AmScope PM240 Series Manuel utilisateur

PM240

Series

User’s Manual

PM240

Series

abl

Contents

Before Use..........................................................................................3

Introduction ............................................................................................................. 3

Safety Precautions ................................................................................................... 4

Parts .............................................................................................. 5

PM240T ........................................................................................................... 5

Definition of Parts ............................................................................................... 6

Getting Started ............................................................................ 8

Assembly ..................................................................................................................

Operation .................................................................................... 9

Setting Up ................................................................................................................... 9

Focusing ................................................................................................................... 9

Using the Trinocular Port ................................................................................. 10

Attaching a Camera ........................................................................................... 10

Adjusting Focusing Tension ........................................................................... 11

Maintenance/Precautions ..................................................................................... 11

Specifications.............................................................................. 12

PM240 Series Specifications ................................................................................ 12

Optional Accessories ............................................................................................. 13

Technical Terms & Concepts ..........................................................................14

Troubleshooting.......................................................................... 15

Common Issues (Optical) .................................................................................. 15

Common Issues (Mechanical) ........................................................................... 16

PM240

Series

Before

Use

Introduction

Congratulations on the purchase of your new AmScope microscope!

This manual is designed for the PM240 series microscopes.

The two base models of this series differ in that the -B models are binocular (two eyepiece ocular

tubes), while the -T models are trinocular (two eyepiece ocular tubes with a third port on top for

a microscope camera).

Please take a few minutes to familiarize yourself with the features and functions of your new mi-

croscope.

If you’d like more information on microscopes, parts, or accessories, please visit our website at:

www.iScopeCorp.com

We highly recommend you study this manual thoroughly before operating the microscope and

that you keep it on hand for future reference.

If you have additional questions or need assistance, please send us an email at:

info@amscope.com

PM240

Series

Before

Use

Safety Precautions

As the microscope is a precision instrument, always handle it with care, avoiding impact

or abrupt movement during transportation. Do not shake the package.

Do not place the microscope in direct sunlight or in high heat. Keep it indoors in a dry

and clean place with temperatures between 32-100 degrees F (0-40 degrees C), and in

maximum relative humidity of 85%.

Avoid touching the lenses on the objectives and the eyepieces so that oil and dirt from

your fingerprints do not obstruct your view.

Before turning the power on, make sure that the power supply voltage is consistent with

the voltage of your microscope (for units with built in illumination).

PM240

Series

Parts

PM240T

Trinocular Port (PM240T Only)

Eyepieces

Ocular Tubes

Interpupillary Adjusters

Pillar Stand

Magnification Knob

Objective

Focusing Rack

Focusing Knob

Top Light Source

StageClips

Base Illuminator

PM240

Series

Parts

Definition of Parts

AdjustableTrinocularPort

Threaded port with adjustable length of attachment of digital or video camera

Boom Stand

Stand for the microscope that allows the head to be moved in physical space in various directions

Continuous Zoom

A microscope head with a knob to change magnification through a range

Dimmer

Controls the amount of light that escapes from the illumination source

Diopter

Allows the focus to be perfected for both eyes, independent of each other

Fixed Power

Microscope head whose objectives are pre-set at certain levels and changed by rotating the objective

FocusingKnob

Used to move the microscope head vertically to bring the sample into focus

GooseneckIlluminator

Illuminator independent of the unit that allows movement of one or two necks for controlled lighting

Head Lock Screw

Screws the microscope head into place

PM240

Series

Parts

Magnification Knob

Changes the magnification of the lenses on a continuous zoom microscope

Microscope Head

Contains the objective lens, eyepiece ocular tubes, and prisms used to magnify

Ocular Tube

Tube designed to hold the eyepieces or camera in place

Ring Light

An illuminator that mounts directly onto the objective to emit even light on the sample below

Simul-FocalMicroscopeHead

Head containing a focus adjustment for a trinocular port camera to simultaneously to match the eyepieces

Table Stand

A stand which sits on the table and holds the head directly above the sample without moving

PM240

Series

Getting

Started

Assembly

First, take the styrofoam container out of the cardboard carton and lay it on its side, paying attention to which

side is labeled up. Remove the tape and open the container carefully so as to avoid dropping and damaging the

optical items. Check carefully to ensure that all parts and accessories are intact.

