AC Input Alarm Trips, Isolated, Factory Configured APD 1600, APD 1620
Input: 0-50 mVAC to 0-300 VAC, 0-1 mAAC to 0-1000 mAAC
Output: Two 8 Amp SPDT Relays
OFactory Set AC Input Range
OAdjustable Setpoint and Deadband Potentiometers
OInput LoopTracker®and Alarm Status LEDs
OFull 1200 V Isolation
OAlarm Test, Optional Reset Button
QProcess Limit Backup Alarm
QOver or Under Voltage or Current Alarm
QHeater Break, Conveyor Jam Alarm
Applications
AC Input Range
Factory configured, please specify input type and range
Consult factory for special ranges
Voltage: 0-50 mVAC to 0-300 VAC
Current: 0-1 mAAC to 0-1000 mAAC
Measurements are true RMS
Input Impedance (Voltage Input)
220 kΩminimum
Input Voltage Burden (Current Input)
1.0 VRMS maximum
Input Frequency
40 Hz to 1000 Hz sinusoidal
Isolation
Power to input isolation: 1200 V
Common mode protection: 750 VACpor 750 VDC
LoopTracker
Variable brightness LED indicates input level and status
APD 1600 Relay Output
Dual SPDT Form C contact sets operating in unison
1 setpoint adjustment, 1 deadband adjustment
Standard: HI alarm, non-latching, normal acting
Options: LO alarm, latching, reverse acting
APD 1620 Relay Output
2 independent SPDT Form C contact sets
2 setpoint adjustments, 2 deadband adjustments
Factory configured alarm
Standard: HI/LO alarm, non-latching, normal acting
Options: LO/LO, HI/HI, LO/HI alarms, band alarms,
latching, reverse acting
Relay Contact Ratings
8 A max @ 240 VAC
resistive load
External contact
protection such as
an RC snubber is
recommended for
inductive loads
Setpoint
12 turn potentiometer adjustable from 0 to 100% of span
Deadband
12 turn potentiometer adjustable from 1 to 100% of span
Response Time
70 milliseconds typical
Output Test/Reset Button
Front button or external contact closure toggles relays to
opposite state when pressed.
Resets relay if latching relay option is ordered
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than 1% of span over operating temperature range
Better than 0.02% of span per °C
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than 0.02% of span per °C
Switching Current (A)
Switching Voltage (V)
0 3 5 10 30 50 100 300 500
8
5
3
1
0.5
0.3
0.1
AC inductive load
(cos f= 0.4) AC resistive
load
DC inductive load
(L/R = 7 ms)
DC resistive
load
Model Input Standard Alarm Configuration Power
APD 1600 Factory ranged, specify
mVAC, VAC, or
mAAC range
Single setpoint dual SPDT relays
HI alarm, non-latching, normal acting
85-265 VAC or 60-300 VDC
APD 1600 D 9-30 VDC or 10-32 VAC
APD 1620 2 setpoints, 2 SPDT relays
HI/LO alarms, non-latching, normal acting
85-265 VAC or 60-300 VDC
APD 1620 D 9-30 VDC or 10-32 VAC
Alarm Options—add to end of model number
LAPD 1600 with LO trip. Alarm trips on decreasing signal.
HH APD 1620 with HI/HI trip. Alarms trip at their respective
trip points on increasing signal.
LL APD 1620 with LO/LO trip. Alarms trip at their respective
trip points on decreasing signal.
LH APD 1620 with LO/HI trip. Alarm 1 trips on decreasing
signal. Alarm 2 trips on increasing signal.
BA APD 1620 with band alarm. Alarm trips if signal is outside
LO and HI trip points.
IBA APD 1620 with inverse band alarm. Alarms trip if signal is
between LO and HI trip points.
HT Latching alarm with push button reset
HP Latching alarm with power-off reset. Module power
must be turned off to reset alarms
RA Reverse-acting alarms. Relay coils energized in an alarm
condition. No alarm condition with module power off.
UConformal coating for moisture resistance
Spare Connector
API BP4 4 terminal plug, black
© 03-22
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: 800-942-0315 Fax: 800-949-7502
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
Description
The APD 1600 and 1620 accept an AC voltage or milliamp
current input and provide a visual alarm indication and alarm
relay contact outputs.
The input type, range, and alarm types are factory configured.
Front-accessible potentiometers are used to adjust alarm
setpoint and deadband.
LoopTracker and Alarm Status LEDs
API exclusive features include a LoopTracker LED that varies in
intensity with changes in the process input signal.
