Ameriwood 1844335COM Manuel utilisateur

1844335COM

TV Stand

B341844335COM1

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Follow Ameriwood Home

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Assembly Difficulty Meter

Easy Tough

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

WARNING

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

Helpful Hints

ameriwoodhome.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

ESTIMATED ASSEMBLY TIME: 1 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Tube

You

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not actual size

Left Panel

31844335010

Right Panel

31844335020

Support

31844335060

Back

31844335070

Top

31844335030

Bottom

31844335040

TV Rail

31844335050

Kick

31844335100

Top Rail

31844335110

Vertical Molding

31844335080

Center Molding

31844335090

ameriwoodhome.com

Board Identification

Not actual size

ameriwoodhome.com

Part List

Actual Size

Not Actual Size

(x13)

#A22620

cam lock

(x13)

#A22610

cam bolt

(x2)

#A22910

connector bolt

(x2)

#A22920

connector

(x7)

#A53510

angle bracket

(x4)

#A53840

angle bracket

(small)

(x38)

#A12210

#8 x 7/16" pan head

(x2)

#A12930

#8 x 1-1/8" pan head

(x2)

#A23030

confirmat screw

(x6)

#A21660

wood dowel

(x4)

#A54270

connecting plate

12 3 4

#B64359

TV warning label

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x3)

#A22620

(x2)

#A22610

(x2)

#A53510

(x4)

#A12120

(x1)

#A21660

1210

Be sure the outside edge of the vertical molding

(H) overlaps the front edge of the left panel (A) so

no raw board is showing.

ameriwoodhome.com

STEP2

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x3)

#A22620

(x2)

#A22610

(x2)

#A53510

(x4)

#A12120

(x1)

#A21660

Be sure the outside edge of the vertical molding

(H) overlaps the front edge of the right panel (B)

so no raw board is showing.

1210

ameriwoodhome.com

STEP3

110

(x2)

#A22620

(x2)

#A22910

(x1)

#A21660

rear surface front surface

Proper orientation of CAM LOCK

Tip

Assembly

Quick

ameriwoodhome.com

STEP4

110

(x1)

#A22620

(x1)

#A21660

Proper orientation of CAM LOCK

Tip

Assembly

Quick
