Amica FH 664 620 E Manuel utilisateur

IO-HOO-0791/1

(10.2019)

Kitchen extractor hood / kaminhaube /

kuchyňského odsavače / kuchynského odsávača

/ Hotte aspirante / Afzuigkap / Kuhinjska napa /

Kuhinjska napa

FH 664 620 E / FH 664 620 S /

FH 694 620 E / FH 694 620 S

OPERATING INSTRUCTIONS EN

GEBRAUCHSANWEISUNG DE

NÁVOD K OBSLUZE CS

NÁVOD NA OBSLUHU SK

NOTICE D’UTILISATION FR

GEBRUIKSAANWIJZING NL

UPUTE ZA UPORABU HR

NAVODILA ZA UPORABO SL

- 3 -

NOTES ON SAFETY 7

UNPACKING 10

DISPOSAL OF OLD APPLIANCE 10

OPERATION 11

OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 14

CLEANING AND MAINTENANCE 15

MAINTENANCE 15

GREASE FILTER 15

ACTIVATED CHARCOAL FILTER 15

LIGHT 15

WARRANTY AND AFTER SALES SERVICE 16

WARRANTY 16

SICHERHEITSHINWEISE 18

AUSPACKEN 22

ENTSORGUNG VON ALTGERÄTEN 22

BEDIENUNG 23

ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 26

REINIGUNG UND WARTUNG 26

WARTUNG 26

FETTFILTER 27

AKTIVKOHLEFILTER 27

BELEUCHTUNG 27

GARANTIE, NACHVERKAUF-SERVICE 28

GARANTIE 28

EN- Table of contents

DE- Inhaltsverzeichnis

BEZPEČNOSTNÍ POKYNY 30

VYBALENÍ 33

LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 33

OBSLUHA 34

JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 37

ČIŠTĚNÍ A ÚDRŽBA 38

ÚDRŽBA 38

PROTITUKOVÝ FILTR 38

UHLÍKOVÝ FILTR 38

OSVĚTLENÍ 38

ZÁRUKA, POPRODEJNÍ SERVIS 39

ZÁRUKA 39

CS- Obsah

- 4 -

BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 41

ROZBALENIE 45

LIKVIDÁCIA ZARIADENÍ 45

POBSLUHA 46

INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 49

ČISTENIE A ÚDRŽBA 50

KONZERVÁCIA 50

PROTITUKOVÝ FILTER 50

UHLÍKOVÝ FILTER 50

OSVETLENIE 50

ZÁRUKA, POPREDAJNÝ SERVIS 51

ZÁRUKA 51

INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 53

DÉBALLAGE 57

ÉLIMINATION DES APPAREILS USAGÉS 57

EXPLOITATION 58

AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 61

NETTOYAGE ET ENTRETIEN 62

ENTRETIEN 62

FILTRE À GRAISSE 62

FILTRE À CHARBON 62

ÉCLAIRAGE 62

GARANTIE, SERVICE APRÈS-VENTE 63

GARANTIE 63

AANWIJZINGEN VOOR VEILIG GEBRUIK 65

UITPAKKEN 69

VERWIJDERING VAN GEBRUIKTE APPARATUUR 69

BEDIENING 70

BEDIENING VAN DE AFZUIGKAP 72

ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 73

REINIGING EN ONDERHOUD 74

ONDERHOUD 74

ANTIVETFILTER 74

ACTIEVE KOOLFILTER 74

VERLICHTING 74

GARANTIE, SERVICE 75

GARANTIE 75

SK- Obsah

FR- Table des matières

NL- Inhoudsopgave

- 5 -

HR- Kazalo

SL- Sadržaj

SIGURNOSNE NAPOMENE 77

UKLANJANJE PAKIRANJA 80

ZBRINJAVANJE POTROŠENIH UREĐAJA 80

UPORABA 81

OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 84

ČIŠĆENJE I ODRŽAVANJE 85

ODRŽAVANJE 85

FILTER PROTIV MASNOĆE 85

UGLJENI FILTER 85

RASVJETA 85

JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 86

JAMSTVO 86

NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 88

RAZPAKIRANJE 91

ODSTRANJEVANJE IZRABLJENIH NAPRAV 91

UPORABA 92

DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 95

ČIŠČENJE IN VZDRŽEVANJE 96

VZDRŽEVANJE 96

MAŠČOBNI FILTER 96

OGLENI FILTER 96

OSVETLITEV 96

GARANCIJA, POPRODAJNE STORITVE 97

GARANCIJA 97

- 6 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 7 -

NOTES ON SAFETY

• Before using the appliance, please carefully read

this manual!

• The appliance is designed for household use only.

• The manufacturer reserves the right to introduce

changes, which do not aect operation of the ap-

pliance.

• The manufacturer shall not be liable for any dam-

age or re caused by the appliance resulting from

failure to follow instructions in this manual.

• Cooker hood is designed to remove cooking

odours. Do not use cooker hood for other pur-

poses.

• Connect the cooker hood operating in extraction

mode to a suitable ventilation duct (do NOT con-

nect the cooker to smoke or ue gas ducts, which

are in use). It requires installation of the air ex-

traction duct to the outside. The length of the

duct (usually a pipe of Ø 120 or 150 mm) should

not be longer than 4-5 m. An air extraction duct

is also required for telescopic and furniture hoods

in absorption mode.

• Cooker hood operating in air recirculation mode

requires the installation of an activated charcoal

lter. In this case, installing an extractor duct is

not required, however it is recommended to in-

stall an air guide vane (Mainly in chimney cooker

hoods).

• The cooker hood features independent lighting

and exhaust fan that can be operated at one of

several speeds.

