AmazonBasics B072MF4SHR Manuel utilisateur

created by: Impala Services Ltd.Page size: 139.7 x 107.95 mm

B072MF4SHR

Aluminum Heavy Duty Steel Wire Double Post Shelf

Estante De Poste Doble De Aluminio Muy Resistente De Alambre de Acero

Grandes Étagères En Aluminium Dotées De Montants Doubles Et d’Un Grillage En Acier

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 1 8/28/17 5:49 PM

English ..................................... 3

Español.................................. 15

Français ................................. 27

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 2 8/28/17 5:49 PM

3

Welcome Guide •English

Aluminum Heavy Duty Steel Wire

Double Post Shelf

Contents:

Before getting started, ensure the package contains the following components:

Part Qty

Beam 10

Brace 10

Stiffener (included screws

and nuts) 10

Bottom post 4

Top post 4

Steel wire shelf 5

Bottom protective cover 4

Top protective cover 4

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 3 8/28/17 5:49 PM

4

Assembly

Step 1:

Setting Up the Product

•

Insert all 4 bottom protective covers to bottom , insert all 4 top protective covers to top .

• Note: Do not omit this step, which could protect your ﬂoor from scratches.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 4 8/28/17 5:49 PM

5

Assembly

Step 2:

Setting Up the Product

• Slide the rivets of brace into bottom posts of your desired location with the key slot

pointing down and shelf ledge of brace facing up. Tap lightly to seat rivets.

• Note: Make sure all the rivets are fully seated into the post slots. You may want to use a rubber

mallet (not included) to help push the rivets into the post slots. This applies to all the rivets used

in this unit.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 5 8/28/17 5:49 PM

6

Assembly

Step 3:

Setting Up the Product

• Repeat the previous step 2 to attach beams and braces to bottom posts until the ﬁrst

level is assembled.

• Note: Each of the beams and braces on the same level should be at the same height.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 6 8/28/17 5:49 PM

7

Assembly

Step 4:

Setting Up the Product

• Use screws to ﬁx stiffeners onto beams .

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 7 8/28/17 5:49 PM

8

Assembly

Step 5:

Setting Up the Product

• Repeat the previous two steps to attach beams and braces to posts until the ﬁrst two

levels are assembled.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 8 8/28/17 5:49 PM

9

Assembly

Step 6:

Setting Up the Product

• Top posts , bottom posts , beams , braces should be connected as illustrated.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 9 8/28/17 5:49 PM

10

Assembly

Step 7:

Setting Up the Product

• Repeat step 2 - 4 to form the third to ﬁfth levels.

B072MF4SHR-AmazonBasics-IM-V01 (US).indb 10 8/28/17 5:49 PM
