Ethernet Printer

User’s Guide

Version 1.03

Ethernet Printer Technical Manual November 10, 2010

Table of Contents

1. ETHERNET CARD SPECIFICATIONS

2. ADDITIONAL COMMANDS

TABLE1: PARAMETER ID

TABLE 2

3.ETHERNET PRINTER STATUS/ACTIVITY INDICATORS

3.1 Ethernet Module Status/Activity indicators



3.2 Printer Status/Activity indicators



4.OBTAINING THE IP ADDRESS

5.INFORMATION AND SETTING

6.ETHERNET PORT SETTING

7.LCD ETHERNET SETTING

8.RESET ETHERNET CARD

9.REBOOT ETHERNET CARD

10.ETHERNET CARD REPLACEMENT

10.1 A-2240E Ethernet Card Replacement



10.2 X-2300E/X-3200E Ethernet Card Replacement



10.3 CP-2140E Ethernet Card Replacement



10.4 OS-2130DE Ethernet Card Replacement



11.PRINTER UTILITY

11.1 Download/Upgrade firmware



11.2 Printer setting



Ethernet Printer Technical Manual November 10, 2010

11.3 Printer Info



12.SELF-TEST DIAGNOSIS

12.1 Perform Self-test Diagnosis



Ethernet Printer Technical Manual November 10, 2010

1. Ethernet Card Specifications

Items Specifications

CPU 32-bits, ARM-922, 100MHz

RAM 8 MBytes ( 4 M * 16Bits )

ROM 4 MBytes

Ethernet 1. Port: RJ-45 connector

2. LAN: 10/100 Mbps ( Auto Detect )

3. Protocol: ARP, IP, ICMP, UDP, TCP, HTTP, DHCP,

rawTCP, LPR, IPP, SNMPTrap

4. Mode: TCP Server/Client, UDP Client

5. Setup: HTTP Browser Setup

6. Security: Setup Password

Digital I/O Port Digital I/O * 5, USB 2.0 * 2

Watch Dog Function

Firmware Firmware On-line Updated Via Ethernet/USB

LED Lamp Power

Environment Operating Temperature: 0°C ~ 70°C,

Storage Temperature: -20°C ~ 50°C

Dimensions 67.8 x 64 x 17.2 mm ( W x L x H )

Weight 32 g

Ethernet Printer Technical Manual November 10, 2010

2. Additional Commands

Parameter types:

-None: no parameter is required

-Signed integer. e.g. +100 or –23

-Unsigned integer. e.g. 32

Signed byte. Just one byte binary data. e.g.

+3 is represented as 0x03(03H), and –1 as 0xff (0FFH).

Command Description

<ESC>KIZA

*Enable/disable the switch detection of the print head if it is opened.

*Syntax: <ESC>KIZAm

*Parameter:

m = 0; disable the switch detection of print head if it is opened

(default)

m= 1; enable the switch detection of print head if it is opened

If this function is enabled, the label auto-calibration will be performed when the print head is

closed.

<ESC>KJA Request the printer status through Ethernet to be displayed on the web

page. Information about the printer status is listed in TABLE1.

<ESC>KJB End Job

<ESC>KJH Enable the printer to check if Ethernet card is alive or not every second.

<ESC>KJI Disable the printer to check if Ethernet card is alive or not every second.

<ESC>KJJ Start Job

<ESC>KJK *Reset the printer function.

*Syntax: <ESC>KJKm

*Parameter:

m=0 disable the reset function (default)

m=1 enable the reset function

This command is for printer configuration.

<ESC>KJL *SNMP broadcasted function setting.

*Syntax: <ESC>KJLmnq

*Parameter:

m= 0, disable the Ethernet card to enquire to reset the printer

(default)

m=1, enable the Ethernet card to enquire to reset the printer.

n= 0, disable the SNMP function (default)

n=1, enable the SNMP function

q= 1~9 seconds;which SNMP enquire for the

Ethernet Printer Technical Manual November 10, 2010

printer status. (default value:1)

This command is for Ethernet card to enquire Printer.



<ESC>KJOETHERNET

*Ethernet IP addresses

*Syntax: <ESC>KJOETHERNETm,m,m,m,n,n,n,n,o,o,o,o,q,q,q,q,q,q

*Parameter: “m,m,m,m,”: IP address

“n,n,n,n,”: subnet mask

“o,o,o,o,”: gateway

“q,q,q,q,”: MAC address

Parameters must be HEX values.

