American Standard 3260.210.AXX Manuel utilisateur

32” x 60” Walk-In

Soaking Tub, Air Spa And Whirlpool

High Gloss

Walk-in Bath 32” x 60” Soaking Tub, Air Spa And Whirlpool

⁮3260.210.SXX Soaking Tub

•Acrylic with fiberglass reinforcement.

•Free standing metal support frame with five

adjustable leveling feet

•Easy access, powder coated aluminum door system

•Contoured, built-in seat.

•Built-in grab bar and textured bottom.

•Faucet / accessory deck areas.

•Color match cable driven drain assembly.

⁮3260.210.WXX Whirlpool system

•Electronic control with timer.

•1 HP variable flow pump system.

•12 adjustable massage jets with

•Automatic Tub Cleaning System - Ozone.

⁮3260.210.AXX Air Spa system

•Electronic control with timer.

•1 HP variable flow heater blower.

•Multiple seat and floor air injectors.

•Automatic purge cycle

⁮3260.210.CXX Combo system

•Combines Whirlpool And Air System

Nominal Dimensions

32” x 60” x 37 1/2”

Compliance Certifications

•ETL – INTERTEK SEMKO

•IAPMO - USPC

•ANSI Z 124.1.2 –for Plastic Bathtubs

•ASME A112.19.7 – Whirlpool Appliances

•ASME A112.19.15 –for Walk-in Bathtubs

•CSA B-45.5 – Canadian Plumbing Fixtures

To Be Specified – Required:

⁮Drain Configuration: Left (L) Or Right (R)

⁮Color: White (W) Or Linen (L)

⁮Faucet

⁮Quick Drain™: 9QUD

⁮Whirlpool Heater*: 9ILH (Whirlpool System Only)

⁮Chromatherapy: 9CTP

⁮Neck Rest: 9NR

SEE REVERSE FOR ROUGHING –IN

DIMENSIONS AND PRODUCT SPECIFICATIONS

* NOTE: The whirlpool heater is designed to

maintain water temperature during operation.

It will not heat cold water to desired bathing

temperature

32” x 60” Walk-In

Soaking Tub, Air Spa And Whirlpool

High Gloss

NOTES:

TUB IS SUPPORTED BY THE FRAME AND FIVE

INTEGRATED ADJUSTABLE FEET, NO ADDITIONAL

SUPPORT IS REQUIRED.

REFER TO INSTALLATION INSTRUCTIONS SUPPLIED

WITH TUB FOR ADDITIONAL INFORMATION.

FIXTURES NOT INCLUDED AND MUST BE ORDERED

SEPARATELY.

PROVIDE SUITABLE REINFORCEMENT TO SUB

FLOOR FOR ALL SUPPORTS.

IMPORTANT:

Dimensions of fixtures are nominal, may vary and are

subject to change or cancellation. No responsibility is

assumed for use of

superseded or voided leaflet

GENERAL SPECIFICATIONS FOR 3260.210.XXX

WALK IN BATH TUB

INSTALLED SIZE_______________60 x 32 x 37-1/2 In. (1524 x 812 x 952 mm)

WEIGHT ___________________________________________210 Lbs. (95 kg)

WEIGHT w/ WATER _________________________________877 Lbs. (398 kg)

OPERATING GAL. ____________________________________80 Gal. (302 L.)

FLOOR LOADING _______________________65 Lbs/Sq. Ft (321 Kgs/Sq. m.)

(PROJECTED AREA)

CUBE (FT³) ___________________________________________________41.7
