FT-100 Fire Training

Fog Machine User Manual

!"#"$%&'()*+%,+-.(+'-%)'/%01123(4%,(/5%

English Français Deutsch • • • ㆗文

User Manual - English

Safety Information

Please read the following safety information carefully before operating the

machine. This information includes important safeguards about installation,

usage, and maintenance. Pay attention to all warning labels and instructions in

this manual and printed on the machine.

If you have questions about how to operate the machine safely, please contact your local

Antari dealer for help.

․ Keep this device dry.

․ Always connect to a grounded circuit to avoid risk of electrocution.

․ Before connecting machine to power, always check the voltage indicates on the

machine matches to your local AC voltage. Do not use the machine if the AC power

voltage does not match.

․ Disconnect the machine from the AC power before servicing and when not in use.

․ This product is for indoor use only! Do not expose to rain or moisture. If fluid is spilled,

disconnect the AC power and clean with a damp cloth. If fluid is spilled onto electronic

parts, immediately unplug the machine and contact your local Antari dealer for advice.

․ No user serviceable and modifiable parts inside. Never try to repair this product, an

unauthorized technician may cause damage or malfunction to the machine.

․ For adult use only. Never leave the machine running unattended.

․ Install the machine in a well-ventilated area. Provide at least 50 cm of space around

the machine.

․ Never add flammable liquid of any kind to the machine.

․ Make sure there are no flammable materials close to the machine while operating.

․ Only use Antari fluid. Other fluid may lead to heater clog or malfunction.

․ If the machine fails to work, unplug the machine and stop operation immediately.

Contact your local Antari dealer for advice.

․ Before transporting the machine, make sure the fluid tank is completely drained.

․ Fog fluid may present health risks if swallowed. Do not drink fog fluid. Store it securely.

In case of eye contact or if fluid is swallowed, immediately look for medical advice.

Unpacking and Inspection

Immediately upon receiving the machine, carefully unpack the carton, check the content to

ensure that all parts are present and have been received in good condition. If any parts

appear damaged or mishandled from shipping, notify the shipper immediately and retain the

packing material for inspection.

What is included: 1 x FT-100 Fog Machine

1 x W-2 Wireless Remote

1 x Power Cord

1 x User Manual

Product Dimensions

580 mm

264.5 mm

278.2 mm

Product Overview

Setting Up

Step 1: Place the machine on a flat surface and in a suitably large area with at least 50 cm

of open space around the machine.

Step 2: Fill the fluid tank with Antari approved fluid.

Step 3: Connect the machine to a suitably rated power supply. To determine the power

requirement for the machine refer to the label on the back of the machine.

Always connect the machine to a protected circuit and ensure it is properly

grounded to avoid risk of electrocution.

Step 4: Turn on the machine and allow it to heat up. Heat up takes approximately 10

mintues. Once the machine has reached operating temperature, the LCD display will show

“Ready To Fog”. Now the machine is ready for operation.

Step 5: To start making fog, locate the rotary knob on the right side of control panel, and

press the rotary knob to start making fog.

Step 6: To turn off the machine, press rotary knob again button and turn Powercon to the

OFF position.

XLR 5-Pin DMX Connector

Remote Control (Z-3 Remote)

Wireless Receiver

(W-2 Wireless Remote)

Two rotary knobs

Timer / Volume

Operation

Control Panel Operation

The machine can be operated with the onboard digital control interface.

Operation - Timer Mode

Rotary knob

Action

Description

Left

Press once

Activate timer mode

Right

Press second time

Deactivate timer mode

Right

Rotate

Adjust output volume

Operation – Volume Mode

Rotary knob

Action

Description

Right

Press once

Activate volume mode

Right

Press second time

Deactivate volume mode

Right

Rotate

Adjust output volume

Setting

Rotary knob

Action

Description

Left

Press and hold for 3

seconds

Enter setting menu

Left

Rotate

Scroll through menus

Left

Press

Press once to enter

Left

Rotate

Adjust for preferred value

Right

Press

Escape from menu

Control Menu

Set interval time from 5 to 200 seconds

Set duration time from 1 to 200 seconds

Set output volume from 1 to 100%

Set DMX address from 1 to 512

Turn ON or OFF wireless remote feature

Turn ON or OFF fluid sensor

Turn ON or OFF wireless DMX module

Turn ON or OFF memory setting. When turned “ON”, the

machine will return to its original state before last shut off.

Turn ON or OFF rotary knob sound

Interval Set

XXX S

Duration Set

XXX S

Timer Output

XXX %

Volume Output

XXX %

DMX512

Address:XXX

Wireless

Fluid Sensor Set

W-DMX Power

OFF

Run Last Setting

OFF

Keypad Sound

Pair or unpair wireless remote

Turn ON or OFF nonstop burst function. Once the machine is

turned on, it can paoduce output continously without reheating.

Wireless Operation

Wireless remote control system W-2 consists of a transmitter equipped with four buttons to

activate, deactivate, increase and decrease fog output and an onboard receiver attached to the

rear panel of FT-100 fog machine.

W-2 Wireless Transmitter

Press [A] button to emit fog. Press [B] button to stop. Press [C] button to increase output

volume. Press [D] button to decrease output volume.

In an unobstructed open space the effective distance is 50 meters, usage depending on

obstacle level the effective distance is 10-25 meters.

Wireless Receiver

Wireless Detect

Pair

Nonstop Burst

OFF

Registering a transmitter

Transmitters can be paired or deleted from the receiver. Each receiver can pair up to 5

transmitters. Follow the steps below to pair or delete a transmitter from a receiver.

Step 1: Press and hold the left rotary knob for 3 seconds to enter setting menu.

Step 2: Rotate the rotary knob to find the “Wireless Detect” menu.

Step 3: Follow the menu instruction to pair or delete a transmitter.

Transmitter battery replacement

If the effective distance seems to decrease, it is possible the battery level is low and

requires replacement. In order to replace the battery, undo the three screws on the back of

transmitter to release the cover. Replace with the same type and specification of battery

which is 27A 12V

DMX Connector Pin Assignment

The machine provides a 5-pin XLR connector for DMX connection. The diagram below

indicates pin assignment information.

Function

Ground

Data-

Data+

N/A

DMX Channel Function

Channel 1

DMX Value Range

Function

Fog

0 – 4

5 – 255

Fog Off

Output 1-100%

Fluid

Only use Antari FLP water-based liquid for the FT-100 Fire

Training Fog Machine. The machine is tested and calibrated

with this liquid to get the best output performance. Warranty will

be voided if any other type of liquid is used, improper use of

liquid may lead to machine failure and malfunction.

Service and Maintenance

․ Do not allow the machine to become contaminated.

․ Remove dust from air vents with air compressor, vacuum or a soft brush.

․ Only use a damp cloth to clean the casing.

․ Before storing run distilled water through the system to help prevent condensing the

pump or heater.

․ It is recommended to run the machine on a monthly basis in order to achieve best

performance and output condition.

․ Excessive dust, liquid and dirt built up will degrade performance and cause

overheating.

Breaker Reset

Disconnect AC power before resetting the breaker. Only replace fuse with same

type and rating.

Step 1: Disconnect AC power.

Step 2: Flip breaker to ON position.
