American Standard 1340M Series Mode d'emploi

755043-100 Rev. A

THANK YOU...

for selecting an American Standard bathing product. Your new bath is shipped to you after careful inspection. The

whirlpool version is completely assembled with pump, motor and system piping. All you need to finish the

whirlpool installation are your selected fittings, electrical connections and support bedding material.

To ensure maximum performance and pleasure from this product, please follow the instructions and cautions.

All product names listed herein are trademarks of AS America, Inc. unless otherwise noted.

For questions or service issues, please call Technical Support 1-(800)-442-1902.

Please do not contact or return product to the store.

OPERATING AND

MAINTENANCE MANUAL

MASTER SERIES WHIRLPOOLS

MODEL 2770 - CADET®5' x 32"

MODEL 2771 - CADET®5' x 36"

MODEL 2772 - CADET®5' x 42"

MODEL 2773 - CADET®6' x 36"

MODEL 2774 - CADET®6' x 42"

MODEL 2775 - CADET®CORNER

MODEL 2776 - CADET®5' x 32"

w/INTEGRAL APRON

755043-100 Rev. A

SAVE THESE INSTRUCTIONS

WARNING: Risk of personal injury. Do not permit children to use this unit without adult supervision.

WARNING: Risk of personal injury. Do not operate this unit without the guard over the suction fitting.

WARNING: Risk of electric shock. Do not permit electrical appliances (hair dryer, telephone, radio, etc.) within

60 inches (1524mm) of this unit.

WARNING: Risk of hyperthermia and possible drowning. People using medications and/or having adverse

medical history should consult a physician before using this product.

WARNING: Risk of personal injury. Do not overfill unit before entering. Entering tub when filled more than 2/3

can cause overflow and slippery conditions. Exercise caution when entering and exiting.

WARNING: No Food or Alcoholic Beverages. Use of your bathtub immediately after meals is not

recommended. Avoid alcohol consumption before or during bathing. Alcoholic beverages can cause drowsiness or

hyperthermia resulting in loss of consciousness or even drowning.

WARNING: Pregnancy. If you are or think you may be pregnant, consult your physician before using the bathtub.

Never drop or insert any object into any opening.

Use this unit only for its intended use as described in this manual. Do not use any attachments not recommended by

American Standard.

The unit must be connected only to a supply circuit that is properly protected by a ground-fault circuit-interrupter

(GFCI). Such a GFCI should be provided by the installer and should be tested on a routine basis. To test the GFCI,

push the test button. The GFCI should interrupt power. Push the reset button. Power should be restored. If the GFCI

fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the bathtub without the test button

being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this hydromassage

bathtub. Disconnect the hydromassage bathtub and have the problem corrected by a licensed electrician before using.

A pressure wire connector is provided on the exterior of the motor unit to permit connection of a no. 8 AWG solid

copper bonding conductor between this unit and all other electrical equipment and exposed metal in the vicinity, as

needed to comply with local requirements. To reduce the risk of an electric shock, connect this connector to the

grounding terminal of your electric service or supply panel with a conductor equivalent in size to the circuit conductors

supplying this unit.

IMPORTANT SAFETY

INSTRUCTIONS

INSTRUCTIONS PERTAINING TO

A RISK OF FIRE, ELECTRIC SHOCK

OR INJURY TO PERSONS

READ AND FOLLOW ALL INSTRUCTIONS!

755043-100 Rev. A

Operation: SYSTEM I WHIRLPOOL

BATHING:

• Fill bath with water at a comfortable bathing temperature - If your whirlpool is equipped with the optional

EZ-Heater, it will automatically maintain the water temperature.

• IMPORTANT: Do not fill the whirlpool more than 2/3 full before getting in, as it may overflow.

• IMPORTANT: Do NOT add bath oils or salts – this will damage the whirlpool pump.

• IMPORTANT: Water level must be at least one inch (25mm) above the highest jet before the whirlpool is

started. Operating the system without water (dry running) for extended periods will cause

pump damage and void the warranty.

