SAFETY PRECAUTIONS
1. Ensure the operator understands the contents of this manual before using the
equipment.
2. Donotwearloose-ttedclothing.
3. Ensuretheequipmentisonarm,level,drysurfacethatisfreeofrocksandothertrip
hazards.
4. DO NOT ALLOW CHILDREN UNDER THE AGE OF 18 NEAR AN OPERATING
MACHINE.
5. Follow safe cattle handling procedures in other areas of the yard so that cattle are more
docile.
6. DonotmakeanymodicationstoArrowquipequipment.Non-factorymodicationsto
the equipment can reduce the safety for the operator and livestock.
RISK ASSESSMENT
Conduct a risk assessment on procedures for which the equipment is used and establish a
safe work procedure.
1. Ensure all users of the equipment have been inducted and comply with safe working
procedure.
2. Please ensure that there are NO large or hazardous objects inside the equipment that
may cause injury to the animal or operator, or may cause the equipment to malfunction.
3. Make sure that your equipment has been cleared of ALL livestock after use.
4. Some chemicals and medicines can damage powder coat. Take all precautions and
wash after use.
Level Ground HEAVY
Partner Lift
Forklift Required
BEFORE INSTALLING
RISK ASSESSMENT | 2
PACKING LIST: 8´ EASY FLOW RACE
7002337
A
x4
7001812
B
x8
7002062
C
x8
2004618
D
x2
WING HEAD BOLT
2004619
E
x1
2004616
F
x2
1/2" FLANGE NUT
PACKING LIST: 10´ EASY FLOW RACE
2003908
G
x2
1/2" x 3" HEX BOLT
7002337
A
x4
7001812
B
x8
7002062
C
x8
2003891
D
x2
WING HEAD BOLT
2004949
E
x1
2003890
F
x2
1/2" FLANGE NUT
2003908
G
x2
1/2" x 3" HEX BOLT
ASSEMBLY INSTRUCTIONS
ASSEMBLING A SINGLE EASY FLOW RACE
REQUIRED TOOLS
- 3/4" Wrench
- 3/4" Socket
- 9/16" Wrench
- 9/16" Socket
- Ratchet
3 | ASSEMBLING A SINGLE EASY FLOW RACE
ASSEMBLY
1 Lay two race bows on the ground horizontally.
2 Install the top post in the race. Keep nuts loose.
x2
B x 8 C x 8 E x 1
ASSEMBLING A SINGLE EASY FLOW RACE | 4
G x 2
3 Stand the race frame up, and position one panel on each side.
4 Insert the bottom pins on the panel into the frame on one side.
x2
5 | ASSEMBLING A SINGLE EASY FLOW RACE
5 Insert the bottom pins on the panel into the frame on the opposite side.
x2
6 Lift the panels up and latch into the frame. Tighten all fasteners to secure.
x2
ASSEMBLING A SINGLE EASY FLOW RACE | 6
7Connect to crush, race or other equipment using the provided panel pins.
CONNECTING TO ADDITIONAL PRODUCTS
KICKER PANEL INSTALLATION
REQUIRED TOOLS
- 9/16" Wrench
- Alignment bar
PACKING LIST
7 | KICKER PANEL INSTALLATION
7002294
A
x8
2004382
B
x1
3/8" x 2 3/4"
CARRIAGE BOLT
7001811
C
x8
3/8" FLANGE NUT
ASSEMBLY
1 Start with two assembled Easy Flow Races.
2008775
D
x2
