Connect the pump to the mains power supply using the supplied cable.

Set the Run/Standby switch (on the side of the pump) to the Run ( |) position.

The Run/Standby indicator is illuminated when the pump is running.

In the event of mains failure, the Power Fail alarm indicator will start ashing and an audible alarm will sound.

The pitch of the alarm will increase in time. If the power supply is returned the audible alarm will stop, but the

alarm light will remain illuminated until the system is reset using the Run/Standby switch.

The Low Pressure indicator will ash whenever the pump detects low pressure in the cushion. An audible

alarm will sound. The pitch of the alarm will increase at 60 second intervals.

The indicator will extinguish once normal pressure is reached. Check the tubeset is connected properly.

Comfort Control - The seat cushion cell pressure can be manually adjusted for patient comfort using the

Pressure Control.

Note: An internal battery will power an audible and visual alarm if the power supply is interrupted prior to

switching off. For example, if the mains lead is removed before switching to Standby mode.

The pump alarm can be reset by switching the pump to Standby and back to Run again using the Run/

Standby switch on the side panel.

This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional

aspects of the system. This guide does not replace the general safety warnings, cautions and recommendations provided in

the product Instructions for Use, part number 500935EN.

Refer to the product Instructions for Use before using this product.

Caution: Active therapy (alternating) cushions may be unsuitable for patients with poor sitting posture or pelvic deformity;

advice from a seating specialist should be sought.

Contraindication: Do not use the system for patients with unstable spinal fractures.

Caution: If patients have other unstable fractures, or conditions which may be complicated by a soft or moving surface,

advice should be sought from an appropriate clinician before use.

Indications:

• The Aura cushion is designed for patients weighing up to 120 kg (264 lb).

• The Aura systems are indicated for the prevention and/or management of all categories1of pressure ulcer, when

combined with an individualised, comprehensive pressure ulcer protocol.

1. NPUAP/EPUAP International Pressure Ulcer Guideline, 2014.

Aura

500937EN_03 · 05/2019

QUICK REFERENCE GUIDE

Aura

Installation

Place the Aura seat cushion on top of

the chair surface.

From a standing position in front of

the chair and facing it, make sure

the cells are uppermost, the tubeset

appears from the front right corner

of the cushion and the cells are in a

horizontal position across the chair.

Secure the seat cushion to the

chair surface using the xing straps

provided.

If the chair is of the closed side type

with a removable cushion, x the Aura

seat cushion as shown.

To complete the seat cushion installation:

Zip the protective cover over the cushion.

Make sure the Arjo logo is uppermost and at the front of the

cushion.

Quick Start:

When the Aura pump is switched on at the mains

supply, all indicators will momentarily ash.

Set the Run/Standby switch on the side of

the pump to the Run ( | ) position

Allow approximately 2 minutes for the seat cushion to

inate fully.

Once the patient is on the seat cushion, adjust the cell

pressures using the comfort control according to the

patient’s preference.

Caution: Do not use the seat cushion without a foam cushion

beneath it.

Installing the pump:

Position the pump feet down on any

convenient horizontal surface or

alternatively suspend from the chair

frame by means of swing out hooks.

Connect the male and female air feed

tubes into the appropriate outlets on

‘

‚

·¢

the pump unit. Push connectors in until they click. Make sure

the air feed tubes are not “kinked” or twisted.

Insert the mains power plug into a suitable mains power

socket.

Caution: Do not use the Aura seat cushion without a

foam cushion beneath it.

Caution: Always use the Aura seat cushion with the

protective top over.

Caution: Always use the Aura seat cushion in the correct

orientation.

Caution: Avoid trailing cables - ensure that cables and

tubing are positioned beneath the chair to

avoid causing a hazard.

Make sure the cells are in a horizontal position across the

chair, NOT from front to back.

® and ™ are trademarks belonging to the Arjo group of companies.

As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice. The content of this publication

may not be copied either whole or in part without the consent of Arjo.

ArjoHuntleigh AB

Hans Michelsensgatan 10

211 20 Malmö, Sweden

www.arjo.com 500937EN_03: 05/2019