A red/green bi-color alarm status LED (two on the APD 1620)
visually indicate alarm status.
These LEDs provide a quick visual picture of your process at
all times.
Output Test / Unlatch
API's exclusive Output Test button can be used to verify the
alarm and system operation and also provides the additional
function of unlatching the alarm when the latching option has
been ordered. This feature can be remotely operated.
The output test button greatly aids in saving time during initial
startup and/or troubleshooting.
Dimensions
0.89" W x 4.62" H x 4.81" D
(22.5 x 117 x 122 mm)
Height includes connectors
Housing and Connectors
IP 40, requires installation in panel or enclosure
For use in Pollution Degree 2 Environment
Mount vertically to a 35 mm DIN rail
Four 4-terminal removable connectors, 14 AWG max wire size
Power
85-265 VAC, 50/60 Hz or 60-300 VDC, 2 W maximum
D versions: 9-30 VDC or 10-32 VAC 50/60 Hz, 2 W maximum
Quick Link: api-usa.com/1600
Universal Power
Alarm Status LED
Input LoopTracker LED
Alarm Test Function
Adjustable Deadband
Two 8 Amp SPDT
Alarm Relays
Custom Input Ranges
Removable Plugs
File E145968
85-265 VAC, 60-300 VDC
model only
Adjustable Setpoint
Free Factory
I/O Setup!
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
See Wiring
Diagrams on
Next Page
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
Applications Link
api-usa.com/apps
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
Made in USA
Installation and Setup APD 1600, APD 1620
Precautions
WARNING! All wiring must be performed by a qualified electrician
or instrumentation engineer. See diagram for terminal designa-
tions and wiring examples. Consult factory for assistance.
WARNING! Avoid shock hazards! Turn signal input, output, and
power off before connecting or disconnecting wiring, or remov-
ing or installing module.
Précautions
ATTENTION! Tout le câblage doit être effectué par un élec-
tricien ou ingénieur en instrumentation qualifié. Voir le dia-
gramme pour désignations des bornes et des exemples de
câblage. Consulter l'usine pour assistance.
ATTENTION! Éviter les risques de choc! Fermez le signal
d'entrée, le signal de sortie et l'alimentation électrique avant
de connecter ou de déconnecter le câblage, ou de retirer ou
d'installer le module.
Electrical Connections
See wiring diagrams. If the module does not function, check
all wiring.
*Do not make any connections to unused terminals or use
them as wiring junctions for external devices. This may cause
permanent damage to the module!
Input
The input range is factory pre-configured (at 24°C ±1°C). See
the model/serial number label for module information, input
type, input range and options. Connect the input as shown in
the wiring diagrams.
Alarm Types
Note that the deadband is symmetrical about the setpoint; relay
trip and reset points will both change if either the setpoint or
deadband are changed.
High Alarm (default, H, or HH): The alarm relay changes state
when the input exceeds the deadband trip point. The relay
resets when the input drops below the deadband reset point.
For a high alarm, the trip point is above the reset point.
Low Alarm (L or LL): The alarm relay changes state when the
input goes below the deadband trip point. The relay resets
when the input exceeds the deadband reset point. For a low
alarm the trip point is below the reset point.
HT: Latching alarm with push button reset
HP: Latching alarm with power-off reset. Module power must
be turned off to reset alarms
R: Reverse-acting alarms. Relay coils energized in an alarm
condition. No alarm condition with module power off.
Relay Output Terminals
See wiring diagrams below right for connections. APD modules
do not provide power to the relay contacts. Inductive loads
(motors, solenoids, contactors, etc.) will greatly shorten relay
contact life unless an appropriate RC snubber is installed.
The APD 1600 operates two sets of relays in unison with a
single setpoint. The dual SPDT contact sets are in a Form C
configuration.
The APD 1620 operates two sets of relays independently, each
with its own setpoint. The dual SPDT contact sets are in a Form
C configuration.
Module Power
Check model/serial number label for module operating voltage
to make sure it matches available power.
When using DC power, either polarity is acceptable, but for
consistency with similar API products, positive (+) can be wired
to terminal 13 and negative (–) can be wired to terminal 16.
Mounting to a DIN Rail
Install module vertically on a 35 mm DIN rail in a protective
enclosure away from heat sources. Do not block air flow. Allow
1" (25 mm) above and below housing vents for air circulation.
1. Tilt front of module downward and position against DIN rail.
2. Clip lower mount to bottom edge of DIN rail.
3. Push front of module upward until upper mount snaps into place.
Removal
1. Push up on the bottom back of the module.
2. Tiltfrontofmoduledownwardtoreleaseuppermountfromtop
edge of DIN rail.
