APW Wyott M-83 Manuel utilisateur

Rev. 1/1/2003

Bun Grill

Toaster

PRODUCT: QUANTITY: ITEM#:

Model: M-83 120V M-83 208V M-83 240V

APW Wyott Design Features

Designed Smart.

Developed for high output

• The APW Wyott M-83 Bun Grill can generate up to 1600

Bun Halves per hour.

• Bun Grill is available with Super Feeder to allow for high

volume production.

• Fast warm-up allows your operation to react to surges in

volume.

Perfectly Carmelized Buns all the time

• Patented “self-leveling” conveyor automatically adjusts to

various sizes of buns, bagels, and Texas Toast.

• Butter roller and pan consistently covers buns with the

perfect amount of butter.

• Durable steel griddle plate is controlled with an electro-

mechanical thermostat adjustable to temperatures

between 200 and 500 degrees.

Easy to Maintain and Service

• Removable side panel allows easy access for service.

Built Solid.

Built to Last

• Stainless steel construction protects against kitchen ‘wear

and tear’ and rust.

• High temperature insulated wire is used for long life.

Easy to fit into all Counter Spaces

• Compact, vertical design allows unit to fit into tight

counter areas.

Reliability backed by APW Wyott’s Warranty

• All APW Wyott Bun Grills are backed by a

1-year Parts and Labor warranty,

including On-Site Service calls within

50 miles of authorized service

technicians.

• Certified by the following agencies:

• Heavy-duty stainless steel construction.

•6

feeder, “butter” roller and “butter” pan standard.

• Patented conveyor chain that automatically adjusts to

almost all sizes of buns, rolls and Texas toast.

• 1/2

griddle plate for better heat distribution.

• Fast warm-up.

• Permanent grill surface — never needs replacing.

• Use wet or dry.

• Compact vertical style saves space.

• Fast — up to 1600 pieces per hour.

• Caramelized bun surface — buns never get soggy.

• Adjustable legs.

• Snap-lock construction, easy to clean, fewer parts.

Options

M-83: Speed up gear: fast speed — 26 sec. (85048)

Slow down gear: med. speed — 45 sec. (85045)

Slow down gear: slow speed — 85 sec. (85050)

Bun Superfeeder, Factory reconditioning kit (89525)

Teflon sheet kit (10 sheets) (87449)

MODEL M-83 BUN GRILL TOASTER

CUS

PRODUCT: QUANTITY: ITEM#:

Model M-83 Bun Grill Toaster

Bun Grill

Toaster

Model: M-83 120V M-83 208V M-83 240V

PRODUCT SPECIFICATIONS

Construction:

Heavy-duty stainless steel construction.

4 inch adjustable legs.

Electrical Information:

Each unit is equipped with a 39”, three wire grounded

power cord which terminates with a standard three-

pronged male plug. The 120V unit uses a NEMA 5-15P

plug. The 208/240V units use a NEMA 6-20P plug.

Electrical Specifications:

M-83: 120V, 1600W, 13.3 Amps

208V, 1600W, 7.7 Amps

240V, 1600W, 6.7 Amps

Overall Dimensions:

M-83: 20

H x 245⁄8

W x 12

(50.8 cm x 62.5 cm x 33.0 cm)

M-83: With Superfeeder

H x 245⁄8

W x 161⁄2

(78.7 cm x 62.5 cm x 41.9 cm)

Shipping Weight:

M-83: 97 lbs. (44 kg)

Capacity:

M-83: Up to 1600 pieces per hour.

World Class Support

World Class Sales Support to assist you with finding the right

solution to your operation’s needs. Call Customer Service at

(800) 527- 2100 or Fax your request to (214) 565-0976.

For more information about APW Wyott’s World Class Support and

High Performance Equipment, look us up on the Internet at

www.apwwyott.com

Most Extensive Service System in the Industry! APW Wyott

has two levels of service support for your needs:

• Direct Service Hot Line to Service Department, call

(800) 527-2100.

•

To find the Registered Service Technician in your area, call

Automated Service Hot Line at (800) 733-2203.

Rev. 1/1/2003

#1710
