OWNERS MANUAL
Model S1600/S1610
VHF Wireless Microphone
3149 MacArthur Blvd.
Northbrook. IL 60062
1 -800-AmpliVox
The AmpliVox S1600 wireless microphone system is compact,
lightweight and compatible with all AmpliVox and Perma Power
Sound Systems currently being produced or that were produced
since 1961. The S1600 operates in an authorized VHF band and
has a useful range of up to 200’ in line-of sight applications.
Each S1600 system operates on two crystal-controlled, switch-
selectable frequencies for clear clean transmission.
“A” Channel “B” Channel
T6: 171.105 MHz T7: 171.845 MHz
The frequency appears on the back of each unit. Both transmitter
and receiver must have the same, and both units must be set to
either “A” or “B.”
Note that two transmitters on the same frequency will not work
with one receiver. However two or more receivers will work with
the same transmitter
The S1600 is offered with a choice of two microphones: The
S2030 miniature cardioid condenser lapel microphone or the
S2040 headset microphone.
Before use, make certain you understand the function and
operation of the system.
RF INTERFERENCE
Please note that wireless frequencies are shared with other radio
services. According to the Federal Communications Commission
regulations, “Wireless microphone operations are unprotected
from interference from other licensed operations in the band. If any
interference is received by any Government or non-Government
operation, the wireless microphone must cease operation…”
If you need assistance with operation of frequency selection,
please contact your dealer or AmpliVox.
Additionally There are models available for use in Canada.
Receiver
Flexible Antenna
Power ON Indicator
Phone Out Jack—connect this jack to amp
Mike Out Jack
Power ON/OFF Switch
Channel Selector Switch
9V DC Power input Jack
Transmitter
Mike Input Jack
Power ON Indicator
Power ON/OFF Switch
Channel Selector Switch
S2030 Lapel Mic
FEATURES & CONTROLS
POWER SOURCE
The transmitter and receiver are each operated by a 9V alkaline
battery. Before use, install a battery as shown. Make certain the
battery is fully seated in its compartment so the cover slides in place
easily. Battery life with alkaline batteries is approximately 8 hours of
operating time. The receiver also features an external jack for
connecting a 9V DC power supply (not included).
TRANSMITTER OPERATION
B) If there is a “dead spot” in a room, try a slight change of position or
try changing frequencies.
Each unit provides two selectable transmitting frequencies.
1) Switch the Frequency Selector Switch to the desired channel (A or
B).
2) Belt clip on the back of the unit clips the transmitter onto a belt or
the transmitter simply can be put into a pocket.
3) Plug the microphone into the Mike Input Jack.
4) The microphone can be clipped to a necktie or other clothing,
using the supplied clip.
5) Slide the power ON/OFF switch to the ON position (the LED
indicator light will light).
Ribbon for battery removal
9V DC battery
Battery compartment cover
OPERATION
RECEIVER OPERATION
Each unit provides two selectable receiving frequencies.
1) Switch the Frequency Selector Switch to the same channel as the
one selected on the transmitter (A or B)
2) Attach the receiver to the amplifier by inserting the mounting
bracket foot into the amplifiers accessory shoe (if available) or with
the supplied Velcro.
3) Connect the mini-plug audio signal cable from the phone out jack
on the receiver to the wireless mic jack on amplifier
4) Attach Antenna by screwing it into socket on top of receiver.
5) Turn the Power ON/OFF switch to the ON position (The LED
indicator will light)
HELPFUL HINTS
A) If the selected channel is noisy, switch both the transmitter and
receiver to the other channel.
C) Low ceiling fluorescent lighting, overhead telephone lines, or close
proximity to metal fences can all cause static. If this occurs, try a
slight change of position and/or try changing frequencies.
D) When the battery voltage drops below 6V, the LED indicator will
go out. This means you need a new battery.
E) Be sure to turn off the power whenever the units are not in use,
and remove the batteries if the units will be out of service for a
long time.
NOTE: There are no user-adjustable parts inside the transmitter or
receiver Do not attempt to open or make any adjustments.
Phone Out Jack
Wireless Mic Jack
BELT CLIP
A detachable belt clip is included for convenience. Slide the tapered
end of the belt clip into the grooved area located on the back of the unit
until it clicks into place.
MOUNTING
The receiver can be mounted to some AmpliVox units by means of the
supplied mounting bracket or velcro self-adhesive patch.
a product of
1-800-AmpliVox
(800-267-5486)
FAX 847-498-6691
3149 MacArthur Blvd.
Northbrook. IL 60062
1 -800-AmpliVox