STARTING WHIRLPOOL:

• Press on/off button to start whirlpool.

STOPPING WHIRLPOOL:

• Press on/off button again to stop whirlpool.

AIR VOLUME CONTROL ADJUSTMENTS:

• Water turbulence is determined by the amount of air mixed with the water. Rotate the air volume control

counterclockwise for more turbulence--clockwise for less.

FLOW JET VOLUME ADJUSTMENTS:

• The water flow action may be adjusted from vigorous to soft by rotating the nozzle clockwise for vigorous

massage and counter-clockwise for soft massage.

MORE VIGOROUS MASSAGE

(clockwise)

SOFTER MASSAGE

(counterclockwise)

MORE AIR LESS AIR

755043-100 Rev. A

OPTIONAL IN-LINE EZ-INSTALL™HEATER OPERATING INSTRUCTIONS:

(EXCEPT MODEL 2776 - CADET®5' x 32" w/INTEGRAL APRON)

Your whirlpool is equipped for use with the optional EZ-Install Heater Whirlpool Bath Heater, part no. 9075.120. Simply

locate the EZ-Install Heater Removable Blank near the whirlpool pump and replace it with the heater. Be sure to FOLLOW

ALL OPERATING, INSTALLATION, and SAFETY INSTRUCTIONS THAT COME WITH YOUR EZ-INSTALL HEATER

CAREFULLY BEFORE PROCEEDING WITH THE INSTALLATION. The heater will maintain the temperature of the water

in the whirlpool, or increase the temperature of the water in the whirlpool at about two to four degrees Fahrenheit per hour

up to a maximum of 104°F (40 °F). The heater includes the following components:

Thermostat:

The "Smart Thermostat" requires no adjustment and will automatically maintain the water temperature at 104° Fahrenheit

If the bathtub is too warm, simply adjust by adding cold water. See Important Safety Instructions supplied with heater.

High Limit:

The heater includes an exclusive “Intelligent High-Limit”. This safety circuit will not “false trip” from hot tap water. It will only

turn the heater of if the thermostat fails. If the high-limit trips frequently, call a service technician.

To manually reset the circuit in the event that the “High-Limit” switch has been activated, simply:

(1) Turn off the whirlpool pump

(2) Drain water from the tub

(3) Remove power from heater by unplugging at receptacle or turning off circuit breaker

(4) The heater circuit will automatically reset in less than 15 minutes

(5) Restore power to the heater

(6) Whirlpool bath is now ready to use

Indicator Light:

The light turns on when the heater is operating.

Pressure Switch:

The heater is equipped with a preset pressure switch. This switch will not allow the heater to turn on if the pump is not

running with water flowing through the whirlpool piping system.

755043-100 Rev. A

Your American Standard whirlpool is designed to give you many years of pleasure with reasonable care and

maintenance.

Your new acrylic bathtub is tough, durable and easy to care for. The colors have been formulated to match other

American Standard fixtures and enhance your choice of bathroom decorations. The high gloss surface will retain its

lasting luster with proper care and maintenance

CLEANING AND MAINTENANCE:

• Always fill the tub with temperate water. Excessively hot water (greater than 130° F) may cause surface damage.

• Remove bath mat after use and hang to dry. Allowing bath mat to dry in the tub may cause surface damage.

• Clean after use with a mild liquid household detergent cleaner. Do not turn on jets when such cleaners are present.

Do not use: Lestoil® Cleaner; Lysol® Disinfectant (spray or concentrate); or Lysol® Basin, Tub and Tile Cleaner;

Windex® Cleaner; Mr. Clean® Cleaner; Dow® Disinfectant Bathroom Cleaner*; or other cleaning products in

aerosol cans.

HARSH CHEMICALS, SHARP AND ABRASIVE OBJECTS SHOULD NEVER BE USED ON ACRYLIC SURFACES:

• Do not use wire brushes, knives or sharp objects to remove stains or other surface blemishes.