Check the packing list to ensure that you’re received all items. Please note that this can vary depending on

which model you’ve purchased, and is generally listed on www.amscope.com at the items’ details page for your

specific model.

Remove the microscope body from the box and remove the plastic protective covering. The body of the micro-

scope is composed of the base that comes with your unit, the focusing rack, and the head lock screw.

After mounting the focusing rack to the base (if not already attached in shipping), slide the objective of the

microscope into the hole and secure with included head lock screw.

For the PM240T models, screw the photo port onto the top of the microscope head (trinocular C-mount

port).

Remove the eyetube caps and drop the desired eyepieces into the eyepiece ocular tubes. Be sure to avoid

touching the lens to ensure no artifacts appear in your image.

Remove the cap from the objective lens.

Plug in the microscope and turn it on if a light source is included (or refer to your specific light source in-

structions for mounting/turning on if an external source). If no light emerges from the light source, adjust the

dimmer knob near the power switch.

If viewing an opaque sample, use a top light source, however while using a translucent sample, either light

source can be used.

PM240

Series

Operation

Setting Up

Once you have placed your sample on the table or base below the objective, center the sample as best as possible.

A slide is neither needed nor required for a stereo microscope, although they can be used if desired. If using a slide,

use the stage clips to hold it in place.

With both eyes open, look into the eyepieces. Adjust the interpupillary distance by holding the eyepiece tubes

and rotating the eyepiece tubes either towards or away from each other until only one circle of light is seen by both

eyes.

Adjust the magnification knob to the lowest setting (0.8) and move the microscope’s focusing knobs (on the

focusing rack) to adjust the height of the unit until at approximately 4 inches (101mm) away from the sample. If

not clear after adjusting, please be sure that you have not installed any additional Barlow lenses onto the objective.

Center the object in the field of view once you have achieved focus.

Focusing

A stereo microscope’s focus differs from a compound microscope. Magnification and focal distance (working

distance) are inversely related to each other. The more magnified one is, the lower the distance between the objec-

tive and the sample to achieve focus.

When first using the microscope, remove all Barlow lenses and set the magnification knob (on the microscope

head) to the minimum setting (0.8x).

Begin focusing the microscope by moving the knob until the head is about 4 inches (101mm) away from the

sample. This should bring the microscope in focus at 8x.

If you’d like to use greater magnification than the minimum setting, you will need to move the microscope head

closer to the sample as well as adjust the magnification knob to a higher setting. The more magnified, the closer

you need to be.

This unit is a common main objective (CMO) microscope, so the optical quality through the trinocular port

and eyepieces will be better, however the image will appear more flat than your typical Greenough design stereo

microscope. The trinocular port when using a camera will appear to have more focus than the Greenough variants

due to the single objective design (rather than the dual offset design of a Greenough).

PM240

Series

Operation

Using the Trinocular Port

The AmScope PM240T model is uniquely designed so that you can view the image through the eyepieces and the

trinocular port without removing the camera or using your eyepiece.

This feature allows the images through the microscope’s eyepieces, and those displayed on your computer screen

or television be viewed at the same time (although unless using 20x eyepieces to match your camera, the image

may differ in magnification). You do not need an adapter to attach your AmScope camera to the trinocular port,

however you may need one if you have a non-AmScope camera. Our photo port is a 23mm size.

If using a simul-focal microscope head (one with a focusing adjustment on the third port), then you can use the

middle portion to focus the camera. This allows the camera to be in focus even if the magnifications between the

eyepieces and the camera are different. The PM240T models do not come standard with a simul-focal feature.

Attaching a Camera

If your microscope has a C-mount, you can simply screw the camera onto the trinocular port.

If your camera has a 23mm mounting size, remove the C-mount cap (if present) from the top of the trinocular

port by loosening the screw. Then, drop the camera with reduction lens directly into the trinocular port. It should

slide in without issue.

To focus through the trinocular port (simul-focal models only), simply turn middle portion of the tube. Other-

wise, you will need to focus it individually using the microscope’s focusing mechanisms.
