Aquatic SERENITY STUDIO 35 Manuel utilisateur

SPECIFICATIONS:

The manufacturer accepts a 1/4” variance. There are variations on each tub and speciﬁcations are subject to change as we improve upon our product

as required. The dimensions needed for site preparation and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no

responsibility for preparatory work.

www.aquaticwhirlpools.com 800.555.5324

June 2008

SErENITy STudIO 35

GENERAL SPECIFICATIONS:

Tub Size 59 3/4” x 36” x 24”

152 cm x 91 cm x 61 cm

Bathing Well 38” long

21” wide

21” interior depth

Maximum Water Depth 17 1/2”

Shipping Weight 158 lbs. / 72 kg

Tub Weight Filled 779 lbs. / 353 kg

Tub Only Weight 88 lbs. / 40 kg

Weight with Equipment 98 lbs. / 44 kg

Gallons to Overow 82 gal. / 310 L

ELECTRICAL SPECIFICATIONS:

Blower/Heater 1 HP; 10.5 AMP; 120V

Requirement 15 AMP; 120V, separate circuit

required protected w/ Class A GFCI

STANDARD EQUIPMENT: OPTIONAL EQUIPMENT:

SErENITy STudIO MODEL # AI35AIR6036/AI35AIR6036TO (Tub Only)

Deck

Width

4”

36”

Deck Width

3 3/4”

38”

21”

36”

22”

24”

59 3/4”

20 1/2”

Air Bath System:

- 70 Air Jets

- 1 HP Variable Speed Air Blower with 20-Minute Timer

- 600 Watt Air Heating System

- Electronic Control Package with Wave and Pulse Features

- Automatic Purge and Dry Cycle with Water Sensors

Aquatic Quality Features:

- Chromatherapy

- Slip Resistant Floor

- Air Channels Lined with Antimicrobial Coating

- Pre-leveled ABS Support Base

- Durable, Easy to Clean, Lucite® Cast Acrylic Surface

- Available in 8 Standard No-Charge Colors

UL & IAPMO Listed, Factory Tested

Limited Lifetime Warranty

• Comfort Pillow - Oval or Rectangle

• Bolt-On Grab Bars

- White, Biscuit, Chrome, Polished Brass, Gold,

Polished Nickel, Satin Nickel or Oil Rubbed Bronze

• Lift & Turn Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel or Oil Rubbed Bronze

• Cable Drive Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel, Oil Rubbed Bronze or

Color Matched (Bone, White and Biscuit Only)

• Waterproof Remote Control with infrared sensor

and 25’ cord

• Remote Blower Wiring Kit

• Integral Tiling Flange (Customer must specify which

side(s) should receive ange)

• Color Matched Acrylic Skirt

• Premium Colors

All acrylic colors featured by Aquatic match the

industry’s leading xture manufacturers.

Each Serenity Air Bath model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air temperature will

be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air coming from the air jets

will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.

Fax-On-Demand

Document # 1148

Back Angle

26°

Rough-In Plumbing

Measurements

2 3/4”

10 3/4”