3. The module can now be removed from the DIN rail.
Setpoint and Deadband Adjustments
Relay operation is factory configured. See model/serial number
label for relay configurations and options.
The Setpoint potentiometer allows the operator to adjust the
level at which the alarm is activated. This control is adjustable
from 0 to 100% of the input range.
The Deadband potentiometer allows the alarm trip and reset
window to be adjusted symmetrically about the setpoint from
1 to 100% of the span. This allows the operator to fine tune
the point at which the alarm trips and resets. The deadband is
typically used to prevent chattering of the relays or false trips
when the process signal is unstable or changes rapidly.
To calibrate the alarm section, set the deadband control to the
minimum (counterclockwise). The deadband will be 1.0% of
input span in this case.
Set the signal source to a reference that represents the desired
trip point.
Adjust the setpoint control to the point at which the relay
changes state from a non-alarm to an alarm condition.
If a larger amount of deadband is desired turn the deadband
potentiometer clockwise. The deadband is symmetrical about
the setpoint; both transition points will change as deadband
is increased.
Relay set and reset points will both change if the setpoint or
deadband are changed. Alternately set the setpoint and dead-
band until the desired trip and rest points are set.
Output Test Function
When the front test button is depressed it will drive the relays
to their opposite state. A customer-supplied switch connected
to terminal 4 and 8 can also be used to toggle the relays. When
released, the relays will return to their prior states.
This can be used as a diagnostic aid during initial start-up or
troubleshooting, or as a manual over-ride function. The Test
button also resets the relays on models with the HT option.
Operation
The green LoopTracker®input LED provides a visual indication
that a signal is being sensed by the input circuitry of the mod-
ule. It also indicates the input signal strength by changing in
intensity as the process changes from minimum to maximum.
If the LED fails to illuminate, or fails to change in intensity as
the process changes, check the module power or signal input
wiring. Note that it may be difficult to see the LEDs under bright
lighting conditions.
The bi-color alarm LED provides a visual indication of the alarm
status. In all configurations, a green LED indicates a non-alarm
condition and a red LED indicates an alarm condition.
In the normal mode of operation, the relay coil is energized in
a non-alarm condition and de-energized in an alarm condition.
This will create an alarm condition if the module loses power.
For a normal acting, non-latching configuration, the alarm will
activate when the input signal exceeds the setpoint (HI alarm)
or falls below the setpoint (LO alarm), then will automatically
reset when the alarm condition no longer exists.
For a reverse acting alarm, the relay coil is de-energized in a
non-alarm condition and energized in an alarm condition. The
alarm activates when the input signal exceeds the setpoint (HI
alarm) or falls below the setpoint (LO alarm), then automatically
resets when the alarm condition no longer exists.
For models with the latching relay option, it will be necessary
to push the Test button or remove power from the module to
reset the alarm, depending on the type of latching option. The
alarm will only reset if the alarm condition no longer exists.
Module Power
AC or DC +
AC or DC –
1413 15 16
Cu 60/75°C
conductors
14 AWG
max.
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
Input
Relay 1
Power
Relay 2
4 and 84 and 8
Relay TestRelay Test
Test Input
APD 1600
AC Input to
Single Alarm Trip
Loop
Tracker
Deadband
Setpoint
Alarm
Test
APD 1620
AC Input to
Dual Alarm Trip
Input
Loop
Tracker
Deadband 1
Setpoint 1
Alarm 1
Deadband 2
Setpoint 2
Alarm 2
109 11 12
Current or
Voltage
Device
Sinking mA Input
or Voltage Input
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: 800-942-0315 Fax: 800-949-7502
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
Relay Wiring APD 1600
NO C NC
21 3 4
65 7 8
NO C NC
Customer-Supplied
Remote Test Switch
NO C NC
21 3 4
65 7 8
NO C NC
Customer-Supplied
Remote Test Switch
RLY 1
RLY 2
Relay Wiring APD 1620
Wire terminal torque
0.5Nm to 0.6Nm
(4.4 to 5.3 in-lbs)
To maintain full isola-
tion avoid combining
power supplies in
common with input,
output, or unit power.
API maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. See api-usa.com for
latest product information. Consult factory for your specific requirements.
WARNING: This product can expose you to chemicals includ-
ing nickel, which is known to the State of California to cause
cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
* Do not make
connections to
unused terminals!
* Do not make connections to
unused terminals!
Ce manuel convient aux modèles suivants
3
Autres manuels API Changer
