AMERICH Nouveau FT Manuel utilisateur
Installation and User Guide
Nouveau FT/RT
Thank you for purchasing an Americh International bath. This bath is made
from two skins of acrylic.
Before you start
Please note that this product has been through our rigid quality control
procedures which include a thorough visual and physical inspection. Please
unwrap the bath and check it carefully to ensure it has not been damaged in
handling or transport which is beyond our control.
Claims regarding cracks and or face damaged must be reported
within 24hrs of receipt of the product. No such claims will be
recognised after installation as this is classed as acceptance of the
product
Please do not remove the old fixture before you unpack and inspect the new
unit. Upon receipt check for shortages immediately. Store the bath in a safe
place until you begin installation to avoid damage.
Any installation should be carried out by a qualified tradesman with
knowledge of statutory and plumbing requirements in your area.
Tools needed
•Spirit Level
•Set of screwdrivers, both flat
and cross heads
•Adjustable Pliers
•Sharp knife
•Silicone sealant
•Drop cloth
Getting Started
Freestanding Nouveau Bath
Certain baths have been designed so the outer skin goes all the way to the
floor, as shown in the picture below.
Some Americh International baths are made form double skin acrylic
technology. Both skins are bonded together as one;
there is no panel around
the bath
.
Due to the way the Nouveau Flat top bath is designed, the pop up waste is
factory fitted. The baths are water tested for any leaks wrapped and
despatched.
Installation Instructions
This bath has been designed for floor or wall mounted taps.
The floor which the bath sits on must be as level as possible due to the
bath sitting on it’s flat base.
As the skirted baths have no panel to remove for access to the waste, an
access hole in the base of the outer skin has been cut so connection can
be made from the waste. Picture (A) shows the access hole below
Access
hole in
outer skin
Fitted
waste in
bath
Picture (A)
The access hole can be enlarged if required, be careful not to cut into the
structural supports in the bath. The cut should not extend beyond the
base up the side walls.
Plumbing The Bath In
Again we recommend that the bath be fully installed by a
professional/qualified tradesman.
Because the waste is already fitted to your bath the next step is to
connect it to you outlet pipe and secure it to the floor.
A 1 ½”adaptor should be with the bath, this is shown below.
Screw the 1 ½” adaptor onto the end of the waste thread ensuring a
tight fit. Make sure the rubber seal is in the adaptor, shown below.
1 ½” Adaptor
screwed onto
waste underneath
the bath
Rubber
seal inside
adaptor
The position of the bath should have been finalised and the outlet pipe
work should be on place. Once the adaptor has been fitted, with the
use of a compression fitting, slide the bath pipe work down onto the
compression fitting.
Check for leaks before securing to the floor
Once you’re satisfied with the waste connection, with the plug in, run a
little water into the bath and check for leaks. Take the plug out and let
the water drain. Check again for leaks. Then fill the bath half way full,
empty and check for leaks again.
Securing the bath
It is very important that you secure your bath to the floor to stop it
moving from its final position. When the installation is complete, it is
recommended that you apply silicone sealant around the bottom of the
bath to secure it to the floor.
Should maintenance access be needed the silicone can be released by
cutting round it with a sharp knife
Care and maintenance of your bath
It is advisable always to run in some cold water before turning on the hot tap
The acrylic has been tested to relevant standards and once formed, acrylic
can only be cracked by suffering some form of impact, stress or chemical
reaction. The surface of the acrylic is very smooth and easy to clean. Americh
suggests the use of a non abrasive cleaner. The cleaning of your bath should
be on a regular basis.
Avoid cleaning products that contain acetone, ethyl alcohol, amyl or ethyl
acetate, these products can damage the finish of the bath.
Do not use cigarettes near the bath, they could damage the finish.
Safety
•This product is intended for indoor use only. Use the bathtub only for its
intended purpose as described in this manual and do not use attachments
or accessories which are not recommended by the manufacturer.
•Caution should always be exercised when entering or exiting the bathtubs.
•Pregnant women should be careful of the temperature of the water when
bathing
•To reduce the risk of injury, do not permit children or persons with a
disability to use this unit unless they are closely supervised at all times.
•Never drop or insert any object into the bath
•Do not attempt to use/plug electrical items while in or near a filled bath.
•Failure to comply with all instructions, requirements, and warnings
contained in this manual create a serious hazard to the bathtub user and
may result in serious injury.
