Lullaby Mini

AquateX™Bathtub

(formerly Aquastone™)

Installation & Care Manual

USA & Canada

www.aquaticabath.com

E: [email protected]

Lullaby Mini

AquateX™ Bathtub

55.125”

Ø2.0”

Use Male Adapter Spg x MIPT

- ABS DWV for Aquatica®bath wastes

with Sch40 Waste Fitting

Thread 1½ NPSM ( 1½ IPS)

P-Trap

(not supplied)

Male Adapter Spg x MIPT - ABS DWV

for Aquatica®bath wastes with

Sch40 hub outlet.

Thread: 1 ½ NPSM (1 ½ IPS)

Male Adapter Spg x MIPT - ABS DWV

for Aquatica®bath wastes with

Sch40 hub outlet.

Thread: 1 ½ NPSM (1 ½ IPS)

Aquatica®Freestanding

Bath Installer™

(not supplied)

Sch40

Waste Fitting

1½“ ﬂanged brass

tube for Aquatica®

cable-drive and

concealed bath

wastes.

PLEASE NOTE: Parts marked with are supplied as part of Aquatica®Freestanding Bath Installer™ Kit (NOT included with bathtub)

13.75”

0.375”

25.625”

17.50”

27.50”

2.00”

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

A - A

3.125”

52.375”

41.50”

39.125”

18.875”

16.25”

23.75”

Slope: 0.25” - 0.50” per foot

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

MaleAdapter Spg x MIPT - ABS DWV

forAquatica®bath wastes with

Sch40hub outlet.

Thread:1 ½ NPSM (1 ½ IPS)

HANDLE

WITH CARE

DO NOT

DROP

The Male Adapter Spg x MIPT - ABS DWV for Aquatica®bath wastes with Sch40 Waste Fitting

and Aquatica®Freestanding Bath Installer™ are not included with bathtub.

Male Adapter

Spg x MIPT

- ABS DWV

- available for

purchase separately

1 ½ " ﬂanged

brass tube - available for

purchase separately

Sch40

Waste Fitting

Aquatica®

Freestanding

Bath Installer™

in the ﬂoor

- available for

purchase

separately

P-Trap - not

included

Installation is completed by applying

silicone at several points between

the bottom panel and ﬂoor.

Lullaby Mini

AquateX™ Bathtub

www.aquaticabath.com

E: [email protected]

TYPICAL FREESTANDING BATHTUB INSTALLATION PROCEDURE

Before you start:

• Ensure that the floor is even.

• The waste-overflow fitting is supplied with the product, however other accessories like the slip joint

and adaptors are not included and must be purchased separately.

• Because of the technical features of the product, it should be used only with the supplied waste-

overflow or specific 3rd party models that have been tested and approved by us.

• Place the bathtub by raising it up 4” with 4x4 pieces of lumber so you can have access from the

bottom of the bathtub.

INSTALLATION SEQUENCE

• The Lullaby Mini bathtub is equipped with factory pre-installed overflow system.

• The waste pipe/p-trap connection must be made directly to the waste/drain outlet located

at the bottom of the tub.

• Picture 1-2: the bathtub is leveled via a water level at the intended local installation area.

• Picture 3: place the bathtub by raising it up 4” with 4x4 peices of lumber so you can have access

from the bottom of the bathtub. Important note: during the installation, the bathtub should not be

turned on its side to prevent its weight from deflecting its monobloc sides. This is why it is important

to use supports to raise the bathtub above the floor. This will also provide you with easy access to the

internal plumbing parts.

Lullaby Mini

AquateX™ Bathtub

1 2 3

Lullaby Mini

AquateX™ Bathtub

INSTALLATION SEQUENCE continued

• Picture 4: the water outlet pipe should be connected.

• Picture 5: foot leveling lock nuts are adjusted.

• Picture 6: silicone is applied to the feet of the bathtub that stands on the floor.

• Picture 7: when the installation is completed, the bathtub is taken down from the supports

( ie 2 x 4x4's). If necessary, installation is completed by applying silicone at several points between

the bottom panel and floor.

Compatible adaptors for adapting a threaded male connection to a solvent weld connection:

• Mueller Industries: Part # 05913

• Nibco: C4803

http://www.homedepot.com/p/NIBCO-1-1-2-in-PVC-DWV-Hub-x-FIPT-Female-Adapter-C4803HD112/100677994

The adaptor must have the appropriate thread type or it will keep slipping and you will not be able to get

a tight connection!

Male Adapter Spg x MIPT - ABS DWV

for Aquatica®bath wastes with

Sch40 hub outlet.

