Amica OMP6568BG STUDIO Manuel utilisateur

IO-HOO-0918/3

(09.2022)

Kitchen extractor hood / okap nadkuchenny /

kuchyňského odsavače / kuchynského odsávača

OMP6568BG STUDIO

OMP9568BG STUDIO

OPERATING INSTRUCTIONS EN

INSTRUKCJA OBSŁUGI PL

NÁVOD K OBSLUZE CS

NÁVOD NA OBSLUHU SK

- 3 -

NOTES ON SAFETY 6

UNPACKING 9

DISPOSAL OF OLD APPLIANCE 9

OPERATION 10

COOKER HOOD CONTROLS 10

OFF-TIMER 11

GESTURE CONTROL 11

OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 13

CLEANING AND MAINTENANCE 14

MAINTENANCE 14

GREASE FILTER 14

ACTIVATED CHARCOAL FILTER 14

LIGHT 14

WARRANTY AND AFTER SALES SERVICE 15

WARRANTY 15

EN- Table of contents

CS- Obsah

PL- Spis treści

WSKAZÓWKI DOTYCZĄCE BEZPIECZEŃSTWA 17

ROZPAKOWANIE 21

USUWANIE ZUŻYTYCH URZĄ DZEŃ 21

OBSŁUGA 22

STEROWANIE OKAPEM 22

TIMER (OPÓŹNIONE WYŁĄCZENIE OKAPU) 23

STEROWANIE GESTAMI 23

INNE WAŻNE INFORMACJE DOTYCZĄCE OBSŁUGI OKAPU 25

CZYSZCZENIE I KONSERWACJA 26

KONSERWACJA 26

FILTR PRZECIWTŁUSZCZOWY 26

FILTR WĘGLOWY 26

OŚWIETLENIE 26

GWARANCJA, OBSŁUGA POSPRZEDAŻOWA 27

GWARANCJA 27

BEZPEČNOSTNÍ POKYNY 29

VYBALENÍ 32

LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 32

OBSLUHA 33

OVLÁDÁNÍ ODSAVAČE 33

ČASOVAČ (ODLOŽENÉ VYPNUTÍ DIGESTOŘE) 34

OVLÁDÁNÍ GESTY 34

JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 36

ČIŠTĚNÍ A ÚDRŽBA 37

ÚDRŽBA 37

PROTITUKOVÝ FILTR 37

UHLÍKOVÝ FILTR 37

OSVĚTLENÍ 37

ZÁRUKA, POPRODEJNÍ SERVIS 38

ZÁRUKA 38

- 4 -

SK- Obsah

BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 40

ROZBALENIE 44

LIKVIDÁCIA ZARIADENÍ 44

POUŽÍVANIE 45

OVLÁDANIE ODSÁVAČA 45

ČASOVAČ (ONESKORENÉ VYPNUTIE ODSÁVANIA) 46

OVLÁDANIE GESTAMI 46

INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 48

ČISTENIE A ÚDRŽBA 49

KONZERVÁCIA 49

PROTITUKOVÝ FILTER 49

UHLÍKOVÝ FILTER 49

OSVETLENIE 49

ZÁRUKA, POPREDAJNÝ SERVIS 50

ZÁRUKA 50

- 5 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 6 -

NOTES ON SAFETY

• Before using the appliance, please carefully read

this manual!

• The appliance is designed for household use only.

• The manufacturer reserves the right to introduce

changes, which do not aect operation of the ap-

pliance.

• The manufacturer shall not be liable for any dam-

age or re caused by the appliance resulting from

failure to follow instructions in this manual.

• Cooker hood is designed to remove cooking

odours. Do not use cooker hood for other pur-

poses.

• Connect the cooker hood operating in extraction

mode to a suitable ventilation duct (do NOT con-

nect the cooker to smoke or ue gas ducts, which

are in use). It requires installation of the air ex-

traction duct to the outside. The length of the

duct (usually a pipe of Ø 120 or 150 mm) should

not be longer than 4-5 m. An air extraction duct

is also required for telescopic and furniture hoods

in absorption mode.