*Example:

IP address:192,168,0,42

(“m,m,m,m,”=”0xC0 0x2C 0xA8 0x2C 0x00 0x2C 0x2A”)

After configuring the Ethernet related settings or upgrading firmware, the Ethernet card will

send this command to the printer. Use the printer self test to get the Ethernet related

information.

<ESC>KJPETHERNET

*IP addresses setting.

*Syntax: <ESC>KJPETHERNETa,a,a,a,b,b,b,b,

*Parameter: “a,a,a,a,”: IP address

“b,b,b,b,”: subnet mask

Parameters must be HEX values.

*Example:

IP address:192,168,0,42

(“a,a,a,a,”=”0xC0,0xA8,0x00,0x2A)

If “a,a,a,a,”=”0x00 0x2C 0x00 0x2C 0x00 0x2C 0x00 0x2C”, the setting will

become DHCP (auto IP address).

You can send this command to Ethernet card through PC; use the printer self test to get the

Ethernet related information.

This command is for configuring the Ethernet card.

<ESC>KJQETHERNET

*Ethernet card gateway setting.

*Syntax: <ESC>KJQETHERNETc,c,c,c,

*Parameter: “c,c,c,c,”: Ethernet card gateway

Parameters must be HEX values.

*Example:

Gateway:255,255,248,0

(“c,c,c,c,”=”0xFF 0x2C 0XFF 0x2C 0xF8 0x2C 0x00”)

You can send this command to Ethernet card through PC; use the printer self test to get the

Ethernet related information.

Ethernet Printer Technical Manual November 10, 2010

This command is for configuring the Ethernet card.

<ESC>KJR *Ethernet card version.

*Syntax: <ESC>KJRm,nn

*Example: <ESC>KJR5,21; Ethernet card version is 5,21.

After upgrading the firmware, the Ethernet card will send this command to the printer. Use the

printer self test to get the Ethernet card version.

<ESC>KJS Start Page

<ESC>KJT End Page

<ESC>KJU *Ethernet SNMP function

*Syntax: <ESC>KJUmn

m=0, disable the Ethernet SNMP function (default)

m=1, enable the Ethernet SNMP function

n= 1~9 seconds;which the SNMP enquire for the

printer status. (default value:1)

If n=0x0D, this indicates n=1 second. In other words, if n is not

defined, n=1 second.

This command is for printer configuration.

<ESC>KJV Printer aging test

<ESC>KJW *Enquire emulation function

*Syntax: <ESC>KJWmnop

m= total emulation items; m=3~9(0x33~0x39)

Maybe the printer will have more emulation in the future.

n= PPLA emulation; n=0(0x30), PPLA emulation does not exist.

.n=1(0x31), PPLA emulation is used.

o= PPLB emulation; o=0(0x30), PPLB emulation does not exist.

o=1(0x31), PPLB emulation is used.

p= PPLZ emulation; p=0(0x30), PPLZ emulation does not exist.

. p=1(0x31), PPLZ emulation is used.

If the user sends <esc>KJW to enquire emulation through Ethernet card, the printer returns

<esc>KJW3011; This represents that the printer supports 3 emulations but only PPLB and

PPLZ are used in the printer now.

<ESC>KJX Allow the printer LEDs to blink after one of the following conditions:

1. Ethernet card upgrading process is complete.

2. IP address, subnet mask and gateway configuration settings are complete.

<ESC>KJYA *IP Address setting

(Data transfer from the printer to the Ethernet card )

*Syntax: <ESC>KJYAa,a,a,a,b,b,b,b,c,c,c,c

*Parameter: “a,a,a,a,”: IP address

Ethernet Printer Technical Manual November 10, 2010

“b,b,b,b,”: subnet mask

“c,c,c,c”: Ethernet card gateway

Parameters must be HEX values.

*Example:

IP address:192,168,0,42

(“a,a,a,a,”=”0xC0 0x2C 0xA8 0x2C 0x00 0x2C 0x2A 0x2C” )

If “a,a,a,a,”=”0x00 0x2C 0x00 0x2C 0x00 0x2C 0x00 0x2C”, the setting will

become DHCP (auto IP address).

<ESC>KJYB *IP Address setting

(Communication between PC and printer )

<ESC>KJYBm,a,a,a,a[,b,b,b,b,c,c,c,c]

*Parameter: Parameter m is the setting mode; all parameters of the address

must be in HEX format.

