ANTIFERENCE ASM02 Manuel utilisateur

ASM02

Digital Signal Meter for Satellite &Terrestrial with DSCR Mode & Data Logging

User Guide

Important Safety Notice

Thank you for purchasing this Antiference signal analyser product. Please read

the following instructions carefully, retain for future reference and read the

following safety considerations:

1. Do not place any items on the device

2. Ensure no liquids are on or near the device as splashes may damage the unit

3. For cleaning, use a damp cloth only without solvents

4. Do not attempt to open the case as there is a danger of electric shock

5. Repairs should be carried out by a qualied technician

6. Keep the protective jacket in place while using the meter

7. Store the meter in the carry case when not in use to protect the screen from

damage

8. Use only the supplied power supply as 3rd party products may damage the

product

Contents

1. Introduction

2. Features

3. Package Contents

4. Front & Top Panel Layouts

4.1 Top Panel Layout

4.2 Front Panel Layout

5. Main Menu

6. DVB-S/S2 Mode

6.1 Measurement

6.2 Spectrum

6.3 Constellation

6.4 Dish Setup

6.5 Motor Settings

6.6 Angle Calculation

6.7 TP Control

6.8 Datalog

6.9 DSCR

7. DVB-T/T2 Mode

7.1 Measurement

7.2 Spectrum

7.3 Constellation

7.4 Scope

7.5 Datalog

8. DVB-C Mode

8.1 Measurement

8.2 Spectrum

8.3 Constellation

8.4 Scope

8.5 Datalog

9. DAB/DAB+

10. DiSEqE Monitor

11. Settings

12. Help

13. Memory

14. LNB/RF Overload

15. Program Play Menu

16. Technical Specications

17. Declaration of Conformity

Page

Table of Contents

The Antiference ASM02 is an advanced signal analyser for satellite and terrestrial signals.

It features an 8.9 inch touch screen display and simple to use menu system. It supports

DVB-S/S2/DVB-T/T2/DVB-C/C2, DAB/DAB+. Also included is a DSCR mode for

analysis of SKY Q systems and a data logging function allowing the user to download

logs to a USB drive and view in an Excel spreadsheet. Supplied in a protective holder

and carry case, this meter is ideal for use in the eld for professional installers.

