Ambient Weather WS-02 Cabled Indoor and Outdoor

Thermometer with Probe

Table of Contents

1. Introduction.....................................................................................................................................1

2. Getting Started ................................................................................................................................1

2.1 Parts List .......................................................................................................................................1

2.2 Display Console Set Up................................................................................................................1

2.3 Sensor Operation Verification ................................................................................................2

3. Glossary of Terms...........................................................................................................................2

4. Specifications..................................................................................................................................2

4.1 Measurement Specifications.........................................................................................................2

4.2 Power Consumption......................................................................................................................2

5. Troubleshooting Guide....................................................................................................................2

6. Liability Disclaimer ........................................................................................................................3

7. Warranty Information......................................................................................................................3

1. Introduction

Thank you for your purchase of the Ambient Weather WS-02 indoor and outdoor thermometer with

probe. The following user guide provides step by step instructions for installation, operation and

troubleshooting. To download the latest manual and additional troubleshooting tips, please visit:

http://ambientweather.wikispaces.com/ws02

2. Getting Started

2.1 Parts List

QTY

Item

Display Console

Frame Dimensions (LxWxH): 3.5 x 2.5 x 0.75 in

LCD Dimensions (LxW): 1.5 x 1.25”

2.2 Display Console Set Up

Note: To avoid permanent damage, please take note of the battery polarity before inserting the

batteries.

Remove the battery door on the back of the display. Insert two AAA (alkaline or lithium) batteries in

the back of the display console, as shown in

Figure 1.

All of the LCD segments will light up for a few seconds to verify all segments are operating properly.

Replace the battery door, and fold out the desk stand and place the console in the upright position.

Figure 1

2.3 Sensor Operation Verification

Verify the indoor and outdoor (probe) temperature match closely. The sensors should be within 4°F

(the accuracy is ± 2°F). Allow a few minutes to stabilize.

3. Glossary of Terms

Term

Definition

Accuracy

Accuracy is defined as the ability of a measurement to match the actual

value of the quantity being measured.

Range

Range is defined as the amount or extent a value can be measured.

4. Specifications

4.1 Measurement Specifications

The following table provides specifications for the measured parameters.

Measurement

Range

Accuracy

Resolution

Indoor Temperature

32 to 140 °F

± 2 °F

0.1 °F

Outdoor Temperature

-40 to 140 °F

± 2 °F

0.1 °F

4.2 Power Consumption

2 x AAA 1.5VAlkaline batteries

Battery life: Minimum 24 months for base station

5. Troubleshooting Guide

If your question is not answered here, you can contact us as follows:

1. Email Support: support@ambientweather.com

2. Live Chat Support: www.ambientweather.com/chat.html (M-F 8am to 4pm Arizona Time)

3. Technical Support: 480-283-1644 (M-F 8am to 4pmArizona Time)

Problem

Solution

Temperature sensor reads too high in the

day time.

Make sure the probed thermometer is mounted in a

shaded area on the north facing wall.

Indoor and Outdoor Temperature do not

agree

Allow up to 30 minutes for the sensors to stabilize due to

signal filtering. The indoor and outdoor temperature

sensors should agree within 4 °F (the sensor accuracy is

± 2 °F)

Display console contrast is weak

Replace console batteries with a fresh set of batteries.

6. Liability Disclaimer

Please help in the preservation of the environment and return used batteries to an authorized depot.

The electrical and electronic wastes contain hazardous substances. Disposal of electronic waste in

wild country and/or in unauthorized grounds strongly damages the environment.

Reading the “User manual” is highly recommended. The manufacturer and supplier cannot accept any

responsibility for any incorrect readings and any consequences that occur should an inaccurate reading

take place.

This product is designed for use in the home only as indication of weather conditions. This product is

not to be used for medical purposes or for public information.

The specifications of this product may change without prior notice.

This product is not a toy. Keep out of the reach of children.

No part of this manual may be reproduced without written authorization of the manufacturer.

Ambient, LLC WILL NOT ASSUME LIABILITY FOR INCIDENTAL, CONSEQUENTIAL,

PUNITIVE, OR OTHER SIMILAR DAMAGES ASSOCIATED WITH THE OPERATION OR

MALFUNCTION OF THIS PRODUCT.

7. Warranty Information

Ambient, LLC provides a 1-year limited warranty on this product against manufacturing defects in

materials and workmanship.

This limited warranty begins on the original date of purchase, is valid only on products purchased and

only to the original purchaser of this product. To receive warranty service, the purchaser must contact

Ambient, LLC for problem determination and service procedures.

Warranty service can only be performed by a Ambient, LLC. The original dated bill of sale must be

presented upon request as proof of purchase toAmbient, LLC.

Your Ambient, LLC warranty covers all defects in material and workmanship with the following

specified exceptions: (1) damage caused by accident, unreasonable use or neglect (lack of reasonable

and necessary maintenance); (2) damage resulting from failure to follow instructions contained in your

owner’s manual; (3) damage resulting from the performance of repairs or alterations by someone other

than an authorized Ambient, LLC authorized service center; (4) units used for other than home use (5)

applications and uses that this product was not intended (6) the products inability to receive a signal

due to any source of interference or metal obstructions and (7) extreme acts of nature, such as

lightning strikes or floods.

This warranty covers only actual defects within the product itself, and does not cover the cost of

installation or removal from a fixed installation, normal set-up or adjustments, claims based on

misrepresentation by the seller or performance variations resulting from installation-related

circumstances.