Thread: 1 ½ NPSM (1 ½ IPS)

Use Male Adapter

Spg x MIPT

- ABS DWV for Aquatica®

bath wastes with

Sch40 Waste Fitting

Thread 1½NPSM

(1½IPS)

Please refer to our

kit installation guide

on page 6

www.aquaticabath.com

E: [email protected]

Aquatica®

Freestanding Bath Installer™

(Kit available separately - not included with bathtub)

178

48mm

238mm

52mm

114

32mm

418

103mm

614

159mm

112

39mm

112

38mm

203mm

112

38mm

1 ½ " brass tube for female threaded

stone bath wastes.

1 ½ " flanged brass tube for Aquatica®

cable-drive and concealed bath wastes.

112

38mm

203mm

112

38mm

1 ½ " brass tube for female threaded

stone bath wastes.

1 ½ " flanged brass tube for Aquatica®

cable-drive and concealed bath wastes.

FEATURES

• 18 Gauge Epoxy coated Metal Deck Flange

• Designed to be installed in an 8” joist space

• Can be installed with Waterproofing Membrane

(*bronte™ NobleSeal TS Recommended)

• CSA Certified for Canadian and US markets

KIT INCLUDES

• 2 Brass tailpieces (Fine Thread and Flanged)

• Freestanding Bath Installer™ assembly

with 1-1/2” DWV ABS tailpiece

• Cutting template

INSTALLATION TIPS

• Use 6.5” hole saw to cut sub floor (not included).

Cutting template included

• Do not cut the brass tailpiece as this may cause a leak

• Secure Deck Flange with 6 screws (not included)

Male Adapter Spg x MIPT - ABS DWV

for Aquatica®bath wastes with

Sch40 hub outlet.

Thread: 1 ½ NPSM (1 ½ IPS)

INSTALLATION INSTRUCTIONS

Attaches to Freestanding Bath W/O

A. Cut 6½” (16.5 cm) hole into wood sub-floor

(use supplied Cutout Template).

B. Measure and cut ABS Tailpiece as necessary

to ensure a secure connection to P-Trap below.

C. Insert Freestanding Bath Installer™ assembly

into floor opening and connect to Pipe below.

D. Affix to sub-floor with 6 screws (not supplied)

A. Install flooring surface, leaving a 6½”

opening to access Drain.

B. Affix the appropriate brass Tailpiece to the Waste

& Overflow. NOTE: DO NOT CUT THE BRASS

TAILPIECE AS THIS MAY CAUSE

A LEAK.

Ensure the measurement between the base of

the Drain and P-Trap will accomodate the Tail-

piece.

A. Cut out the Installation Label with a utility knife and

remove to expose the Drain.

B. Apply lubricant (supplied) to the Tailpiece.

C. Position the Tub and brass Tailpiece in-line with the

Drain.

D. Carefully lower the tub with the installed brass Tail-

piece into the Red Collar in Drain assembly. Ensure

Tailpiece is fully engaged with Seal.

Aquatica®

Freestanding Bath Installer™

(Kit available separately - not included with bathtub)

IMPORTANT: Do not remove Installation Label until Step 3.

DO NOT CUT THE SUPPLIED BRASS TAILPIECE. Doing so may cause a leak.

Disassembling the drain or cutting the Tailpiece will void the warranty.

www.aquaticabath.com

E: [email protected]

www.aquaticaplumbing.com

E: [email protected]

Maintenance Instructions

The smooth surface of your Purescape®

AquateX™ Bathtub accumulates hardly any

dirt, and can be maintained by simply cleaning

with a soft cloth, using a mild detergent in

water, then wiping over with a dry cloth.

Avoid using abrasive cleansers or solvents,

which will cause damage to the surface.

Damage caused by use of these products, or

any other inappropriate treatment, is not

covered by our guarantee.

Инструкция по уходу

Поверхность легко чистится. За счет

гладкости грязь к ней не прилипает. Для

регулярного ухода используйте мягкую

ткань, мыльный раствор и воду. После

чистки вытирайте поверхность сухой тканью,

которая хорошо впитывает влагу.

Не используйте губки с абразивной

поверхностью и агрессивные растворители,

которые могут повредить ванну.

Повреждения, возникшие вследствие

неправильного ухода, не покрываются

гарантией.

Installation & Entretien

Cette surface est facile à entretenir et à nettoyer.

Sa surface particulièrement lisse, ne retiens que

très peu la saleté. Un entretien quotidien

nécessite simplement l’utilisation d’un chiffon

doux, de l’eau et un peu de savon. Essuyer avec

un chiffon sec. L’utilisation de détergents ou de

solvant endommageraient cette surface.

Les dommages resultants d’un traitement non

conforme effectué par l’utilisateur sont exclus de

la garantie que nous offrons.

