AromaPlan DAP-102NP Manuel utilisateur

PRODUCT MANUAL

AromaPlan scent diffusers are powerful, easy to use and the most silent devices available.

Our innovative technology converts the liquid perfume into dry vaporous microparticles,

creating a practically invisible mist that drifts evenly throughout any space.

For example, when a candle burns, its perfume is stronger the closer you get.

Our devices are different. A space is scented evenly, regardless of where you are.

Our devices are perfect for scenting any setting, controlling foul odors and improving the

quality of indoor air in business and home environments.

With AromaPlan’s diffuser you have ultimate control. You can schedule the strength of the

fragrance as well as when it will automatically turn on and off, to perfectly scent your envi-

ronment according to your daily needs, without ever wasting your favorite fragrance.

Features:

• Easy oor or wall installation.

• Space evenly scented.

• No Residue.

• Safe for Kids & Pets

• Physical diffusion without

heating and water.

• Automatic scheduling on/off

according to your daily needs.

• Ultracold mist.

• Microparticles permit immediate and even

diffusion for lasting results.

• Automatic mode.

• Easily control fragrance concentration.

Attached Warranty Card

Please keep the Instruction and the warranty card carefully for further

reference. Please read all instructions before using the machine.

NO FLAME NO RESIDUE ECO-FRIENDLY PET-FRIENDLY

White Diffuser DAP-101NP &

Black Diffuser DAP-102NP

Avoid casualties and property loss, please always

follow the attentions as the following.

(The following basic safety precautions

should be always complied with)

I.Cautions

WARNING

May cause electric shock

or re hazard.

NOTE

May cause personal injury

or property damage

INSTALLING

1.Do not use unsafe plug or power.

2.Do not install the device at the place

where children can touch.

3.Do not install the device at the place

where can not bear strength and prone

result in falling and collapsing.

4.Do not tilt the device.

5.Keep the device away from re

and heat source, prohibit to store am-

mable and explosive materials

around the device.

6.Except for the atomizer, the housing

material is not resistant to corrosion.

7.Do not use device in high tempera-

ture or wet environment.

8.Do not use inammable, explosive,

corrosive and other hazardous solvents

work with the device.

INSTALLING

1.Ensure the rmness of installation area.

2.Install the device in a ventilative

and adequate space.

3.Do not block the sprayer by hand or

other obstructions when the device is

working.

4.Do not spill water or conductive, cor-

rosive liquid on the device surface or fall

inside of the device.

5.Do not operate device without stop-

ping. Suggested average daily usage

time should not exceed 14hours, and the

third level is recommended.

6.Cut off the power in extreme weather

environment.

PROHIBITION NECESSARY

Parameter

Model: PRO300

Voltage: 12V

Power: 7.5W

Capacity: 300ml

Weight: 0.9KG

Coverage: 300~400m³

Size: 170(L)X80.5(W)X206(H)mm

Atomizer

One-time

inner stopper

Nozzle

Fragrance

oil bottle

II.Specification

170mm

80.5mm

206mm

ATTENTION

The screws are optional parts for xing the equipment on

walls and the air conditioning tube is optional, if it is of

interest to the user, it is necessary to contact via e-mail for

more information and guidance on the installation process.

III.Instruction

Approved Certicate: CE, FCC, RoHS, CNAS and so on.

Application Place: Brand clothing store, 4S shop, bar, clubhouse and so on.

1. APP Operation Introduction

The device has four buttons :

“ ” is the return button

“ ” is the conrmation button,

“ ” is the increasing button

and “ ” is the shift button.

V.Operation Introduction

NORMAL WORKING INTERFACE

IV.How to use the equipament

https://youtu.be/hUPIElts7hE

VIDEO TUTORIAL - How to install your AromaPlan Diffuser

2. Buttons operation:

The device has four buttons:

1.Under the normal working interface, press “ ” and “ ” buttons at the same time to

enter the password setting interface. Password: 0000

2.Under the normal working interface, press “ ” and “ ” buttons at the same time to

turn on/off the essential oil detection function.

3.Under the normal working interface, press “ ” button to adjust the concentration

level A, B and C.

4.Under the normal working interface, press “ ” and “ ” buttons at the same time to

enter local time setting interface.

5.Under the normal working interface, press “ ” button to enter the working time and

frequency setting interface.

6.Under the normal working interface, long press “ ” button to turn on/off the fan.

