Amprobe PY-1A Manuel utilisateur

Users Manual

• Mode d’emploi

• Bedienungshandbuch

• Manual d’Uso

• Manual de uso

PY-1A

AC / DC Voltage Tester

Limited Warranty and Limitation of Liability

Your Amprobe product will be free from defects in material and

workmanship for 1 year from the date of purchase. This warranty does

not cover fuses, disposable batteries or damage from accident, neglect,

misuse, alteration, contamination, or abnormal conditions of operation or

handling. Resellers are not authorized to extend any other warranty on

Amprobe’s behalf. To obtain service during the warranty period, return

the product with proof of purchase to an authorized Amprobe Test

Tools Service Center or to an Amprobe dealer or distributor. See Repair

Section for details. THIS WARRANTY IS YOUR ONLY REMEDY. ALL OTHER

WARRANTIES - WHETHER EXPRESS, IMPLIED OR STAUTORY - INCLUDING

IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OR

MERCHANTABILITY, ARE HEREBY DISCLAIMED. MANUFACTURER

SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE

OR THEORY. Since some states or countries do not allow the exclusion

or limitation of an implied warranty or of incidental or consequential

damages, this limitation of liability may not apply to you.

Repair

All test tools returned for warranty or non-warranty repair or for

calibration should be accompanied by the following: your name,

company’s name, address, telephone number, and proof of purchase.

Additionally, please include a brief description of the problem or the

service requested and include the test leads with the meter. Non-warranty

repair or replacement charges should be remitted in the form of a check,

a money order, credit card with expiration date, or a purchase order made

payable to Amprobe® Test Tools.

In-Warranty Repairs and Replacement – All Countries

Please read the warranty statement and check your battery before

requesting repair. During the warranty period any defective test

tool can be returned to your Amprobe® Test Tools distributor for an

exchange for the same or like product. Please check the “Where to

Buy” section on www.amprobe.com for a list of distributors near you.

Additionally, in the United States and Canada In-Warranty repair and

replacement units can also be sent to a Amprobe® Test Tools Service

Center (see next page for address).

Non-Warranty Repairs and Replacement – US and Canada

Non-warranty repairs in the United States and Canada should be sent

to a Amprobe® Test Tools Service Center. Call Amprobe® Test Tools or

inquire at your point of purchase for current repair and replacement

rates.

In USA In Canada

Amprobe Test Tools Amprobe Test Tools

Everett, WA 98203 Mississauga, ON L4Z 1X9

Tel: 888-993-5853 Tel: 905-890-7600

Fax: 425-446-6390 Fax: 905-890-6866

Non-Warranty Repairs and Replacement – Europe

European non-warranty units can be replaced by your Amprobe® Test

Tools distributor for a nominal charge. Please check the “Where to

Buy” section on www.amprobe.com for a list of distributors near you.

Amprobe®Test Tools Europe

In den Engematten 14

79286 Glottertal, Germany

tel: +49 (0) 7684 8009 - 0

*(Correspondence only – no repair or replacement available from this

address. European customers please contact your distributor.)

Test Probes

Neon for Voltage indication

Pocket Clip

PY-1A AC / DC Voltage Tester

CONTENTS

SYMBOLS............................................................................ 2

UNPACKING AND INSPECTION ......................................... 5

INTRODUCTION .................................................................. 5

OPERATION......................................................................... 5

SPECIFICATION ................................................................... 6

MAINTENANCE................................................................... 6

TROUBLE SHOOTING.......................................................... 7

SYMBOLS

Warning of a potential danger, comply with

instruction manual.

Caution! Dangerous Voltage. Danger of

electrical shock.

Continous double or reinforced insulation

complies with Category II IEC 536



Conﬁrmity symbol, the instrument complies

with the valid directives. It complies with the

EMC Directive (89/336/EEC), Standards EN

50081 and EN 50082-1 are fulﬁlled. It also

complies with the low Voltage Directive (73/23/

EEC), Standard EN 61010-1 is fulﬁlled.

Measurement category III is for measurements

performed in the building installation.

Instrument complies with the standard

(2002/96/EEC) WEEE



The instruction manual contains information

and references, nessary for safe operation and

maintenance of the instrument.

Warnings!

This Electrical Tester has been constructed and veriﬁed

in compliance with the lasted safety standards and have

left the factory in safe and perfect conditions. Prior to

using the instrument (commissioning/assembly) the user

is kindly requested to thoroughly read the instruction

manual and comply with it in all sections.

• Failure to read the instruction manual or to

comply with the warnings and references

contained herein can result in serious bodily injury

or instrument damage.

• The respective accident prevention regulations

established by the professional associations for

electrical system and equipment must be strictly

met at all times.

• In order to avoid electrical shock, the valid safety

regarding excessive contact voltages must receive

utmost attention, when working with voltages

exceeding 120V (60V) DC or 50V (25V) rms AC. The

values in bracket are valid for limited ranges (as

for example medicine and agriculture).

• Never connect the tester to voltage for longer

than 30 seconds. For next operation, a recovery

time of minimum 240 seconds is needed

• The instrument may only be used within the

operating ranges as speciﬁed in the technical data

section and in low voltage system up to 600V.

• Measurements in dangerous proximity of electrical

system are only to be carried out in compliance

with the instructions of a responsible electronics

technician, and never alone.

• The electrical testers may no longer be used if one

or several functions fail or if no functionality is

indicated.