Manuale per il corretto mantenimento

La superficie necessita di pulizia ed

accorgimenti per il corretto mantenimento.

Una superficie liscia non accumula lo sporco.

Usare una spugnetta con del detergente non

aggressivo per una pulizia regolare. Asciugare

con un panno. Evitare l’uso di solventi o

materiali abrasivi: potrebbero rovinare la

superficie.Un danno causato da trattamento

inappropriato non verra’ coperto dalla garanzia.

Instrucciones para la correcta manutención

La superficie debe de ser limpiada y

adecuadamente mantenida. Una superficie lisa

no acumula suciedad.

Utilice una esponja con un detergente suave

para la limpieza diaria. Seque con un paño.

No utilice disolventes o materiales abrasivos ya

que podrían dañar la superficie.

Los daños causados por el tratamiento

inadecuado no serán cubiertos por la garantía.

Lullaby Mini - Maintenance Instructions

Lullaby Mini - Инструкция по уходу

Lullaby Mini - Installation & Entretien

Lullaby Mini - Manuale per il corretto mantenimento

Lullaby Mini - Instrucciones para la correcta manutención

Table des matières

Autres manuels Aquatica Digital Baignoire

Aquatica Digital

Aquatica Digital Lullaby Mini Manuel utilisateur

Aquatica Digital

Aquatica Digital Purescape 118L Instructions d'utilisation et d'entretien

Aquatica Digital

Aquatica Digital AquateX True Ofuro Manuel utilisateur

Aquatica Digital

Aquatica Digital Olivia Manuel utilisateur

Aquatica Digital

Aquatica Digital Tulip Manuel utilisateur

Aquatica Digital

Aquatica Digital True Ofuro Duo Manuel utilisateur

Aquatica Digital

Aquatica Digital AquateX Corelia Manuel utilisateur

Aquatica Digital

Aquatica Digital HydroRelax Series Manuel utilisateur

Aquatica Digital

Aquatica Digital True Ofuro SuperGrip Manuel utilisateur

Aquatica Digital

Aquatica Digital AquateX Lullaby Manuel utilisateur

Aquatica Digital

Aquatica Digital EcoMarmor Instructions originales

Aquatica Digital

Aquatica Digital True Ofuro Tranquility Series Manuel utilisateur

Aquatica Digital

Aquatica Digital True Ofuro Tranquility Series Manuel utilisateur

Aquatica Digital

Aquatica Digital Corelia Manuel utilisateur

Aquatica Digital

Aquatica Digital Sensuality Aquastone Manuel utilisateur

Aquatica Digital

Aquatica Digital Spoon2 Purescape 204AM Manuel utilisateur

Aquatica Digital

Aquatica Digital AquateX Corelia Manuel utilisateur

Aquatica Digital

Aquatica Digital AquateX Lillian Guide de configuration

Aquatica Digital

Aquatica Digital AquateX Purescape 720 Manuel utilisateur

Aquatica Digital

Aquatica Digital Baby Boomer Manuel utilisateur

Aquatica Digital

Aquatica Digital Harmony Duo Manuel utilisateur

Aquatica Digital

Aquatica Digital PureScape 171 Mini Manuel utilisateur

Aquatica Digital

Aquatica Digital Illusion AquateX Manuel utilisateur

Aquatica Digital

Aquatica Digital PureScape 028 Series Manuel utilisateur

Manuels Baignoire populaires d'autres marques

Agua

Agua BARTOLI-66 Manuel utilisateur

PAA

PAA PRELUDE Manuel utilisateur

BETTE

BETTE SILHOUETTE Manuel utilisateur

Kohler

Kohler K-820-GC Guide de démarrage rapide

American Standard

American Standard Whirlpool/Bathing Pool 2748.XXXW Manuel utilisateur

Oliveri

Oliveri Naples Manuel utilisateur

Lyons

Lyons Elite ETLxx663219 Series Manuel utilisateur

Woodbridge

Woodbridge BJ500 Instructions de montage

Whirlpool

Whirlpool Ariel ARL-702 Manuel utilisateur

TEIKO

TEIKO EXCELLENT DUO Manuel utilisateur

American Standard

American Standard Colony 5-1/2' x 32" Manuel utilisateur

American Standard

American Standard 3052OD.X0X Guide de démarrage rapide

Kohler

Kohler K-1111-H2 Guide de démarrage rapide

agape

agape MARSIGLIA AVAS1075 Manuel utilisateur

Kohler

Kohler K-1151 Instructions de montage

Kohler

Kohler K-1158 Guide de démarrage rapide

Kohler

Kohler K-1244 Instructions de montage

Kallista

Kallista P50045-G5 Instructions de montage