Parameter

m a,a,a,a b,b,b,b c,c,c,c

Mode

0x31

Gateway Ignored Ignored

0x32

Subnet Mask

Ignored Ignored

0x33

Subnet Mask

Gateway Ignored

0x34

IP Address Ignored Ignored

0x35

IP Address Gateway Ignored

0x36

IP Address Subnet Mask

Ignored

0x37

IP Address Subnet Mask

Gateway

TABLE1: PARAMETER ID

Parameter ID

( 4 bytes)

Length

(bytes)

Settings

All Parameters 0 0

Firmware Version 2 24 ( Up to 24 characters )

Printer Resolution 5 4 0: 203 4:100

1: 300

2: 600

3: 900

Standard RAM Size

7 4 4GB

Available RAM Size

8 4 4GB

Standard Flash

Memory Size

9 4 0: 2MB

1: 1MB

2: 4MB

A: 1GB

B: 2GB

C: 4GB

Ethernet Printer Technical Manual November 10, 2010

3. 8MB

4. 16MB

5. 32MB

6: 64MB

7: 128MB

8: 256MB

9: 512MB

D: 8GB

E: 16GB

Available Flash

Memory Size

10 4 4GB

DT/ TT 11 4 0: DT mode

1: TT mode

Media Sensor Type

12 4 0: Reflective

1: See Through1

2: See Through2

Print Mode 14 4 00000000: Normal

10000000: Backfeed Enable

20000000: Cutter Enable

30000000:Peeler Enable

Cut Offset 16 4

Peel Offset 17 4

Vertical Offset 18 4

Horizontal Offset 19 4

TPH Offset 20 4

Print Width 21 4 10 ~ 108 (mm)

Print Length 22 4 100 (inches)

Darkness 23 4 1 ~ 15 (0~30)

Speed 24 4 1 ~ 12

Inter Font Symbol

Set

27 4 ab00 total: 4bytes

a: 1=7 bit b: 1~19

0=8 bit

(see table2 and show symbol set)

Total Printed Label

NO.

28 4 (Only F20L have)

Total Printed Label

Length

29 4

Labels CAL. Result

31 4 abcd : total 4 bytes

ab: reflective empty value

cd: see through empty value

Ethernet Printer Technical Manual November 10, 2010

Label Size 32 4

Origin Coordination

Shift

33 4

External Card 34 4 RTC card :0x3000000

Chinese font:0x2010000

Taiwan font :0x2020000

Korean font :0x2040000

Japanese font 0x2080000

Flash Module 36 4 0:External

1:Internal

2: Internal

Serial COMM. 40 8 abcd 0000 total: 8 bytes

a (Baud Rate)

b (Parity)

c (Data Bit)

d (Stop Bit)

a: 0: 9600

1: 2400

2: 4800

3: 19200

4: 38400

5: 1200

6: 115200

7: 57600

8: 600

b: 0: NONE

1: EVEN

2: ODD

c: 0: 8 BITS

1: 7 BITS

d: 0: 1 BIT

1: 2 BITS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Argox Imprimante

Argox

Argox AME-2230B Manuel utilisateur

Argox

Argox CP-2140Z Manuel utilisateur

Argox

Argox OS Series Manuel utilisateur

Argox

Argox D4 250 Manuel utilisateur

Argox

Argox OS-214ZIP Manuel utilisateur

Argox

Argox O4 Series Manuel utilisateur

Argox

Argox MP Series Manuel utilisateur

Argox

Argox A-2240 Manuel utilisateur

Argox

Argox O4 Series Manuel utilisateur

Argox

Argox O4 Series Manuel utilisateur

Argox

Argox iX4 Series Manuel utilisateur

Argox

Argox OS Series Manuel utilisateur

Argox

Argox iX4 Series Manuel utilisateur

Argox

Argox X-2300 Manuel utilisateur

Argox

Argox P4 Series Manuel utilisateur

Argox

Argox CP Series Manuel utilisateur

Argox

Argox Xellent X-1000VL Manuel utilisateur

Argox

Argox AME-3230 Manuel utilisateur

Argox

Argox X2000 Manuel utilisateur

Argox

Argox O4 Series Manuel utilisateur

Argox

Argox A-50 Manuel utilisateur

Argox

Argox PI-10X0 Manuel du propriétaire

Argox

Argox AME-3230 Manuel utilisateur

Argox

Argox R-400plus Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