• Cooker hood operating in air recirculation mode

requires the installation of an activated charcoal

lter. In this case, installing an extractor duct is

not required, however it is recommended to in-

stall an air guide vane (Mainly in chimney cooker

hoods).

• The cooker hood features independent lighting

and exhaust fan that can be operated at one of

several speeds.

• Depending on the type, the hood is designed to

be permanently attached to a vertical wall over

a gas or electric stove (chimney and universal

hoods); on the ceiling over a gas or electric stove

(island hoods); on the vertical built in furniture

over a gas or electric stove (telescopic and built-

in hoods). Before installing, make sure that the

wall/ceiling structure is strong enough to suspend

the hood. Some hoods are very heavy.

- 7 -

• For details of the installation distance above an

electric hob please refer to product technical

sheet If the installation instructions of the gas

cooker specify a greater distance, this must be

taken into account (Fig. 1).

• Do not leave an open ame under the hood.

When the pots are removed from the burner, set

the minimum ame. Always make sure that the

ame does not extend outside the pot, because it

causes unwanted loss of energy and a dangerous

concentration of heat.

• When cooking on fat, supervise the pans con-

stantly, because overheated fat can ignite.

• Unplug the appliance before any cleaning, replac-

ing the lter or repair work.

• Cooker hood grease lter should be cleaned at

least once a month, because the lter saturated

with fat is ammable.

• Ensure adequate ventilation (air ow) if other

equipment such as liquid fuel stoves or heaters

are operated in the room in addition the cooker

hood. When the cooker hood is simultaneously

operated with burning appliances requiring ade-

quate fresh air from the room to work properly,

their safe operation is possible if under pressure

around these appliances is a maximum of 0.004

mbar (this does not apply when the cooker hood

is used as an odour lter)

• Do not lean on the hood.

• The hood should be cleaned regularly both inside

and out (AT LEAST ONCE A MONTH, following the

indications concerning maintenance provided in

this manual)..Failure to adhere to the rules con-

cerning cleaning the hood and replacing lters

results in a re risk.

• If the power cord is damaged it should be re-

placed by a specialised service centre.

• Ensure that it is possible to disconnect the ap-

pliance from the mains by removing the plug or

switching o the bi-polar switch.

• This appliance is not intended for use by persons

(including children) with physical, mental or sen-

sory handicaps, or by persons inexperienced or

- 8 -

unfamiliar with the appliance, unless under su-

pervision or in accordance with the instructions

as communicated to them by persons responsible

for their safety.

• Particular attention should be paid not to allow

unaccompanied children to use the appliance.

• Make sure voltage indicated on the nameplate

corresponds to the local mains supply voltage.

• Before use, extend and straighten the power cord.

• Packaging materials (bags, polyethylene, poly-

styrene, etc.) should be kept away from children

during unpacking.

• Before connecting the hood to the mains power

supply always check that the power cord is prop-

erly installed and is not trapped by the appliance.

Do not connect the appliance to the mains until

assembly is complete.

• Do not operate your kitchen hood without the al-

uminium grease lters.

• It is strictly forbidden to cook dishes under on an

open ame (ambé) under your kitchen hood.

• Always strictly adhere to regulations issued by the

competent local authorities regarding the techni-

cal and safety requirements for fume extraction.

• Failing to tighten bolts and fasteners in accord-

ance with these instructions may endanger life

and health.

• Hanging kitchen hoods operate only in air circu-

lation / odour absorber mode

• WARNING! Failure to install the screws or xing

device in accordance with these instructions may

result in electrical hazards.

• This appliance can be used by children aged 8 years

and older or by persons with physical, mental or sen-

sory handicaps, or by those who are inexperienced

or unfamiliar with the appliance, provided they are

supervised or have been instructed how to safely use

the appliance and are familiar with risks associated

with the use of the appliance. Ensure that children

do not play with the appliance. Cleaning and main-

tenance of the appliance should not be performed by

children unless they are 8 years or older and are su-

pervised by a competent person.

