AmazonBasics B072Y2MRY2 Manuel utilisateur

cr eated by: Impala Services Ltd.Page size: 139.7 x 107.95 mm

B072Y2M

B07HGD179J

RY2

Drafting Stool

Tabouret De Dessin

Taburete de Dibujo

ドラフティングスツール

B072Y2MRY2-AmazonBasics-IM-V01 (Multi).indb 1 7/14/17 6:26 PM

English ..................................... 3

Français ................................. 12

Español .................................. 21

日本語 ..................................... 30

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 2

7/14/17 6:26 PM

Welcome Guide •English

Drafting Stool, Black

Contents:

Before getting started, ensure the package contains the following components:

Part Qty

Seat Cushion 1

Seat Plate 1

Gas Lift 1

Star Base 1

Casters 5

Screws 4

Wrench 1

B072Y2MRY2-AmazonBasics-IM-V01 (Multi).indb 3 7/14/17 6:26 PM

Assembly

Step 1:

Setting Up the Product

•Please keep the wrench for regular tightening.

•Turn the base upside down and press the casters into the holes of each of the base legs.

Check that they are securely ﬁxed.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 4

7/14/17 6:26 PM

Assembly

Step 2:

Setting Up the Product

•Place the base upright and insert the gas lift into the hole of the base.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 5

7/14/17 6:26 PM

Assembly

Step 3:

Setting Up the Product

•Align the seat plate over the pre-drilled holes underneath the seat cushion.

•Attach the seat plate to the seat cushion using four bolts. Tighten all the bolts with the

wrench , be careful not to cross thread the bolts or damage the seat.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 6

7/14/17 6:26 PM

Assembly

Step 4:

Setting Up the Product

•Turn the seat cushion upright and align the center hole of the seat plate over the gas lift, do not

sit on the seat cushion until the connection is secure.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 7

7/14/17 6:26 PM

Assembly

Step 5:

Setting Up the Product

Control handle

•To raise your seat, lean forward to lift your body weight from the seat, then pull up the control

handle.

•To lower the seat, pull up the control handle while you’re seated.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 8

7/14/17 6:26 PM

Cleaning and Maintenance

•Use a dry cloth to remove dirt.

•If required, use a slightly damp cloth to clean heavily soiled areas, then wipe dry using a dry cloth.

•

Occasionally, thoroughly wipe the frame using a slightly damp cloth. Then dry the frame using

a dry cloth.

•Do not use strong cleaning agents or abrasives.

•

Do not use the chair unless all screws are securely fastened. Screws should be re-tightened regularly.

Safety and Compliance

•Please read the instructions carefully before assembly.

•Remove all parts from the carton and ensure all parts are included prior to assembly.

•Assemble the stool on the carton or a carpet to prevent scratching the ﬂoor.

•Be careful not to cross-thread screws and do not use power tools.

•Before using the stool be sure that it is completely and properly assembled.

•Handle with care.

•War ning: Do not let children climb on or play with the product.

•Regularly check if all screws are tightly secured.

•The use of accessories or attachments, which are not recommended by the manufacturer can

pose hazard to persons or objects and cause injuries.

•Attention: The gas lift must be replaced and repaired by a qualiﬁed professional only.

•This stool is intended for indoor use only.

•Do not exceed the maximum load weight of 124.7 kg or 275 lbs.

•Do not use the stool if any components are damaged, worn, broken, or cracked. If required,

return the complete product to your place of purchase for an inspection, repair or adjustment.

•Be careful when using the product to avoid squeezing and shearing especially between

movable parts!

•Your stool is equipped with casters for all types of ﬂooring.

B072Y2MRY2-AmazonBasics-IM-V0

1 (Multi).indb 9

7/14/17 6:26 PM

Weight 5.9 kg / 13.01 lbs

Maximum load weight 124.7 kg / 275 lbs

Warranty Information

To obtain a copy of the warranty for this product:

Visit amazon.com/AmazonBasics/Warranty

— or —

Contact Customer Service at 1-866-216-1072