2. Features

• 8.9 inch touch screen display

• Supports DVB-S/S2/DVB-T/T2/DVB-C/C2, DAB/DAB+

• Video decoding: MPEG- 1, MPEG-2, MPEG-4, H.263, H.264, HVEC/H.265(up to

4K@60fps),AVS,VC-1,VP8, MVC

• Audio decoding: MPEG-1, MPEG-2, ISO/IEC 13818-3 LAYER I&II

• Measurement values MER, dbµV,VBER, CBER, LBER

• LNB & RF short circuit protection

• Signal lock audible notication

• Data log function

• USB interface for data log download & rmware updates

• HDMI output

• LED ashlight

• Li-ion battery [email protected] with fast charging function

• OSD with multi-languages

• Internal storage

• Protective case

• Power supply 100-240V/50/60Hz 12V 2000mA

1. Introduction

3. Package contents

4. Front & Top Panel Layouts

4.1.Top Panel Description

1. Satellite LNB Input

2. Terrestrial RF Input

3. Reset Button

4. HDMI Output

5. USB Interface

6. 12V DC Input

7. On/off Switch

1. ASM02 Signal Meter

2. 12V 2000mA Mains Charger with 3 Pin UK Plug

3. 12V In-Car Charger

4. Soft Carry Case

5. Rubber/Plastic ASM02 Protective Jacket

6. F Connector Adaptors

7. 4 Point Shoulder Strap

4. Front & Top Panel Layouts (cont)

4.2. Front Panel Description

1. Green LED.When lit, indicates 13V is enabled in DVB-S/S2 mode

2. Green LED.When lit, indicates 18V is enabled in DVB-S/S2 mode

3. Green LED.When lit, indicates 22KHz tone is enabled in DVB-S/S2 mode

4. Green LED.When lit, indicates 5V DC power is enabled in DVB-T mode

5. Green LED.When lit, indicates 12V DC power in is enabled in DVB-T mode

6. Charging Indicator LED. Red when charging, blue when charged

7. Red LED. Lit to indicate a short on the LNB or RF input

8. Power Indicator LED. Green when on.

9. Mode button to toggle between TV mode and measurement

10. LED/ashlight on/off control button.

11. Increase volume

12. Decrease volume

13. Menu button

14. Exit menu button

15. Search function. Press to scan for channel in measurement mode

16. Store button. Press to save screen shots

17. Hotkey F1

18. Hotkey F2

19. Hotkey F3

20. Hotkey F4

21. Info button

5. Main Menu

When the ASM02 has booted, the main menu will appear.To navigate to the sub-menu’s,

simply tap the icon of the mode you wish to operate and the menu for that function will

appear.

To return to the previous menu, press [EXIT]

Tap DVB-S/S2 icon to enter the satellite measurement menu.This menu shows all the

analysis of the incoming satellite signal.The available satellite channel plans are listed

down the left hand side of the screen and the measurement details on the right.

Select the satellite required from the list to begin.

Once the satellite is selected, choose the transponder required from the next column

by tapping the frequency value. Scroll to see additional transponders not in view.

Tap and hold the transponder value to enter manual edit mode. Pop up window will

appear.

6.1. Measurement Menu

6. DVB-S/S2 Mode

6.1. Measurement Menu (cont)

Tap the [BACK] icon to return to the main menu

Tap the [SPECTRUM] icon to enter spectrum mode

Tap the [CONSTELLATION] icon to enter constellation mode

Tap the [DISH SETUP] icon to enter the dish setup menu

Tap the [ANGLE SETTING] icon to view the angle calculation menu

Tap the [TRANSPONDER] icon to enter the transponder control menu

Tap the [ZOOM] icon to enter the zoom menu

This icon indicates a signal lock

This icon indicates a signal no lock

Tap this icon to start a pop-up channel scan

Explanation of Functions in DVB-S/S2 Mode

6. DVB-S/S2 Mode

6.1. Measurement Menu (cont)

MER - Modulation error ratio value

LKM - Link margin test results

CBER - CBER test results

LBER - LBER test results

Pilot Pattern - The pilot pattern of signal value

Orbit Position - The orbit position of the TS in the NIT table

TS Bit rate - The bit rate of the input TS

Freq Offset - The offset value of the setting frequency and input signal

Feed Current - The feed current of the LNB port

FeedVoltage - The feed voltage of the LNB port

ONID - The Original Network ID of the input transport stream

TSID - The Transport Stream identication of the input stream

66.1dBµV - The power level of the input signal

DVB-S QPSK 5/6 - DVB type, demodulation type & FEC value

Explanation of Elements

Dish Set Up TP Control Mute Help

Hot Key Function in DVB-S/S2 Mode

6. DVB-S/S2 Mode

Tap this icon or press [EXIT] to return to the previous menu

6.2. Spectrum

The ASM02 can display live spectrum from 950MHz to 2150MHz covering legacy

satellite analysis and limited wideband frequencies.

Tap this icon or press [EXIT] to return to the previous menu

• Tap the spectrum chart to see more detail including the centre of the frequency

and power level

• To return to the previous menu, press [EXIT]

• Tap [RANGE] segment to set the frequency scan range

• To set the LNB voltage output tap [13V/18V] segment

• Toggle 22kHz tone on and off by tapping the [22K ON/OFF] segment

• Start or stop the spectrum run process by tapping the [RUN/STOP] segment

• Tap and hold on the screen for ne setting of frequency

Functions in Spectrum Mode

LO band 22K on/off 13V/18V Mute Help

Hot Key Function in Spectrum Mode

6. DVB-S/S2 Mode