7.Under the normal working interface, long press “ ” button to

turn off the machine.

3. Factory Reset:

Under the normal working interface, rstly, press the “ ” and “ ” buttons at the

same time until the interface shows YES/NO, then let your hand go.

Secondly, operate “ ” button to choose YES then press “ ” button to conrm it

and nish the setting.

4. Congure your diffuser

1.Programming Date/Time:

Programming your AromaPlan diffuser updating the

date and time is very simple.

After plugging in your machine you’re going to press “ ”

and “ ” buttons at the same time to update the time in a

24-hour format you’re rst going to click the button “ ”

in order to adjust the hour and then you’ll go to the button

“ ” to update the minutes.

DATE/TIME INTERFACE

Now once we have nished setting up this program screen

we can press “ ” for the diffuser to begin working in the

Normal Working Interface where you’ll see the countdown

of the Working (W) seconds that you programmed and the

Pause (P) for resting seconds that you programmed.

You can programming up to ve schedules.

3. Scenting schedule conguration:

The diffuser has three different intensity settings

depending on the size of your space once you are in the

home screen simply click “ ” and you will begin to see

the intensity changing from A, Band C.

The suggested intensity is for spaces up to 1000 square

feet use intensity A, spaces is up to 1500 square feet

use intensity B, spaces above 1500 square feet use

intensity C and if in any case you need more intensity

for your fragrance you’ll just hold “ ” for 5 seconds

and it’ll enter into turbo mode “ ”.

NORMAL WORKING INTERFACE

VI.Accessories and spare parts

Please clean the equipment periodically, suggest 2-3 months in 1 circle, so that it can

work under best condition.

Please cut off the power when cleaning, also do not use wet hand to operate it directly,

in case of electric shock and injury.

1. Long-term non-use

(1) Please turn off and cut off the power then roll up the power cord.

(2) Clean the lter components.

(3) Place the deodorant package which contains activated carbon in the device or package,

to prevent residual substances in the equipment produce odor.

(4) Please equip the machine with the dust cover, placed in the shade, ventilative place.

https://youtu.be/jw-mbckVvuQ

VIDEO TUTORIAL - How to congure your equipment

SCENTING SCHEDULE INTERFACE

NORMAL WORKING INTERFACE

Next, set the day of the week and the date using the same buttons as before to congure.

Clicking the “ ” button changes the item, and the “ ” button moves you to the next

item to be adjusted.

Press “ ” button to conrm it and nish the setting.

2. Scenting schedule conguration:

Programming working hours

After conguring the date and time, congure the

scenting schedule of the diffuser. The rst step is to

program the diffusers working hours. We will do this by

pressing “ ” in order to enter these settings.

Once you are in the program screen click “ ” to move

from the current day to the hour.

Now we can begin adjusting the diffusers Start Time (St) by clicking “ ”, we’ll change

the hour and we can click “ ” in order to change the minutes we will then click the “ ”

again in order to move to the end time.

Programming working intervals

Once we have nished setting up the hours, now we are going to adjust the intensity of your

fragrance this is done by setting up working intervals in seconds so we’ll click “ ” after

we adjust the time to come down to your Working (W) seconds this is how long your diffuser

will release fragrance, for example so we have it set to Work, by clicking “ ” button, for 30

seconds (30s). Then we will click the “ ” again in order to move it, so we can also adjust

the Pause (P) for resting time. We cal also ajust the Pause (P) for resting time, so for

example you can set it to pause for 90 seconds (90s) by clicking in “ ” button.

VII.Accessories and spare parts

NAME

Aroma diffuser

Adapter

Cap

Air conditioning tube

Key

Pneumatic ttings

1PC

2PC

1PC

NAMEQUANTITY QUANTITY

Screws

(including plastic

expansion tube)

Manual

Warranty card

Bottle sealing gasket

Mounting strip

2PC

1PC

2PC

VIII.After-sales Service

1. Provide free technical solutions and installation process guidance.

2. Provide free online FAQ consultation and scent-marketing suggestion.

IX.The equipment warranty and precautions

1. The equipment has a 1-year warranty (from the date of purchase).

2. Please provide the warranty card,Invoice or other provement which can prove the

equipment was ordered in our company to enjoy the free maintenance.

3. The human error or other wrong operation cause the fault not belong to the scope of

warranty, and will not be accepted to provide free maintenance.