• Do not use this instrument under damp conditions.

• Perfect display is only guaranteed within a

temperature range of 5°C up to +40°C at relative

humidity <80%.

• Test leads and test probes may only be touched

at handle surfaces provided. Absolutely avoid the

direct contact of the rest probes.

• Prior to usage ensure perfect instrument function

(e.g. on known voltage source).

• The instrument may only be opened by an

authorized service technician.

The safety can no longer be insured if the instrument:

• Shows obvious damage.

• Does not carry out the desired measurements.

• Has been stored for too long under unfavorable

conditions

• Has been subjected to mechanical stress during

transport.

• Avoid any heating up of the instrument by direct

sunlight to ensure perfect functioning and long

instrument life.

• The instrument may only be used under those

conditions and for those purposes for which it

was conceived. For this reason, in particular the

safety references, the technical data including

environmental conditions and the usage in dry

environments must be followed. When modifying

or changing the instrument, the operational safety

is no longer ensured.

• The instrument may only be used under those

conditions and for which it was conceived. For

this reason, in particular the safety references,

the technical data including the environmental

conditions and the usage in dry environments

must be followed.

UNPACKING AND INSPECTION

Your shipping carton should include:

1 Electrical Tester PY-1A

1 Instruction Manual

If any of the items are damaged or missing, return

the complete package to the place of purchase for an

exchange.

INTRODUCTION

This Electrical Tester is for universal applications for

indoor use only. It represents a valuable support for all

testing in handicraft and industrial applications.

The electrical tester is characterized by the following

features.

• AC voltage detection up to 480V, and DC voltage

upto 600V.

• Bright neon AC/DC voltage display.

• Ergonomically and robust housing.

• Snap-in leads are spaced to t to the standard US/

Canada outlet, for easy, one hand operation.

• Integral probe storage for easy carrying.

OPERATION

• Test the electrical tester on a known source.

• Connect both test leads with UUT.

• The voltage is displayed via Neon lamps.

• The instrument with 120, 240, 277, 480V AC range

and 160, 330, 380, 600V DC range.

SPECIFICATION

Voltage Range 120, 240, 277, 480V AC

160, 330, 380, 600V DC

Response Time <0,3s

Frequency Range DC, 0~65Hz

Interal Load approx. 2.0 W/ 600V

Test Current <3.5 mA

Operation Time (DT) 30s

Recovery Time 240s

Temperature Range 5°C ~ +40°C (41°F ~ 104°F)

Humidity Max. 80% rel. H.

Height above sea level up to 2000 m (6562 ft)

Measurement Cat. CATIII / 600V

Pollution Degree 2

Safety Standards IEC 61010, UL 61010, CSA

22.2 No. 61010

Weight Approx. 50g (0.11 lb)

Dimension Approx. 150X32X26 mm

(5.9x1.3x1.0 in)

MAINTENACE

When using the instrument in compliance with the

instruction manual, no special maintenance is required.

Should operational problems occur during daily use, our

consulting service will be at your disposal, free of charge.

If functional errors occur after expiration of warranty,

the repairing of the tester should be performed only by

a Factory Authorized Service Center or by other qualiﬁed

instrument service personnel. The front panel and

case can be cleaned with a mild solution of detergent

and water. Apply sparingly with a soft cloth and allow

to dry completely before using. Do not use aromatic

hydrocarbons or chlorinated solvents for cleaning.

Do not attempt to repair this tester. It contains no user-

serviceable parts. Repair or servicing should only be

performed by qualiﬁed personnel.

TROUBLE SHOOTING

If the instrument fails to operate, check test leads, and

replace as necessary. Double check operating procedure

as described in this user’s manual.

Table des matières

Autres manuels Amprobe Équipement de test

Amprobe

Amprobe BAT-500 Manuel utilisateur

Amprobe

Amprobe AM-42 Manuel utilisateur

Amprobe

Amprobe LAN-1 Manuel utilisateur

Amprobe

Amprobe ROBIN KMP7010 Manuel utilisateur

Amprobe

Amprobe UAT-600-EUR Series Manuel utilisateur

Amprobe

Amprobe LT-10-EUR Manuel utilisateur

Amprobe

Amprobe ACD-14 FX Manuel utilisateur

Amprobe

Amprobe CT238A Manuel utilisateur

Amprobe

Amprobe INSP-3 Manuel utilisateur

Amprobe

Amprobe Telaris Series Manuel utilisateur

Amprobe

Amprobe BT-120 Manuel utilisateur

Amprobe

Amprobe A-5000 Manuel utilisateur

Amprobe

Amprobe AMB-50 Manuel utilisateur

Amprobe

Amprobe BAT-200 Manuel utilisateur

Amprobe

Amprobe gp-2a Manuel utilisateur

Amprobe

Amprobe AMB-45 Manuel utilisateur

Amprobe

Amprobe VP-700-E Manuel utilisateur

Amprobe

Amprobe PRM-6 Manuel utilisateur

Amprobe

Amprobe PRM-2 Manuel utilisateur

Amprobe

Amprobe SM-CAL1 Manuel utilisateur

Amprobe

Amprobe BT-120 Manuel utilisateur

Amprobe

Amprobe AMB-25 Manuel utilisateur

Amprobe

Amprobe VPC-30 Manuel utilisateur

Amprobe

Amprobe GROUND PROBE GP-1 Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
