Apricorn Xtreme Upgrade Manuel utilisateur

Introducing Apricorn’s next generation hard drive upgrade kit,

the Xtreme Upgrade. The Xtreme Upgrade kit is a complete

hardware and software solution which enables users to upgrade

their PATA/IDE or SATA hard drive utilizing the latest hard drive

technology. The kit comes with everything you will need to quickly

transfer all les, e-mail settings, applications and the operating system

from the hard drive in your notebook to the new Xtreme hard drive.

Apricorn's 7200 RPM Xtreme Drive is the fastest available hard drive for

notebook computers. This drive can improve overall system performance

by 30%, providing desktop performance in a notebook computer.

Once the new drive is installed in the notebook, the old drive can be installed

in the Xtreme Upgrade’s Hi-Speed USB 2.0 enclosure for either external storage

or backup.

The kit comes bundled with a 7200 RPM SATA hard drive, Apricorn's Upgrade Suite

CD, a Hi-Speed USB 2.0 hard drive enclosure, (USB 1.1 compatible) 1 meter USB cable

and an AC power adapter.

Apricorn's Upgrade Suite includes:

Apricorn’s EZ Gig II for Windows and ShirtPocket SuperDuper! for Mac.

EZ Gig II is comprised of two modules: Disk Clone & Disk Image Ideal for users who require

an exact copy of their hard drive. Disk Clone creates an exact copy of the original hard

drive including the operating system, les, folders favorites and system settings. A cloned

copy of a hard drive can be used for disaster recovery backup, or as a hard drive upgrade.

Disk Image takes a snapshot of your entire system and compresses it into a le up to half

its original size. This method takes up less space, thus allowing multiple backups to a single

drive. The Image option also allows restoration of individual les or folders and a password

to be assigned to a backup image, providing security for your data. A detailed description

for each image can be entered giving the user total exibility to retain backups from multiple

dates, or multiple computers.

ShirtPocket SuperDuper! for Mac is a highly acclaimed program that makes recovery painless,

because it makes creating a fully bootable backup painless. Its incredibly clear, friendly

interface is understandable, easy to use. And it runs beautifully on both Intel and Power PC

Macs! SuperDuper’s interface conrms all your actions in simple, clear language to ensure that

the end result is exactly what you intended.

Visit our website at www.apricorn.com or call 1-800-458-5448

• WorkswithbothPATA/IDE&

 SATAharddrives

• 3simplestepstoabigger,

faster system

• Comesbundledwitha7200RPMHDD-

Achieve desktop performance

 fromyournotebookcomputer

• 8MBcache-400%largerthan

standard drives

•Increase overall system

performanceupto30%over

standard drives

• Lightening fast transfers via

Hi-SpeedUSB2.0

 (USB1.1compatible)

• Includes Apricorn's

UpgradeSoftware

Suite for PC & Mac

• Converts old drive

into external

 Hi-Speed

 USB2.0

storage

device

• Plug-n-Play

• 3Year

 warranty

For more information on Xtreme Upgrade and other innovative Apricorn products visit our

website at www.apricorn.com or call 1-800-458-5448

Features Benets

Simple three step upgrade process EZ Upgrade is a three-step hard drive upgrade system that seamlessly automates and

simplies the task of upgrading your notebook hard drive.

7200 RPM SATA hard drive Achieve desktop performance on your notebook computer

Hi-Speed USB 2.0 backup system After the upgrade is complete, the old drive can be used as a portable Hi-Speed USB

2.0 backup system.

Universal 2.5" hard drive compatibility Works with any PATA/IDE or SATA 2.5" laptop hard drives

Operating System Compatibility PC and Mac compatible

Plug-n-Play Drivers not required for Windows® 2000, XP, Vista or Mac® OS

Hot Swappable No need to power down, just plug and go

Box Contents EZ Upgrade hard drive enclosure, 7200 RPM SATA 2.5" hard drive, Upgrade Suite Soft-

ware CD, USB cable & AC power adapter

Apricorn's Upgrade Suite CD Programs for PC and Mac

Upgrade & Cloning Software EZ Gig II for Windows®

ShirtPocket SuperDuper! for Mac®

Hard Drive Health Monitor SMART-ER for Windows

Specications

Capacities SATA: 120,160 & 200GB

Data Buffer 8 MB

Rotational Speed 7200 RPM

Data Transfer Rates USB 2.0 - Up to 480Mbps

Power Supply AC power adapter required

Hard Drive Interface SATA & PATA/IDE

Dimensions 19mm X 84mm X 148mm

Warranty 3 year limited

Approvals FCC & CE

PC System Requirements CD-ROM Drive, 128MB RAM, Pentium ® CPU II, available powered USB port

Supported Operating Systems:

Windows Vista Home basic/premium, Ultimate & Business

Windows XP Home and Professional

Windows 2000 Professional

MAC ®System Requirements CD-ROM Drive, Apple® G3 or later, 64 MB RAM, available powered USB port, Sup-

ported Operating Systems: Mac® OS 9.2 or later & Mac OS X 10.2 or later

*One gigabyte (GB) = one billion bytes; accessible capacity will be less and actual capacity depends on the operating environ-

ment and formatting.