• Use of abrasive cleaners or powders will dull the surface. If the glossy surface looses its sheen, dulled areas can

be partially restored by rubbing with a white automotive body polishing compound and waxing with a liquid wax.

Do not wax surfaces where you walk or stand.

• Do not allow nail polish remover, acetone, dry-cleaning fluid, paint remover, or other solvents to come into

contact with the surface.

• Clean the surrounding surface immediately after using caustic drain cleaners.

Do not permit drain cleaner to enter circulation system.

• Burning cigarettes will irreparably damage the surface of the whirlpool.

CLEANING/PURGING THE CIRCULATION SYSTEM:

Once every month the circulating system must be purged and cleaned. Follow the steps outlined below:

1. Fill whirlpool with warm water and add two teaspoons of powdered automatic dishwasher (not laundry)

detergent and one-half cup of household bleach to filled whirlpool.

2. Activate whirlpool system in accordance with operating instructions and run system for two minutes.

3. Drain and refill whirlpool with cold water. Circulate for five minutes.

4. Drain whirlpool completely after step 3 (above) is completed.

For Troubleshooting and Repair Parts please log on to www.americanstandard-us.com

* Lestoil® is a registered trademark of The Clorox Company.

Lysol® is a registered trademark of The Linden Company.

Windex® is a registered trademark of S.C. Johnson and Son, Inc.

Mr. Clean® is a registered trademark of The Proctor and Gamble Company.

Dow® is a registered trademark of The Dow Chemical Company.

755043-100 Rev. A

In the United States:

American Standard Brands

P.O. Box 6820

Piscataway, New Jersey 08855

Attention: Director of Customer Care

For residents of the United States, warranty

information may also be obtained by calling

the following toll free number: (800) 442-1902

www.americanstandard.com

In Canada:

AS Canada, ULC

5900 Avebury Rd.

Mississauga, Ontario

Canada L5R 3M3

Toll Free: (800) 387-0369

www.americanstandard.ca

In Mexico:

American Standard B&K Mexico

S. de R.L. de C.V.

Via Morelos #330

Col. Santa Clara

Ecatepec 55540 Edo. Mexico

Toll Free: 01-800-839-1200

www.americanstandard.com.mx

AS America, Inc. Limited Warranty Acrylic Products

AS America, Inc. (“American Standard®”) warrants to the original consumer purchaser that it will, at its option, repair or replace any of its plumbing products

found by it to be defective under normal use and maintenance within the following periods from date of purchase:

Electronic Components - two (2) years

Pump Motors - two (2) years

Fittings and Plumbing - two (2) years

Shell - three (3) years

This limited warranty DOES NOT COVER the following:

1. Defects or damage arising from shipping, installation, alterations, accidents, abuse, misuse, lack of proper maintenance and use of other than genuine

American Standard replacement parts, in all cases whether caused by a plumbing contractor, service company, the owner or any other person.

2. Deterioration through normal wear and tear.

3. Expense of normal maintenance - periodic replacement of washers, seals, etc. is a normal maintenance requirement.

4. Postage or shipping costs for returning products for repairs or replacement under this limited warranty and labor or other costs incurred in connection

with product removal or installation under this limited warranty.

5. ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, ALL OF WHICH ARE HEREBY EXPRESSLY DISCLAIMED, OR THE

EXTENSION BEYOND THE ONE-YEAR DURATION OF THIS LIMITED WARRANTY OF ANY IMPLIED WARRANTIES, INCLUDING THOSE OF

MERCHANTABILITY OR FITNESS FOR PURPOSE INTENDED. (Some jurisdictions do not allow limitations on how long an implied warranty lasts, or

the exclusion or limitation of incidental or consequential damages, so these limitations and exclusions may not apply to you.)

6. Responsibility for compliance with local code requirements. (Since local code requirements vary greatly distributors, dealers, installation contractors and

users of plumbing products should determine whether there are any code restrictions on the installation or use of a specific product.)