• Depending on the type, the hood is designed to

be permanently attached to a vertical wall over

a gas or electric stove (chimney and universal

hoods); on the ceiling over a gas or electric stove

(island hoods); on the vertical built in furniture

over a gas or electric stove (telescopic and built-

in hoods). Before installing, make sure that the

- 8 -

wall/ceiling structure is strong enough to suspend

the hood. Some hoods are very heavy.

• For details of the installation distance above an

electric hob please refer to product technical

sheet If the installation instructions of the gas

cooker specify a greater distance, this must be

taken into account (Fig. 1).

• Do not leave an open ame under the hood.

When the pots are removed from the burner, set

the minimum ame. Always make sure that the

ame does not extend outside the pot, because it

causes unwanted loss of energy and a dangerous

concentration of heat.

• When cooking on fat, supervise the pans con-

stantly, because overheated fat can ignite.

• Unplug the appliance before any cleaning, replac-

ing the lter or repair work.

• Cooker hood grease lter should be cleaned at

least once a month, because the lter saturated

with fat is ammable.

• Ensure adequate ventilation (air ow) if other

equipment such as liquid fuel stoves or heaters

are operated in the room in addition the cooker

hood. When the cooker hood is simultaneously

operated with burning appliances requiring ade-

quate fresh air from the room to work properly,

their safe operation is possible if under pressure

around these appliances is a maximum of 0.004

mbar (this does not apply when the cooker hood

is used as an odour lter)

• Do not lean on the hood.

• The hood should be cleaned regularly both inside

and out (AT LEAST ONCE A MONTH, following the

indications concerning maintenance provided in

this manual)..Failure to adhere to the rules con-

cerning cleaning the hood and replacing lters

results in a re risk.

• If the power cord is damaged it should be re-

placed by a specialised service centre.

• Ensure that it is possible to disconnect the ap-

- 9 -

pliance from the mains by removing the plug or

switching o the bi-polar switch.

• This appliance is not intended for use by persons

(including children) with physical, mental or sen-

sory handicaps, or by persons inexperienced or

unfamiliar with the appliance, unless under su-

pervision or in accordance with the instructions

as communicated to them by persons responsible

for their safety.

• Particular attention should be paid not to allow

unaccompanied children to use the appliance.

• Make sure voltage indicated on the nameplate

corresponds to the local mains supply voltage.

• Before use, extend and straighten the power cord.

• Packaging materials (bags, polyethylene, poly-

styrene, etc.) should be kept away from children

during unpacking.

• Before connecting the hood to the mains power

supply always check that the power cord is prop-

erly installed and is not trapped by the appliance.

Do not connect the appliance to the mains until

assembly is complete.

• Do not operate your kitchen hood without the al-

uminium grease lters.

• It is strictly forbidden to cook dishes under on an

open ame (ambé) under your kitchen hood.

• Always strictly adhere to regulations issued by the

competent local authorities regarding the techni-

cal and safety requirements for fume extraction.

• Failing to tighten bolts and fasteners in accord-

ance with these instructions may endanger life

and health.

• Hanging kitchen hoods operate only in air circu-

lation / odour absorber mode

• WARNING! Failure to install the screws or xing

device in accordance with these instructions may

result in electrical hazards.

- 10 -

UNPACKING

During transportation, protective

packaging was used to protect the

appliance against any damage. Af-

ter unpacking, please dispose of all

elements of packaging in a way that

will not cause damage to the environ-

ment.

All materials used for packaging the

appliance are environmentally friendly; they are

100% recyclable and are marked with the appropri-

ate symbol.

Important! Packaging materials (bags, polyethyl-

ene, polystyrene, etc.) should be kept away from

children during unpacking.

DISPOSAL OF OLD APPLIANCE

In accordance with European Directive

2012/19/EU and local legislation re-

garding used electrical and electronic

goods, this appliance is marked with

the symbol of the crossed-out waste

container. This marking indicates that

the appliance must not be disposed of

together with other household waste

after it has been used.

The user is obliged to hand it over to waste collec-

tion centre collecting used electrical and electron-

ic goods. The collectors, including local collection

points, shops and local authority departments pro-

vide recycling schemes.

Proper handling of used electrical and electronic

goods helps avoid environmental and health haz-

ards resulting from the presence of dangerous com-

ponents and the inappropriate storage and process-

ing of such goods.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Amica hotte de ventilation

Amica

Amica SO 44 AB Manuel utilisateur

Amica

Amica OWC4241 Series Manuel utilisateur

Amica

Amica OKC613RW Manuel utilisateur

Amica

Amica OMP6211B Manuel utilisateur

Amica

Amica OSS 522 Manuel utilisateur

Amica

Amica OSC5232I Manuel utilisateur

Amica

Amica OTP6541BG Manuel utilisateur

Amica

Amica OKC 6462 I Manuel utilisateur

Amica

Amica OKC954S Manuel utilisateur

Amica

Amica OKC IN600BS Manuel utilisateur

Amica

Amica FH 664 300 S Manuel utilisateur

Amica

Amica KH 17425 S Manuel utilisateur

Amica

Amica KH 17390-2 S Manuel utilisateur

Amica

Amica OSC6559W Manuel utilisateur

Amica

Amica KH 17196 E Manuel utilisateur

Amica

Amica OWS 451 O Manuel utilisateur

Amica

Amica OKC6552S Manuel utilisateur

Amica

Amica OSC 6468 W Mode d'emploi

Amica

Amica OMP6253BG Manuel utilisateur

Amica

Amica OKC622S Manuel utilisateur

Amica

Amica OKS4341OZ Manuel utilisateur

Amica

Amica AEA60BL Manuel utilisateur

Amica

Amica OTC612B Manuel utilisateur

Amica

Amica IH 694 610 E Manuel utilisateur

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Miele

Miele DA 1255 Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Miele

Miele DA 6708 D Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur
