THANK YOU FOR CHOOSING
AMMONITE SYSTEM
We are hopeful that your experience with Ammonite System
products will be smooth and flawless. To ensure that please
read this manual and follow the rules within.
For any questions please check our website
www.ammonitesystem.com, contact us by e-mail or our
fanpage on Facebook.
The symbol placed on the product or its package indica-
tes that this product cannot be treated as
household waste. It should be handed over to
the applicable collection point for the used up
electrical and electronic equipment by providing
proper storage you may prevent dangerous
consequences to the environment and human health.
Recycling helps to preserve natural resources. For
more information about recycling of this product,
please contact your local authorities or authorities
responsible for environment protection, your
household waste disposal service or the shop
where the product was purchased.
At the end of the use, the battery should be placed in a special
container or brought to a collection point for the recycling of
electrical and electronic equipment.
In order to do this please read current environmental
protection regulations.
NOTE
Despite the regulations in force concerning air shipping of
hazardous goods including Li-Ion batteries, the shipping company
may refuse to ship a Li-Ion battery onboard a plane.
Ammonite System will notbeheld responsible for such occurrences.
INTENDED USE
ACCU THERMO batteries are intended to be used to supply
power to a diver’s heated dive wear and umbilical dive lights
operating at a maximum of 12 V, with the receivers (heated
undersuit, vest, gloves, and lights) of the maximum total
power of not more than 200 W (for ACCU THERMO 14, ACCU
THERMO 24 and ACCU THERMO 24 Special).
ACCU THERMO batteries feature two connection terminals at
the top part of the casing, one of which has a built-in cable with
the so-called E/O connector (wet connector).
It is used to connect the heating device, it is equipped with
an „intelligent E/O” system and features a two-level power
regulation (70%/100%) switch to control heating levels.
The E/O connector is intended to be a power
supply only for the heated dive wear.
The second terminal is used to charge the battery; it may be
also used to connect and power any Ammonite System umbilical
dive light.
WHAT IS „INTELLIGENT E/O”
“Intelligent E/O” is an electronic circuit protecting the
contacts of a wet connector (E/O cord), from damage caused
by electrolysis. The process responsible for this kind of damage
takes place during the passage of current in water between
the contacts of a wet connector when it remains unconnected.
Until the ACCU THERMO is not connected to a receiver, e.g. a
heated vest, there is no voltageon the wet connector (E/O cord).
Voltage is automatically cut off also upon disconnecting the
receiver by unplugging the E/O cord.
Thus, no current passes between the contacts of the wet
connector, making them safe from damage.