7. If a Whirlpool unit is purchased by a dealer and used as a demonstration unit the Warranty takes effect as soon as the dealer uses the product as a

demo. If this demonstration unit is subsequently sold to a customer, the dealer may transfer the remaining period of the Warranty to the buyer only with

American Standard written approval.

This limited warranty gives you specific legal rights. You may have other statutory rights that vary from state to state or from province to province, in which case

this warranty does not affect such statutory rights.

For service under this warranty, it is suggested that a claim be made through the contractor or dealer from or through whom the product was purchased, or that

a service request (including a description of the product model and of the defect) be sent to the following address:

Autres manuels pour 1340M Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels American Standard Baignoire

American Standard

American Standard Princeton Recess Bath w/ Luxury Ledge and Integral Overflow 2394.202... Manuel utilisateur

American Standard

American Standard Rondo Whirlpool 7242.028W Manuel utilisateur

American Standard

American Standard Colony Corner 1730.002 Manuel utilisateur

American Standard

American Standard Standard 2083 SERIES Manuel utilisateur

American Standard

American Standard Ellisse 2711.XXXW Series Manuel utilisateur

American Standard

American Standard Heritage 2806.XXXW Series Manuel utilisateur

American Standard

American Standard CHAMPION 6069LCH Manuel utilisateur

American Standard

American Standard Whirlpool/Bathing Pool 2748.XXXW Manuel utilisateur

American Standard

American Standard Scala Oval 2645.002 Manuel utilisateur

American Standard

American Standard COLONY 2675 SERIES Manuel utilisateur

American Standard

American Standard Town Square 2748.002 Manuel utilisateur

American Standard

American Standard Cambridge 2460.028W Manuel utilisateur

American Standard

American Standard DXV LYNDON D12536-004 Manuel utilisateur

American Standard

American Standard Williamsburg Elite 5' Integral Apron Whirlpool... Manuel utilisateur

American Standard

American Standard Williamsburg Elite 2425E SERIES Manuel utilisateur

American Standard

American Standard Colony 2740.118C Manuel utilisateur

American Standard

American Standard Scala Oval Whirlpool 2645.018 Manuel utilisateur

American Standard

American Standard Ellisse 2705.118 Manuel utilisateur

American Standard

American Standard Savona 2901.XXXW Series Manuel utilisateur

American Standard

American Standard ELJER 015-0005 Manuel utilisateur

American Standard

American Standard Savona Oval Whirlpool 2903.018W Manuel utilisateur

American Standard

American Standard Green Tea 3571 Manuel utilisateur

American Standard

American Standard Green Tea Whirlpool and Bathing Pool... Manuel utilisateur

American Standard

American Standard Solar Bathtub 0163.060 Manuel utilisateur

Manuels Baignoire populaires d'autres marques

Agua

Agua BARTOLI-66 Manuel utilisateur

PAA

PAA PRELUDE Manuel utilisateur

BETTE

BETTE SILHOUETTE Manuel utilisateur

Kohler

Kohler K-820-GC Guide de démarrage rapide

Oliveri

Oliveri Naples Manuel utilisateur

Lyons

Lyons Elite ETLxx663219 Series Manuel utilisateur

Woodbridge

Woodbridge BJ500 Instructions de montage

Whirlpool

Whirlpool Ariel ARL-702 Manuel utilisateur

TEIKO

TEIKO EXCELLENT DUO Manuel utilisateur

Kohler

Kohler K-1111-H2 Guide de démarrage rapide

agape

agape MARSIGLIA AVAS1075 Manuel utilisateur

Kohler

Kohler K-1151 Instructions de montage

Kohler

Kohler K-1158 Guide de démarrage rapide

Kohler

Kohler K-1244 Instructions de montage

Kallista

Kallista P50045-G5 Instructions de montage

Kohler

Kohler K-1164-HB Guide de démarrage rapide

Kohler

Kohler Hourglass K-1209-LA Guide de démarrage rapide

Ariel

Ariel AM Series Manuel utilisateur