- 9 -

UNPACKING

During transportation, protective

packaging was used to protect the

appliance against any damage. Af-

ter unpacking, please dispose of all

elements of packaging in a way that

will not cause damage to the environ-

ment.

All materials used for packaging the

appliance are environmentally friendly; they are

100% recyclable and are marked with the appropri-

ate symbol.

Important! Packaging materials (bags, polyethyl-

ene, polystyrene, etc.) should be kept away from

children during unpacking.

DISPOSAL OF OLD APPLIANCE

In accordance with European Directive

2012/19/EU and local legislation re-

garding used electrical and electronic

goods, this appliance is marked with

the symbol of the crossed-out waste

container. This marking indicates that

the appliance must not be disposed of

together with other household waste

after it has been used.

The user is obliged to hand it over to waste collec-

tion centre collecting used electrical and electron-

ic goods. The collectors, including local collection

points, shops and local authority departments pro-

vide recycling schemes.

Proper handling of used electrical and electronic

goods helps avoid environmental and health haz-

ards resulting from the presence of dangerous com-

ponents and the inappropriate storage and process-

ing of such goods.

- 10 -

OPERATION

Cooker hood controls

Control Panel is shown in Figure 4, for reference it is also shown below:

34 5

81b

7 6

21a

The appliance is tted with gesture control sensors (1a, 1b, 2) and a

display (8).

The control panel features touch controls: Control functions are de-

scribed below:

3- O-Timer sensor

4- Reduce fan speed sensor

5- Increase fan speed sensor

6- Gesture control on/o sensor

7- Light control sensor

After connecting the appliance to the power supply, all indicators will

light up for a brief moment and the display will also show . Then all

indicators and the display will go out, only the gesture control sen-

sor is illuminated on the control panel. The hood will enter standby

mode, which is indicated by a dot on the display.

When activated, touch to start the fan.

Available fan speeds:

• Low speed (1). Use this speed when cooking a little food with hardly

any fumes.

• Medium speeds (2 - 3). Use this speed when cooking multiple dish-

es at the same time with moderate amount of fumes.

• Turbo ( ) — use this speed when frying or grilling with large

amount of fumes.

Use the and sensors to increase or reduce fan speed.

Note! Turbo mode is only active for 5 minutes, then fan speed is re-

duced automatically to one level down.

To turn o the fan, touch repeatedly until fan speed is reduced to

zero .

Touch to turn on / o the lighting.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Amica hotte de ventilation

Amica

Amica OKS6249SB Manuel utilisateur

Amica

Amica BK313.3 Manuel utilisateur

Amica

Amica OKM6244S Manuel utilisateur

Amica

Amica OSC6110W Manuel utilisateur

Amica

Amica OSC6110.1W Manuel utilisateur

Amica

Amica KH 17119 E Manuel utilisateur

Amica

Amica ST Series Manuel utilisateur

Amica

Amica OTC612B Manuel utilisateur

Amica

Amica UH Series Manuel utilisateur

Amica

Amica OTP9651BG Manuel utilisateur

Amica

Amica OSC6212B Manuel utilisateur

Amica

Amica KH 17285-3 E Manuel utilisateur

Amica

Amica AH3016 Manuel utilisateur

Amica

Amica OMC9751B Manuel utilisateur

Amica

Amica OKC954T Manuel utilisateur

Amica

Amica KH 17583 E Manuel utilisateur

Amica

Amica OTS 645 I Manuel utilisateur

Amica

Amica IH 17025 E Manuel utilisateur

Amica

Amica OKP9321GUK Series Manuel utilisateur

Amica

Amica OTS 645 IOTS 625 IOTS 625 WOTS 615 IOTS 615 WOTS 515 IOTS 515 WOTS 635 IOTS 935 IFH 17231 EOTS 6425 IOTS 6521... Manuel utilisateur

Amica

Amica TU 382 AB Manuel utilisateur

Amica

Amica OME6135I Manuel utilisateur

Amica

Amica OMP6211B Manuel utilisateur

Amica

Amica OSC5232I Manuel utilisateur

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Miele

Miele DA 1255 Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Miele

Miele DA 6708 D Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur
